Installation & Configuration
Document 90-00066F
2017-09-28
Page 1
8128 SIP Strobe Light
FW Version 2.7.4
8128
8128A
8128B
8128R
8128ABR
Algo Communication Products Ltd
4500 Beedie St Burnaby BC Canada V5J 5L2
www.algosolutions.com
8128 SIP Strobe Light
Clear lens only
Clear lens with
AMBER
Clear lens with
BLUE
Clear lens with
RED
Clear lens with 3 color cover kit
support@algosolutions.com
cover
cover
cover
(604) 454-3792
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Algo 8128A
Summary of Contents for Algo 8128A
- Page 1 8128B Clear lens with BLUE cover 8128R Clear lens with cover 8128ABR Clear lens with 3 color cover kit Document 90-00066F Algo Communication Products Ltd (604) 454-3792 2017-09-28 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com Page 1 www.algosolutions.com...
-
Page 2: Table Of Contents
8128 SIP Strobe Light Table of Contents IMPORTANT SAFETY INFORMATION ...................... 5 ABOUT THE ALGO 8128 SIP STROBE LIGHT ..................... 6 ............................6 NCLUDED GETTING STARTED – QUICK INSTALL & TEST ..................7 WEB INTERFACE ............................. 9 MULTICAST OVERVIEW ........................10 WIRING CONNECTIONS ........................ - Page 3 ........................ 35 OWNLOAD ONFIGURATION ........................35 ESTORE ONFIGURATION ......................35 ESTORE ONFIGURATION TO EFAULTS ........................... 35 EBOOT THE EVICE Document 90-00066F Algo Communication Products Ltd (604) 454-3792 2017-09-28 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com Page 3 www.algosolutions.com...
- Page 4 SYSTEM TAB – NETWORK LOGGING ..................... 36 OPTIONAL COLORED LENS COVER ......................37 SPECIFICATIONS ........................... 37 FCC COMPLIANCE STATEMENT ......................38 Document 90-00066F Algo Communication Products Ltd (604) 454-3792 2017-09-28 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com Page 4...
-
Page 5: Important Safety Information
PoE switch must not leave the building perimeter without adequate lightning protection. Relay input and output connections must not leave the building perimeter without adequate lightning protection. Document 90-00066F Algo Communication Products Ltd (604) 454-3792 2017-09-28 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com Page 5 www.algosolutions.com... -
Page 6: About The Algo 8128 Sip Strobe Light
Dry contact closure input Multicasting Multiple Algo endpoints in a SIP environment require only one device to register as a SIP extension. Multicasting capabilities allow the SIP registered strobe to flash and simultaneously stream multicast events to the other Algo strobes, speakers and paging adapters in any combination and number of endpoints. -
Page 7: Getting Started - Quick Install & Test
If there is no DHCP server found the 8128 SIP Strobe Light will default to the static IP address 192.168.1.111. Most often however the 8128 will be assigned an IP address. To determine the IP address for the 8128 download the Algo locator tool to find Algo devices on your network: www.algosolutions.com/locator 4. - Page 8 The 8128 should not be installed beyond a building perimeter without adequately protecting the building wiring from lightning surge. Document 90-00066F Algo Communication Products Ltd (604) 454-3792 2017-09-28 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com...
