NOTES
NOTES
PC board shown are viewed from parts side.
The parts with no reference number or no parts number
in the exploded views are not supplied.
As regards the resistors and capacitors, refer to the
circuit diagrams contained in this manual.
!
Parts marked with this sign are safety critical
components. they must be replaced with identical
components - refer to the appropriate parts list and
ensure exact replacement.
Parts of [ ] mark can be used only with the version designated.
[E]: EUROPE [UK]: U.K.
CD/CASSETTE MICRO SYSTEM
CONTENTS
CONTENTS
2
3
5
10
16
18
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Teac MC-D5
Summary of Contents for Teac MC-D5
-
Page 1: Table Of Contents
CD/CASSETTE MICRO SYSTEM NOTES NOTES CONTENTS CONTENTS 1 SPECIFICATIONS PC board shown are viewed from parts side. 2 ADJUSTMENT AND CHECKS The parts with no reference number or no parts number in the exploded views are not supplied. 3 EXPLODED VIEW AND PARTS LIST As regards the resistors and capacitors, refer to the 4 PC BOARDS AND PARTS LISTS circuit diagrams contained in this manual. -
Page 2: Specifications
MC-D5 1 SPECIFICATIONS CD PLAYER Section Pickup: 3-beam pick-up Wavelength : 790 nm 20 Hz ~ 22 kHz Audio frequency response : CASSETTE DECK Section 4 track, 2 channel stereo Track System: 4.76 cm/sec Tape Speed: 0.4% or less Wow and Flutter:... -
Page 3: Adjustment And Checks
1. Set the function switch to the AM position. 2. Connect the test loop antenna across the output of the signal generator. 3. Connect the oscilloscope to the speaker terminal. 4. Set the signal generator as listed in the alignment chart. MC-D5 TUNER PCB... - Page 4 MC-D5 2-1-3 FM/AM alignment chart SG SETTING TUNER SETTING ADJUSTMENT POINT ADJUSTMENT ITEM 87.5MHz 87.5MHz Adjust for max.output. 1. FM band 1kHz, +/-22.5kHz dev. 90MHz 90MHz 1kHz, +/-22.5kHz dev. Adjust for max. output 106MHz and best waveform. 106MHz 1kHz, +/-22.5kHz dev.
-
Page 5: Exploded View And Parts List
MC-D5 3 EXPLODED VIEWS AND PARTS LIST EXPLODED VIEW - 1... -
Page 6: Exploded View
MC-D5 EXPLODED VIEW-1 REF. NO DESCRIPTION REMARKS PARTS NO. 05-30EX0M500000 CD PCB ASSY 56-07EX0M17B000 PCB BRACKET 05-07EX0M500000 POWER PCB ASSY 05-02EX0M500000 TUNER PCB ASSY 05-23EX0M100000 O/C SWITCH PCB ASSY 56-04EX0M10A040 FRONT CABINET (SILVER) 56-04EX0M10B010 FRONT CABINET (BLACK) 61-61D200000020 LOCK WASHER... - Page 7 MC-D5 EXPLODED VIEW - 2...
- Page 8 MC-D5 EXPLODED VIEW-2 REF. NO DESCRIPTION REMARKS PARTS NO. 56-14EX0M10A020 CD DOOR (SILVER) 56-14EX0M10B020 CD DOOR (BLACK) 56-58EX0M118000 BADGE LOGO (M01241801A) 56-58EX0M500010 BADGE LOGO (M01241802A) 56-57EX0M501000 CD DOOR LENS 56-57EX0M129000 POWER LENS 56-57EX0M130010 DISPLAY LENS (SILVER) 56-57EX0M130020 DISPLAY LENS (BLACK)
- Page 9 MC-D5 EXPLODED VIEW-2 REF. NO DESCRIPTION REMARKS PARTS NO. 2-39 58-263122300020 RUBBER FOOT (HARD) 2-40 45-114200411008 AC CORD BS APP 2M (BES) [UK] (BLACK) 45-114200510008 AC CORD BS PLUG VDE APP [HK] (SILVER) 45-114200500005 AC CORD VDE APP CORD [EUR]...
