Appendix 1 - Futurecom MOBEXCOM DVE User Manual

General Specifications
Dimensions Height / Width / Depth
Channel Spacing
DC Current Drain
Operating Temperature
Protection Against Liquids
RF Connector Impedance
External Connectors
Computer Interface
Power Output at TX Connector
Carrier Frequency Stability
Model (TX and RX Frequency Band)
Applicable Standards
Futurecom Systems Group Inc. DVE Users Manual 8A084X03_Rev1_31.DOC Rev. Preliminary

APPENDIX 1

92mm (3.63") / 186mm (7.32") / 315mm ( 12.41")
Weight
Power Supply
OFF
RPTR Standby
Receive
Transmit
Duty Cycle
RF Connector
Mobile Radio
DC Power
3.0 W Max. (programmable per channel from 0.3 W
CCT Option
Audio Distortion
DVE VHF
DVE UHF
DVE 700
DVE 800
MIL-STD 810C,D,E,F
MIL-STD 810C,D,E,F
5.2 kg (11.5 lbs) approx.
12.5 kHz or 25 kHz
Analog Voice or P25 Modulation
13.8 VDC ± 20%, negative ground only
Max. 0.01 A
Max. 0.8 A
Max 0.8 A
Max. 2.0 A @ 3 W RF output at TX Connector
-30°C to +60°C
IP6 (water jet proof)
50 Ohms
100% TX
Mini UHF female
USB, 9 pin male circular
20 pin male circular
6 pin male circular
Min.)
15 sec to 15 min. or disabled
± 1.5 ppm, from –30° to +60°C, ambient +25°C
reference
<2%
136 - 174 MHz
380 - 512 MHz
763 - 805 MHz
806 - 869 MHz
Test
For rain, dust and salt atmospheres
For shock and vibration
