Sames GNM 100 User Manual

Control module - 220v for manual guns
Hide thumbs
Table of Contents

Advertisement

Quick Links

FRANCE
SAMES Technologies. 13 Chemin de Malacher 38243 Meylan Cedex
Tel. 33 (0)4 76 41 60 60 - Fax. 33 (0)4 76 41 60 90 - www.sames.com
USA
SAMES Technologies Inc. 11998 Merriman Road, Livonia, Michigan, 48 150
Tel. (734) 261.5970 - Fax. (734) 261.5971 - www.sames.com
Index revision : C
From February 1st, 2017 SAMES Technologies SAS becomes SAMES KREMLIN SAS
A partir du 1/02/17, SAMES Technologies SAS devient SAMES KREMLIN SAS
User manual
GNM 100 control module - 220V
for manual guns
1
6209

Advertisement

Table of Contents
loading

Related Manuals for Sames GNM 100

Summary of Contents for Sames GNM 100

  • Page 1 FRANCE SAMES Technologies. 13 Chemin de Malacher 38243 Meylan Cedex Tel. 33 (0)4 76 41 60 60 - Fax. 33 (0)4 76 41 60 90 - www.sames.com SAMES Technologies Inc. 11998 Merriman Road, Livonia, Michigan, 48 150 Tel. (734) 261.5970 - Fax. (734) 261.5971 - www.sames.com...
  • Page 2 SAMES Technologies. © SAMES Technologies 2002 WARNING : Sames Technologies is registered as a "Training Center" approved by the "Ministry of Employment". Trainings with the aim of getting the necessary know-how to use and for the main- tenance of your equipment can be organised all along the year.

  • Page 3: Table Of Contents

    4.7. Faults ..........13 4.8. Cleaning the GNM 100 ......13 5.

  • Page 4: Introduction

    1. Introduction WARNING : Safety warning: the GNM 100 must never be installed in an explosive atmosphere. This means it must be installed outside the coating booth at a minimum distance of 1.5 meters (5 feet) from the nearest opening.

  • Page 5: Specifications

    2.2.2. Electrical output data Maximum voltage output 60 V RMS Frequency output 16-60 kHz Maximum output current 1,1 A RMS 2.2.3. Size GNM 100 Protection index: IP 64 Mass with cable 3 kg - 6.6 lbm Index revision : C 6209...

  • Page 6: Low Voltage Connections

    3. Low voltage connections 3.1. Supply The GNM can be supplied with 220 V or 110 V voltage, 50-60 Hz. Selection takes place by means of a switch located on the main printed circuit. 3.2. Low voltage connectors WARNING : see RT Nr 6169 for use with a high voltage unit UHT 153.

  • Page 7: Connecting Plug (19 Pins B)

    Example of a PLC cabling: 1 to 7 GNM case Inside GNM Main supply output protected by fuses PLC input Cabling for "HV ON" signalling light, 1 to 7 GNM case Inside GNM Main supply output protected by fuses 220 VAC oR 110 VAC Light on 3.5.

  • Page 8: Analog Input

    3.5.1. Analog input Cabling on external adjustment points can be 4/20 mA or 0-10 V. 3.5.1.1. 4/20 mA adjustment point This scale setting has to be done in a PLC. To do this, apply an adjustment point of 8 mA and another adjustment point of 16 mA and read the HV value on the GNM screen.
  • Page 9 3.5.3.2. Using external voltage The external voltage is between 12 and 24 Vdc. Input impedance roughly 1 k Ω . Supply return 12 to 24 V Inside GNM + 12 to 24 V dc 10 to 13 GNM case WARNING : Inputs 10 and 13 are opto-coupled inputs. They are therefore isolated from the earth. Make sure that the 0 V of the 12 to 24 V supply is at a potential close to the earth.

  • Page 10: Using Information Relative To The Faults

    3.5.4. Using information relative to the faults The closed contact of the OK board relay signals that the board is under voltage and that there is no fault. WARNING : This relay is for passing low currents. If a high current is used this contact can no longer be used for low currents.

  • Page 11: Operating Principle Of The Gnm 100

    4.1. Supply voltage and connections The voltage of the GNM 100 is preset at 220 V. Make sure that the earth terminal of the module (located at the back) is property connected to the earth with cable with a gauge between 6 and 10 mm2. Connect the mains cord.

  • Page 12: Storing The Set Points

    . The display will, for example, indicate: 4.4. Storing the set points The GNM 100 can memorise 9 U and I value tables preset by the user as needed. These tables are ref- erenced from J1 to J9. To create a table: •...

  • Page 13: Faults

    4.8. Cleaning the GNM 100 WARNING : turn off the GNM 100 control module before cleaning To clean paint from the front of the GNM 100, use a rag dipped (and not soaked) in ethyl alcohol or burning alcohol. Note: Do not use a solvent or a thinner.

  • Page 14: Plugs

    6. Plugs Ref. Part number Description Sale unit E4PTFS316 Male plug 7 contacts E4PTFS343 Male plug 12 contacts E4PTFS406 Female plug 19 contacts E4PTFA323 Cable clamp Index revision : C 6209...