-
Page 10: Pc Boards And Parts Lists
MC-D5 4 PC BOARDS AND PARTS LIST TUNER PCB ASSY REMARKS REF. NO PARTS NO. DESCRIPTION 05-02EX0M500000 TUNER PCB ASSY 48-02EX0M100220 TUNER PCB 32-022102800020 FERRITE BAR 10X80MM JACK R-018 FOR FM ANTENNA 43-420180000020 45-194150000020 FM ANTENNA WIRE CE/75 #STV8-1H -1500... - Page 11 MC-D5 TUNER PCB R/P PCB...
- Page 12 MC-D5 CD PCB ASSY REF. NO PARTS NO. DESCRIPTION REMARKS 05-30EX0M500000 CD PCB ASSY 48-30EX0M100223 CD PCB 43-012150160320 WAFER 6PIN P=1.5MM CON305 43-022200150120 WAFER 5PIN P=2MM CON410 43-022100216120 WAFER 16P P=1MM CON413 43-012100230120 WAFER 30P P=1MM D403,404,407, 12-1N4148000021 DIODE 1N4148...
- Page 13 MC-D5 CD PCB D423 C414 Q410 CN401 CON413 D422 J428 D403 R418 R417 R419 CON406 D408 R420 D409 Q404 D410 C401 D411 R444 IC401 D413 D412 R125 C402 R415 D415 D414 C412 R427 Q402 R416 CN402 D416 D407 Q405 R428...
- Page 14 MC-D5 POWER PCB ASSY REF. NO PARTS NO. DESCRIPTION REMARKS 05-07EX0M500000 POWER PCB ASSY 48-07EX0M300121 POWER PCB C757 26-017680850121 CE-25V 6800UF C769 26-017100650121 CE-10V 1000UF C808 26-017100850121 CE-25V 1000UF CON701 43-012200170120 WAFER 7PIN P=2MM CON702,704 43-012200150120 WAFER 5PIN P=2MM CON703...
- Page 15 MC-D5 POWER PCB DISPLAY PCB KEY PCB CON1 POWER OP / CL CON501 TIMER PL / PA J119 TAPE MO / ST TUNER J17 J12 STOP REPEAT TIME LCD401 CN502 MEMORY CN503 LED401...
-
Page 16: Wiring Diagram
MC-D5 5 WIRING DIAGRAM TO DISPLAY PCB CON1 TO KEY PCB CON503 CD PCB CON413 TO KEY PCB CON501 CN401 CON406 TO KEY PCB CON502 TO TUNER PCB CON1 TO TUNER PCB CON2 TO CD DECK CON403 CON404 TO POWER PCB CON702... - Page 17 MC-D5 TO CASS DECK POWER PCB CON703 TO TUNER PCB CON3 CON704 CON707 CON708 TO H/P PCB TO TRANSFORMER...
-
Page 18: Included Accessories
MC-D5 6 INCLUDED ACCESSORIES INCLUDED ACCESSORIES REF. NO PARTS NO. DESCRIPTION REMARKS 77-20EX0M500020 INSTRUCTION BOOK-E/F/S/I 02-17EX0M500000 REMOTE CONTROL (BLACK) 02-17EX0M500001 REMOTE CONTROL (SILVER) - Page 19 TEAC NEDERLAND BV Oeverkruid 15,NL-4941 W Raamsdonksveer, Nederland Phone:0162-510210 TEAC BELGIUM NV/SA. c/o TEAC NEDERLAND BV, Oeverkruid 15, NL-4941 W Raamsdonksveer, Nederland Phone:+31-162-510860 TEAC ITALIANA S.p.A. Via C, Cantu 11, 20092 Cinisello Balsamo, Milano, Italy Phone:02-66010550 TEAC AUSTRALIA PTY., LTD.
- Page 20 CD/CASSETTE MICRO SYSTEM...
- Page 21 MC-D5 CD/CASSETTE MICRO SYSTEM...
- Page 22 LED2 LED1 MC-D5 CD/CASSETTE MICRO SYSTEM...
- Page 23 MC-D5 CD/CASSETTA MICRO SYSTEM...