-
Page 9: Web Interface
Enter the IP address (eg 192.168.1.111) into a browser such as Google Chrome, Firefox, or Internet Explorer (other than IE9). The web interface should be visible and the default password will be algo in lower case letters. Document 90-00066F... -
Page 10: Multicast Overview
IP address. All of the other 8128 SIP Strobe Lights are configured as multicast Slaves and will activate in response to the multicast message. Please note that any number and combination of Algo speakers, paging adapters and strobes can be part of a multicast. -
Page 11: Wiring Connections
Terminal Block Relay Out By default these terminals provide a contact closure when the 8128 SIP Strobe Light is active. This relay can be used to interoperate with other Algo speakers and strobes using 24 gauge single twisted pair. Document 90-00066F... -
Page 12: Terminal Block Reset
To return all settings to a factory default, use a wire pair to short these terminals at start up—continue until all the 8128 LEDs start a pulsing flash pattern. Document 90-00066F Algo Communication Products Ltd (604) 454-3792 2017-09-28 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com... -
Page 13: Web Interface Login
8128 SIP Strobe Light Web Interface Login The web interface requires a password which is "algo" by default. This password can be changed using the Admin tab after logging in the first time. Status The device’s Status page will be available before and after log on. -
Page 14: Basic Settings Tab - Sip
SIP registration is also required if using Subscribe/Notify to monitor the status of the extensions (see below). Document 90-00066F Algo Communication Products Ltd (604) 454-3792 2017-09-28 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com... -
Page 15: Authentication Id
Subscribe/Notify (message waiting event): When a message is left for the SIP extension then the 8128 will flash. Note: Phone system compatibility is required for “Subscribe/Notify” events. Document 90-00066F Algo Communication Products Ltd (604) 454-3792 2017-09-28 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com Page 15 www.algosolutions.com... -
Page 16: Basic Settings Tab - Features
Patterns 0 & 1 do not fire the center LEDs and are intended for a ceiling mount application where light is required in every horizontal direction but not straight down. Document 90-00066F Algo Communication Products Ltd (604) 454-3792 2017-09-28 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com... -
Page 17: Test Flash Pattern
Flash Pattern – (Ring/In-Use/Hold) Select a flash pattern to signal a Ring, In-Use, and/or Hold action. This setting only applies to Subscribe/Notify modes. Document 90-00066F Algo Communication Products Ltd (604) 454-3792 2017-09-28 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com... -
Page 18: Continuous
Relay Output Mode When the 8128 SIP Strobe Light is active this contact output will be either closed or open according to this selection. Document 90-00066F Algo Communication Products Ltd (604) 454-3792 2017-09-28 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com... -
Page 19: Multicast Ip Addresses
50000-50008 Make sure that the multicast IP address and port number do not conflict with other services and devices on the same network Document 90-00066F Algo Communication Products Ltd (604) 454-3792 2017-09-28 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com... -
Page 20: Basic Settings Tab - Multicast (Master Settings)
(Note, the 8128 cannot be both a multicast Master and Slave simultaneously). Master Zone Select the multicast zone to broadcast on. Document 90-00066F Algo Communication Products Ltd (604) 454-3792 2017-09-28 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com Page 20 www.algosolutions.com... -
Page 21: Send Flash Pattern And Cadence
If disabled then each Strobe may have a unique flash pattern according to its settings. Send 8180-Compatible Control Signal This option allows the 8128 SIP Strobe Light to activate Algo 8180 Audio Alerters via multicast. www.algosolutions.com/8180 Zone Definitions Multicast IP addresses and ports are configured by default. -
Page 22: Basic Settings Tab - Multicast (Slave Settings)
Select one or more multicast zones for the 8128 to monitor. Note that multicast zone priority is based on the zone definition list order (top to bottom). Document 90-00066F Algo Communication Products Ltd (604) 454-3792 2017-09-28 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com... -
Page 23: Zone Definitions
8128 SIP Strobe Light Zone Definitions See information in previous section under Master settings. Document 90-00066F Algo Communication Products Ltd (604) 454-3792 2017-09-28 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com Page 23 www.algosolutions.com... -
Page 24: Advanced Settings Tab - Network
When selected, DHCP will automatically configure IP addresses for each 8128 SIP Strobe Light on the network. Alternatively the 8128 can be set to a static IP address. Document 90-00066F Algo Communication Products Ltd (604) 454-3792 2017-09-28 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com... -
