- Page 1 O P E R A T O R ' S M A N U A L WOOD CHIPPER WC1208 5PQ990126 (05/01/11)
- Page 2 To the Owner; Thank-You for choosing a quality product from Frontier Equipment. We strive to give you the best equipment and the best level of service of any company. With a little care and maintenance this machine will do your work for you for many years.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction ……………………………………………………………… 2 Intended Use ………………………………………………… 2 Serial Number …………………………………………….… 2 Specifications ………………………………………………… 2 Safety …………………………………………………………………….… 3 Safety Decals ………………………………………………… 4 Inspection and Set-up ………………………………………………… 5 Operation …………………………………………………………………… 6 Startup ………………………………………………………… 6 Chipping Tips ………………………………………………… 6 Chip Chute Adjustments …………………………………… 7 Deflector ………………………………………………………... -
Page 4: Introduction
Frontier Chippers are designed to chip natural, untreated wood only. Materials that are processed may contain chemicals or by-products that could corrode the machine, damage the blades, or spon- taneously combust. Frontier Equipment will not cover under warranty any chipper that has been used for anything besides natural wood. - Page 5 SAFETY Do not operate this machine until this manual has been read and fully understood; serious injury or death can occur if these safety warnings are ignored! Never allow more than one person to operate this machine at a time. If two people are work- ing together it will increase the chance of your workmate engaging the machine or causing you to fall into the machine.
-
Page 6: Safety Decals
SAFETY Safety Decals Warning decals are provided to insure safe and proper use of the machine and should be heeded at all times. If at any time there are damaged and/or faded decals, contact your dealer for replacements immediately. Below is an illustration of each decal. 903100 903101... - Page 7 INSPECTION AND SET-UP • Follow the instructions in the lubrication section of this manual to make sure the chipper is greased properly. The initial grease is applied at the factory, but a routine maintenance schedule is the user’s responsibility. • Check all bolts and nuts to make sure everything is tight.
-
Page 8: Operation
OPERATION Startup • Place tractor transmission in neutral and set the parking brake, then turn the tractor engine off. • Connect the 3 pt. hitch linkages to the chipper and secure them with safety snap pins. • Adjust the top link so that the chipper sits level. •... -
Page 9: Chip Chute Adjustments
OPERATION Chip chute adjustments To position the chip chute, loosen the set bolt (Figure 3) and rotate the chute to the desired position, then retighten the set bolt. The chute conveniently rotates a full 360 degrees. Be sure the set bolt is tight and the chute is locked in place before transporting the chipper! Deflector The chip deflector easily adjusts to regulate the distance that the chips are thrown. -
Page 10: Feeding Material
OPERATION Feeding Material The flow control valve (Figure 5) will control the speed of the material being fed into the chipper, The tractor’s hydraulic pressure will also contribute to the speed of the feed. To adjust the speed of the feed system, find a small branch and feed it into the chipper with the feed adjusted to 3 or 4 and keep adjusting up until the chips are 3/8 to 1/2 inch (9-12mm) thick. - Page 11 OPERATION Feeding Material, Cont’d The optional tachometer(Figure 7) and shut off swith will stop the feed roller if the chipper rotor RPM drops below the specified low speed setting. This feature keeps the tractor from stalling and elimi- nates undue stress on the drive system when the torque requirement is too high. The feed roller will restart automatically after the tractor recovers to the specified high speed setting.
