This guide will show you how to set up your new Lorex system
for connection over the Internet using a PC, Mac, Smartphone,
or Tablet.
This system features
connectivity using the exclusive
Lorex Stratus solution.
C O N N E C T I V I T Y
This cloud-enabled service allows for Internet connectivity
without requiring any network configuration. Each system
includes a Device ID, a unique code that allows your system
to handshake with Lorex's servers for a secure connection over
the Internet.
Please note that an upload speed of 1Mbps is recommended
for the best video performance. Up to 3 devices may connect
to the system at the same time.

Before You Start:

Make sure you have:
• A router and high-speed Internet
access (not included).
• Connected your DVR to your router
using an Ethernet cable (see the Quick
Connection Guide for details).
• Upgraded your DVR firmware and
client software or mobile app to
the latest versions. The latest versions
of firmware and software are required to
connect to the system.
ECO4 LH150 Series
Quick Networking Guide
1
iPhone/iPad
a
Install the free Lorex ECO Stratus app from
the App Store.
Tap the Lorex ECO Stratus icon to open
b
the app.
c
Tap Device Manager.
d
Tap
.
e
Configure the following:
1
Name: Enter a name for your DVR of your choice.
Device ID: Press the QR code icon (
2
Device ID and line up the QR code on the top of
the DVR using the camera on your device.
Device ID: xxxxxxx
OR if your device does not have a camera,
manually enter the Device ID printed on the label.
Client Port: Enter the Client Port
3
(default: 9000).
User Name: Enter the DVR's User Name
4
(default: admin).
5
Password: Enter the DVR's Password
(default: 000000).
6
Channels: Tap Click to retrieve channels.
f
Tap Save, then tap Menu.
g
Tap Live Monitor.
Tap + on one of the display
h
areas and select the camera you would like to view. You will
be prompted to change the DVR password. Tap OK.
i
Enter the new password and tap Done. This password will be
used to connect to your system from now on.
j
Tap + on one of the display areas and select the camera you
would like to view.
Congratulations! You can now view video from your cameras on your smartphone or tablet.
Mobile Connection
a
Install the free Lorex ECO Stratus app from
the Google Play Store.
Tap the Lorex ECO Stratus icon to open
b
the app.
c
Tap Device Manager.
d
Tap Add.
e
Configure the following:
1
Name: Enter a name for your DVR of your choice.
) next to
DeviceID: Press the QR code icon (
2
Device ID and line up the QR code on the top of
1
the DVR using the camera on your device.
2
Device ID: xxxxxxx
3
OR if your device does not have a camera,
manually enter the Device ID printed on the label.
4
3
Client Port: Enter the Client Port
(default: 9000).
5
User Name: Enter the DVR's User Name
4
(default: admin).
Password: Enter the DVR's Password
5
(default: 000000).
6
Channels: Tap Press to get channel number.
6
f
Tap Save, then tap Back.
g
Tap Live Monitor.
Tap +
Tap + on one of the display areas and tap
h
Select. Select the camera you would like to view. You will be
prompted to change the DVR password. Tap OK.
i
Enter the new password and tap Save. This password will be
used to connect to your system from now on.
j
Tap + on one of the display areas then tap Select. Select the
camera you would like to view.
15 Minutes
Android
) next to
1
2
3
4
5
6
Tap + then
Select
