LUCCI ARENA II Installation Instructions

Installation Instructions
Thank you for purchasing this quality Lucci product. To ensure correct function and safety, please read and follow all
instructions carefully before assembly, installation and use. Please keep instructions for future reference.

Warranty

•
This light fitting is covered by a 3 year warranty. The warranty is from date of purchase, not the date of installation.
•
If the fitting is not installed by a licensed electrician the warranty will be void.
•
Please retain proof of purchase and evidence of installation by a licensed electrician.
•
Warranty will be void if there is any damage due to improper usage or modification to the fitting.
•
Failure to comply with the instructions in this manual may increase the risk of damage or injury and will void
warranty.
•
This fitting is not suitable for use with dimmer switches. Warranty will be void if the fitting is used on the same circuit
which has a dimmer

Installation requirements

•
Must be installed by a licensed electrician.
•
All wiring and installation of the light fitting must adhere to local and national wiring rules.
eg. AS/NZS 3000:2007/Amendment 2:2012 Electrical installations.
•
This fitting contains floating tempered glass. Replace any cracked protective glass to maintain IP rating when
using this fitting.
•
Select a suitable location for installation;
This product is suitable for indoor and outdoor use.
-
The mounting point must support 2 times the weight of the fitting.
-
This fitting is protected against water penetration to IP44 standards, which is splashing in every direction.
-
This fitting must not be mounted on a surface which can be subject to vibrations.
-
Take note of the directional marking on the fitting before installation.
-
•
Take care not to pull any electrical wires during unpacking as this may damage the connection.
•
Lay out all the components on a smooth surface and make sure there are no components missing before
assembling. If parts are missing, return the complete product to the place of purchase for inspection or
replacement.
•
Check whether the fitting has been damaged during transport. Do not operate/install any product which appears
damaged in any way. Return the complete product to the place of purchase for inspection, repair or replacement.
•
Ensure power to the circuit you are working on has been switched OFF before commencing any electrical work.

PIR sensor information

PIR (PASSIVE INFRA-RED) SENSOR:
The fitting has a PIR (Passive Infra-Red) sensing device which continuously scans the operating zone and immediately
switches the light on when it detects movement in that area. Whenever movement is detected within the range of the
sensor, the light will switch on automatically to illuminate the area. While there is movement within the sensor range,
the light will remain on.
1 | P a g e
ARENA II FLOOD LIGHT WITH SENSOR
SKU# 240711, 240713, 240715, 240717
Rated Voltage 220-240V~ 50Hz
switch.
v 1 . 0 p u b l i s h e d o n 0 7 . 2 0 1 7