-
Page 12: Belt Tension
Be sure to adjust the turnbuckles the same amount on both sides. The belts should be snug but not stretched too tightly. Replacing the belts Follow these steps to replace the drive belt (Figure 10). The WC1208 chipper uses a 5-section banded B-78 belt. •... -
Page 13: Knives
MAINTENANCE & SERVICE Knives The performance of the chipper will depend largely on the condition of the knives. If the knives are dull or damaged you will create a lot of unnecessary stress on the machine and consumes more power from the tractor. The knives are reversible and can easily be reversed or replaced by remov- ing the four bolts. -
Page 14: Bearings
LUBRICATION Bearings The WC1208 chipper has six bearings. Figure 13 shows the bearings on the output shaft going to the large pulley. Figure 14 shows the feed roller bearing. There is one on each side of the feed roller carriage. The shield may need to be removed to access this bearing. All sealed bear- ings should be greased lightly every 20 hours of use. -
Page 15: Feed Roller Slide
LUBRICATION There are two grease fittings on the gearbox stand where it pivots on the base assembly (Figure 17). These fittings should be greased heavily every 10 hrs of operation and should always be wet with grease. Figure 11 Feed Roller Slide The feed roller slide should always be wet with grease. - Page 16 WARRANTY Warranty coverage is provided by John Deere according to the terms of the Agricultural/Commercial & Consumer Equipment Warranty Statement. Carefully read the warranty statement on the back of your original purchase order for details on coverage and limitations of this warranty.
-
Page 17: Notes
NOTES... -
Page 18: Illustrated Parts Breakdown
Illustrated Parts Breakdowns... -
Page 19: Base Assembly Parts
WC1208 Base Assembly 14 15 Ref# Description Part# Ref# Description Part# Complete Gearbox 5PQ903000 Lock Washer, 5/8 5PQ000860 Drive Shaft 5PQ903428 Flat Washer, 5/8 5PQ001075 Nut, 9/16 5PQ000965 Spacer 5PQ903435 Lock Washer, 9/16 5PQ000850 Bolt, 5/8 x 4-1/2 5PQ000645 SAE Flat Washer, 9/16... -
Page 20: Drum Housing
WC1208 Drum Housing 16 17 Ref# Description Part# Bolt, 1/2 x 1-1/4 5PQ000420 Lock Washer, 1/2 5PQ000840 Flat Washer, 1/2 5PQ001055 Knife Access Cover 5PQ903451 Drum Hood Weldment 5PQ903059 Rotor Weldment 5PQ903440 Blower Paddle, Left 5PQ903031 Blower Paddle, Right 5PQ903020... -
Page 21: Feed Roller Carriage
WC1208 Feed Carriage Assembly Ref# Description Part# Lock Nut, 3/8 5PQ003000 Flat Washer, 3/8 5PQ001035 Feed Carriage Weldment 5PQ903065 Bolt, 1/4 x 6 5PQ000212 Flat Washer, 1/4 5PQ001020 Coupling Shield 5PQ903495 Lock Washer, 1/4 5PQ000805 Nut, 1/4 5PQ000900 Rubber Block... -
Page 22: Hopper Assembly
WC1208 Hopper Assembly 32 33 Ref# Description Part# Ref# Description Part# Lock Nut, 5/16 5PQ002999 Rotary Valve 5PQ291002 Flat Washer, 5/16 5PQ001030 Speed Sensor 5PQ900215 Valve Linkage Bar 5PQ902035 Bolt, 1/4 x 3/4 5PQ000175 Control Linkage 5PQ902036 Bypass Valve 5PQ830323... -
Page 23: Chute Assembly
WC1208 Chute Assembly Ref# Description Part# Set Bolt 5PQ500148 Bolt, 3/8 x 1-1/2 5PQ000280 Chip Chute 5PQ903486 Chip Deflector 5PQ903197 Bolt, 3/8 x 7/8 5PQ000250 Flat Washer, 3/8 5PQ001035 Locknut, 3/8 5PQ003000 Clamp Handle 5PQ806039 Locknut, 3/8 5PQ003000 10 Chute Retainer... -
Page 24: Decals & Labels
WC1205 Decals and Labels 903101 903100 Ref# Description Part# Decal, Frontier Equipment 5PQ903110 Decal, WC1208 5PQ903118 Warning, do not ride 5PQ903104 Warning, crush/pinch hazard 5PQ903105 Warning, thrown objects 5PQ903106 Warning, do not place hands 5PQ903100 Warning, hydraulic pressure 5PQ903114 SMV Decal...
