Page 1: Matrix Switcher
Matrix Switcher MTS800A Video Management System Installer User’s Guide Before connecting, operating or adjusting this product, please read this instruction booklet carefully and completely. -
Page 2: Table Of Contents
Parts ........9 MTS800A Sample System Configuration ....10 Connectors . -
Page 3: Introduction
MTS800A is an all-in-one medical device switcher solution that manages several independent input/ output systems typically found in a surgical environment. MTS800A uses a stand alone PC, or a tablet PC with touch screen user interface to control video switching. Streaming is also available, and live preview of the active video signal can be seen on the controlling PC. -
Page 4: Symbol Definitions
Symbol Definitions The following symbols appear on the product, its labeling, or the product packing. Each symbol carries a special definition, as defined below: AC Voltage Switches on power Switches off power Contained spare fuse Consult accompanying documents Indicates protective earth ground Indicates top-bottom direction Fragile... -
Page 5: Safety Instructions
Safety and Instructions Please read the following safety instructions as they are designed to prevent damage to property and harm to the user. Warning / Caution Failure to follow directions noted by this symbol could result in bodily harm or damage to equipment. -
Page 6: Caution
Caution CAUTION RISK OF ELECTRICAL SHOCK DO NOT OPEN This symbol alerts the user that important literature concerning the operation of this unit has been included. Therefore, it should be read carefully in order to avoid potential problems. This symbol warns the user that un-insulated voltage within the unit may have sufficient magnitude to cause electrical shock. - Page 7 The user could lose authority to operate this equipment if an unauthorized change or modification is made. MTS800A image processing system should be used by qualified staff who have a corresponding specialized qualification and who have been instructed in the use of the system.
- Page 8 Recycling : Follow local governing ordinances and recycling plans regarding the recycling or disposal of this equipment. Servicing dangerous voltages or other hazards, and will void the warranty. Refer all servicing to qualified personnel under the following conditions: - If the power cord or plug is damaged or frayed. - If liquid has been spilled into the system.
-
Page 9: Parts
Package Contents Item Description ..........1 . -
Page 10: Mts800A Sample System Configuration
MTS800A Sample System Configuration Wall Monitors Mount Boom or Stand IP Address Monitors 1 - 8 1 - 4 1 - 4 1 - 4 Tablet with Control Interface INPUT ENTER MTS800A OUTPUT MENU DVI-D 3G-SDI CVBS Video Sources to be Switched... -
Page 11: Connectors
Connectors 23 24 STREAM 25 26 100-240VAC 50-60Hz MONITOR OUT CVBS RS-232C AC in CVBS 3 out AC on/off switch CVBS 4 out CVBS 1 in RGB 1 out CVBS 2 in RGB 2 out CVBS 3 in RGB 3 out CVBS 4 in RGB 4 out RGB 1 in... -
Page 12: Connect Input Video Sources
CVBS RS-232C RS-232C Output video signals from medical equipment. Connect video sources to input ports on the back panel of MTS800A. Input signal choices are: 4 - C-Video 4 - RGB 8 - DVI‐D and SDI out is not supported. -
Page 13: Connect Output Video Destinations
Connect Output Video Destinations After incoming video signals are connected to MTS800A, they are switched and sent out, or output, to a destination. A destination is usually a surgical display monitor. There are 20 output ports that correspond to the video inputs. Additional output ports are available for video stream preview and DVI-connected monitor preview of the active video signal. -
Page 14: Connect Power
Connect Power shock or equipment damage. To avoid the risk of electric shock, this equipment must only be connected to a power supply with protective grounding. MTS800A back panel 100-240VAC 50-60Hz CVBS CVBS Precaution Turn off system power switch before making any video connection modifications. -
Page 15: Connect A Remote Control Device
Connect A Remote Control Device The preferred way to manipulate video signals with MTS800A is by connecting a remote control device, such as a touch screen tablet. This allows use of the graphic user interface that has been designed for the features available with MTS800A. -
Page 16: Methods Of Operation
Operating room staff Remote control device Cutomize Buttons, Presets Please consult the user guide for the remote control device connected to MTS800A. Front Panel Button Control A can also be controlled through the use of front panel push buttons. S800... - Page 17 Entering System Mode or installer. The System Mode in MTS800A is used to alter these functions, and is almost Maneuvering on the front panel of MTS800A. The functions listed below can be accessed and changed through System Mode INPUT ENTER...
-
Page 18: Streaming Setup
Streaming Setup Use a network to connect MTS800A and a PC Router MTS800A PC / file cloud server STREAM Router MONITOR OUT RS-232C RS-232C Obtain the streaming IP address for MTS800A INPUT ENTER OUTPUT MENU System Mode. INPUT ENTER Main IP address. Record... - Page 19 Each MTS800A installation has unique requirements for viewing streamed content. Specialized order to allow streaming. To view streamed content from MTS800A, it is important to choose media player software that has features geared towards playing digital video, including standard control icon buttons for...
-
Page 20: General Specification
General Specification Item Description Model CVBS Analog RGB out is not supported. CVBS Inputs Analog RGB CVBS Outputs Analog RGB DVI-D Preview Outputs RJ-45 Video Stream for Tablet and PC Streaming RJ-45 RS-232C Control Outputs Power Requirements Power Consumption General Temperature Compliance and Certifications FSN1979 - 6/2017... -
Page 21: Input/Output Connectors
Input/Output Connector Specification CVBS/SDI Assignment Composite /SDI Ground Assignment Assignment Green Ground-Sync Blue Ground Ground DDC Data DDC 5V Standby Ground-Red V.Sync Ground-Green DDC Clock Ground-Blue Assignment Assignment T.M.D.S. Data2 T.M.D.S. Data2+ +5V Power T.M.D.S. Data2 Shield T.M.D.S. Data0 DDC Clock T.M.D.S. -
Page 22: Timing
Input/Output Connector Specification (cont.) Assignment Assignment DSR/RI Input/Output Timing RGB / DVI input and output Resolution 31.500 70.000 28.320 31.500 60.000 25.170 37.500 75.000 31.500 37.900 60.000 40.000 46.900 60.000 49.500 48.400 60.000 65.000 60.000 75.000 78.750 64.000 60.000 108.000 80.000 75.000 135.000... -
Page 23: Mechanical Drawing
Mechanical Drawing 437 mm/17.21 in. 437 mm / 17.2 in. INPUT ENTER OUTPUT MENU FSN1979 - 6/2017 English - 23... -
Page 24: Troubleshooting, Cleaning Instructions
Precaution: Before cleaning, turn power off. Do not apply or spray cleaner directly onto the the cloth first. Follow your hospital protocol for the handling of blood and body fluids. MTS800A is not disinfected or packed in a sterile environment. Follow your hospital protocol in case MTS800A needs to be disinfected prior to installation. -
Page 25: Fuse Replacement
Fuse Replacement Precaution: Before fuse replacement, turn off power, and remove all power cords from MTS800A. Extract fuse Open the fuse compartment cap and use the slot opening compartment by hand. flat screwdriver to pry up and to push the fuse with the open the fuse compartment. - Page 26 Notes FSN1979 - 6/2017 26 - English...
- Page 28 Thank you for choosing our product. Service Please contact our customer service if you need any information or help with our products. Warranty One year, parts and labor. EC Representative FORESEESON GmbH FORESEESON UK Ltd. FORESEESON KOREA 404B, Pangyoinnovalley B, 253 Pangyo-ro, Bundang-gu, FORESEESON (Shanghai) Medical Equip.