Page 25: Vlan Mode
Can provide quality of service if the DSCP protocol is supported on your network. Can be specified independently for SIP control packets versus RTP audio packets. Document 90-00066F Algo Communication Products Ltd (604) 454-3792 2017-09-28 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com... -
Page 26: Advanced Settings Tab - Admin
(as well as all other settings) back to the original factory default conditions. Confirmation Re-enter network admin password Device Name Name to identify the device in the Algo Network Device Locator Tool. Document 90-00066F Algo Communication Products Ltd (604) 454-3792 2017-09-28 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com... -
Page 27: Introduction Section On Status Page
Web Interface Session Timeout Set the maximum period of inactivity after which the web interface will log out automatically. Log Level Use on the advice of Algo technical support only. Log Size Consult Algo technical support. Log Method Allows the 8128 SIP Strobe Light to write to external Syslog server if the option for external (or both) is selected. -
Page 28: Advanced Settings Tab - Time
Time Zone Select time zone. NTP Time Server Allows the 8128 SIP Strobe Light to synchronize to an external time server. Document 90-00066F Algo Communication Products Ltd (604) 454-3792 2017-09-28 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com Page 28... -
Page 29: Advanced Settings Tab - Provisioning
(when set) supplies a TFTP boot server address to the DHCP client to boot from. DHCP must be enabled if using DHCP Option 66, in order for Provisioning to work. Document 90-00066F Algo Communication Products Ltd (604) 454-3792 2017-09-28 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com Page 29 www.algosolutions.com... -
Page 30: Md5 Checksum
8128 SIP Strobe Light One of two files can be uploaded on the Provisioning Server (for access via TFTP, FTP, or HTTP): Generic (for all Algo 8128 SIP Strobe Lights) algop8128.conf Specific (for a specific MAC address) algom[MAC].conf MD5 Checksum In addition to the .conf file, an .md5 checksum file must also be... -
Page 31: Generating A Specific Configuration File
The MAC address of each 81 can be found on the back label of the unit. For more information, see the Provisioning of Algo SIP Endpoints Guide. Document 90-00066F Algo Communication Products Ltd... -
Page 32: Advanced Settings Tab - Additional Extensions
Up to 5 SIP extensions can be registered for notification alerting of multiple events. To configure additional extensions click “Enable” beside the target extension and enter the Extension, Authentication ID, and Authentication password. Document 90-00066F Algo Communication Products Ltd (604) 454-3792 2017-09-28 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com Page 32 www.algosolutions.com... -
Page 33: Advanced Settings Tab - Advanced Sip
If Double CRLF is selected the 8128 SIP Strobe Light will send a packet every 30 seconds (unless changed) to maintain connection with the SIP Server if behind NAT. Document 90-00066F Algo Communication Products Ltd (604) 454-3792 2017-09-28 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com... -
Page 34: Server Redundancy Feature
Reconnect with higher priority server once available, even if backup connection still fine. Polling Method SIP message used to poll servers to monitor availability. Document 90-00066F Algo Communication Products Ltd (604) 454-3792 2017-09-28 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com Page 34 www.algosolutions.com... -
Page 35: System Tab - Maintenance
Restore Configuration to Defaults Resets all 8128 SIP Strobe Light device settings to factory default values. Reboot the Device Reboots the device. Document 90-00066F Algo Communication Products Ltd (604) 454-3792 2017-09-28 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com Page 35... -
Page 36: Firmware Image
8128 SIP Strobe Light Firmware Image Point to the firmware image provided by Algo. MD5 Checksum Point to the checksum file provided by Algo. Upgrade 8128 SIP Strobe Light Firmware 1. From the top menu, click on System, then Maintenance. -
Page 37: Optional Colored Lens Cover
Compliance EN60950:2001, IEEE 802.3-2008, RFC3261, RoHS, CE, FCC, CSA (USA & Canada) Document 90-00066F Algo Communication Products Ltd (604) 454-3792 2017-09-28 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com Page 37... -
Page 38: Fcc Compliance Statement
Document 90-00066F Algo Communication Products Ltd (604) 454-3792 2017-09-28 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com... - Page 39 8128 SIP Strobe Light This page has been intentionally left blank. Document 90-00066F Algo Communication Products Ltd (604) 454-3792 2017-09-28 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com Page 39 www.algosolutions.com...
- Page 40 8128 SIP Strobe Light Document 90-00066F Algo Communication Products Ltd (604) 454-3792 2017-09-28 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com Page 40 www.algosolutions.com...
