Marantz SG-5B User Manual

Box Contents
Contenido de la caja
Contenu de la boîte
Contenuti della confezione
Lieferumfang
Technical Specifications
Especificaciones técnicas
Spécifications techniques
Specifiche tecniche
Technische Daten
Type Electret condenser microphone
Polar Pattern Cardioid, supercardioid
70–16000 Hz (cardioid)
Frequency
Response
200–16000 Hz (supercardioid)
Sensitivity -72 dB (±3 dB; 0 dB = 1 V/μbar @ 1 kHz) (cardioid)
-55 dB (±3 dB; 0 dB = 1 V/μbar @ 1 kHz) (supercardioid)
250 Ω (+30%; @ 1 kHz)
Impedance
Polar Pattern
Patrón polar
Diagramme polaire
Figura polare
Polardiagramm
Cardioid
(1 kHz)
Marantz is a trademark of D&M Holdings Inc., registered in the U.S. and other countries. All other product or
company names are trademarks or registered trademarks of their respective owners. Manual Version 1.0

User Guide

Guía del usuario
Guide d'utilisation
Supercardioid
(1 kHz)
Guida per l'uso
Benutzerhandbuch
Equivalent Noise
Maximum SPL
Signal-to-Noise Ratio
Power Requirement
Dimensions
(length x diameter)
Weight
Frequency Response
Respuesta en frecuencia
Réponse en fréquence
Risposta di frequenza
Frequenzgang
marantzpro.com
< 34 dB
120 dB (THD α 1%, 1 kHz)
> 60 dB
9–52V DC phantom power
11.9" x 0.9"
302 x 22 mm
0.71 lbs. / 0.32 kg
Cardioid
Supercardioid
