- Page 1 PEELING MACHINE ALTO FP108, FP110, FP111, FP112, FP113 Installation and user manual 25.5.2015 4080160MT, 4080160MU, 4080161MT, 4080161MU, 4080162MK, 4080162MM, 4080162MO, 4080163MT, 4080163MU, 4080164MK, 4080164MM, 4080164MO...
- Page 2 INDEX CHAP. 1. CONTENT ORGANIZATION AND CONSULTATION MODALITY CHAP. 2. GENERAL INFORMATION AND CHARACTERISTICS CHAP. 3. SAFETY INSTRUCTIONS CHAP. 4. TRANSPORTATION, PUT ON SERVICE AND USE CHAP. 5. MAINTENANCE, BREAKS RESEARCH AND CLEANING CHAP. 6. SELLING CHAP. 7. MANUFACTURING MATERIALS GUARANTEE The machine is guaranteed 12 (twelve) months from the sale date.
-
Page 3: Chap. 1. Content Organization And Consultation Modality
CHAP. 1. CONTENT ORGANIZATION AND CONSULTATION MODALITY MANUAL PURPOSE MANUAL IMPORTANCE The present instructions manual for the use is to be considered as integral parts of the machine: must be kept for all machine life. must be coupled with the machine in case of its ceasing. besides to show all useful notices for the operators, contains (collected in specific chapters) the electric diagrams that will be used for the possible maintenance interventions and reparation. -
Page 4: Chap. 2. General Information And Characteristics
SIMBOLOGY MEANING Here follow it is clearly specified the symbols and definitions meaning, which will be used in the present document. DANGER It shows the danger presence for who works on the machine and for who is the vicinity, so the indicated activity must be performed in accordance with the actual accident prevention standards and with the indications showed in the present manual. - Page 5 TECHNICAL AND MANUFACTURING DATA CHARACTERISTICS TECHNICAL DATA Model 5 kg Model 10 kg Model 18 kg Peeler motor power (kW) / (Hp) 0,37kW / 0,50Hp 0,55kW / 0,75Hp 0,90kW / 1,2 Hp Mussels scraper motor power (kW) / (Hp) 0,35kW / 0,50Hp 0,35kW / 0,50Hp 0,65kW / 0,90Hp Peeler dish revolutions number...
- Page 6 GROUP EXAMPLE 1. superior cover 5Kg.TABLE TOP 2. superior cover handle 3. handle for product discharging door 4. drosses harvest drawer 5. controls panel 6. electric box 7. machine hull 8. support feet 9. high support stand with discharge connection WORKING FLATS SIZES (mm) 385mm...
- Page 7 NORMAL USE, IMPROPER USE, NOT CORRECT USE OR FORBIDDEN The machine described in the present instructions manual for the use is foreseen to be driven from an only operator skilled and prepared on residual risks, but with the competence, in safety matter, of maintenance employees. The operator should have at least the minimum age foreseen from the social laws about the work and having had the necessary technical training at least from a more expert operator that had him preliminarily trained for the correct use of the machine.
-
Page 8: Chap. 3. Safety Instructions
CHAP. 3. SAFETY INSTRUCTIONS INTRODUCTION The lacked standards and safety procedures applications can be danger and damage sources. The machine means bound in the use for the respect, on behalf of the final user, of: 1. all rules, of insertion in the environment and of people behavior, fixed from the laws and/or applicable standards;... - Page 9 PROTECTION DEVICES ON THE MACHINE The machine protections and safety devices must not be removed. If they must be removed for extraordinary maintenance requirements some measures will have to be immediately adopted ready to put in evidence and to reduce at the possible minimum limit the danger. The putting back in its place of the protection or of the safety device must happen as soon as the reasons, that have made necessary their temporary removal, are stopped.
-
Page 10: Chap. 4. Transportation, Put On Service And Use
CHAP. 4. TRANSPORTATION, PUT ON SERVICE AND USE WORKING POSITIONS AND OPERATORS TASKS As described in the instructions manual for the use, the machine is designed to be driven from an operator skilled and informed on the residual risks, but with the competencies, in safety matter, of the maintenance employees. The normal working zone of the operator is: the machine lateral zone opposed to the control panel near the basin, for the manual discharge and charge operations and food product control in work normal conditions with fixed shelters and the lateral discharge door (if any) in closet and... - Page 11 ELECTRIC FEEDING SECTIONING DEVICE The feeding sectioning device, as comparable from what described in the power circuits diagram delivered with the electric equipment, is supplied for the machine feeding unique source. In case of incompatibility between the net socket and the device plug change the socket with another type suitable from maintenance personnel.
-
Page 12: Functioning Description
ASSEMBLY / DISASSEMBLY The assembly / disassembly operations of any machine part are performed with the stop machine, with the plug disconnected from the socket and with water tap closet, or with the sectioning device in OFF and with the basin completely empty, without nor water nor food products. LATERAL DISCHARGE COLLECTOR ASSEMBLY In the case that the machine is equipped with inferior fall water discharge of the dross drawer, the water and dross discharge can be foreseen through the lateral fall discharge collector. - Page 13 SWITCHING ON / SWITCHING OFF The impulse switching on and switching off of the controls panel and the display is possible only with a voluntary action on the control device foreseen with this aim: button white or black “ ”. FUNCTIONING TIME Before the machine starting the functioning time setting is possible only with a voluntary action on the control device foreseen with this aim: button white “...
- Page 14 VERIFICATION / CONTROL MODALITY AND CHECKS Check the functionality: All devices must perform the function for which have been foreseen. Control of the control system parts / safety control; directly the devices so that these ones determine the waiting function. Of the control devices.
-
Page 15: Chap. 5. Maintenance, Breaks Research And Cleaning
CHAP. 5. MAINTENANCE, BREAKS RESEARCH AND CLEANING MAINTENANCE MAN REQUIREMENTS With the term “maintenance” must not be understood only the periodical check of the machine normal functioning but also the analysis and the consequent remedy of all causes that for any matter put it out of service. It is absolutely necessary that for the maintenance, cleaning, parts change and breaks research activities performed from the user, this work is entrusted to skilled personnel, competence and authorized from the employer. -
Page 16: Extraordinary Maintenance
TYPE POTENTIAL CAUSE/S MODALITY AND COMPARISONS Drinking water flexible pipe unions not Switch off the machine, insulate it from the external feeding sources and screwed correctly to the tap or to the tighten the pipe unions to the relative male joints. In the case the pipe union machine thread is stripped or the gaskets are absent, contact directly the Authorized Presence of... -
Page 17: Chap. 6. Selling
FREQUENCY PERSONNEL MODALITY PRODUCTS NOT TO USE: Compressed air with jets towards the machine; A high pressure cleaner or a continue water jet; Vapor equipment or water jets in pressure; Detergent that contains CHLORINE (also if diluted) or its compounds as: the bleach, the muriatic acid, products to clear the drain, products for the marble cleaning, in general decalcifying, etc …...
