DISASSEMBLY AND MAINTENANCE
1.
Unplug the folder.
2.
Remove the two nuts form the bottom sides of the folder. Return the folder to its normal upright
position and lift off the plastic housing.
3.
The rubber rollers may be cleaned with isopropyl alcohol using a clean lint free cloth.
FOLDING TIPS
For easy loading:
1. Grab the paper with one hand as shown in Figure 1.
2. Hold the paper at the top so that it is bowed
lengthwise away from the machine as shown in
Figure 2.
3. Slide the paper against the paper guides as you load
it into the machine.
To avoid jams, ensure that the documents are properly
aligned when folding 2-3 sheets at a time.
Keep this instruction booklet for reference purposes.
Martin Yale Industries, Inc. is a manufacturer of
office equipment forms and document handling
products, paper trimmers, and graphic arts prod-
ucts for the printing professional and modern
electronic publishers.
Figure #1
Figure #2
Premier is a Division of Martin Yale Industries, Inc.
251 Wedcor Avenue • Wabash, IN 46992
Phone (260) 563-0641 • Fax (260) 563-4575
Website: www.martinyale.com
Email: info@martinyale.com
Printed in Taiwan
Revised August 10, 2001
P6200
LETTER
FOLDER
Model P6200 Letter Folder
Maintenance and Operating Instructions
WARNING: NEVER CONNECT POWER UNTIL YOU ARE
READY TO USE THE LETTER FOLDER. THE AC OUTLET
USED FOR THIS MACHINE MUST BE NEARBY AND MUST NOT
BE BLOCKED. THIS MACHINE CONTAINS MOVING PARTS
THAT CAN CATCH HAIR, LOOSE CLOTHING OR JEWELRY.
DURING OPERATION AND MAINTENANCE, KEEP HAIR,
LOOSE CLOTHING AND JEWELRY CLEAR OF MOVING PARTS.
DISCONNECT THE POWER CORD FROM THE WALL OUTLET
BEFORE ATTEMPTING ANY SERVICE TO THE UNIT, AND
BEFORE OPENING THE COVER FOR ANY REASON.
Specifications
Power:
Paper Sizes:
Paper Guide Width:
Capacity:
Dimensions:
Weight:
Foot Print:
Envelope Size:
120AC Volts Adaptor, 60Hz (UL and CSA
approved.)
81/2" X 11"
8.59"
1 to 3 sheets of 20# bond paper. (Sheets
may be stapled.)
13.63" W X 5.94" D X 9.75" H
7.39 lbs
13.75" W X 6.25" D
Folded documents fit #10 business
envelopes.
