Broadata Communications LINK BRIDGE LB-H2-HDV-SCL User Manual

Hdmi 2.0 scaler with hdmi/displayport/vga input
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
LB-H2-HDV-SCL
TM
L
B
HDMI 2.0
INK
RIDGE
S
CALER WITH
HDMI/D
P
/VGA I
ISPLAY
ORT
NPUT
BCI reserves the right to make changes to the products described herein without
prior notice or consent. No liability is assumed as a result of their use or
application. All rights reserved.
©2017 Broadata Communications, Inc.

Advertisement

Table of Contents
loading

Related Manuals for Broadata Communications LINK BRIDGE LB-H2-HDV-SCL

Summary of Contents for Broadata Communications LINK BRIDGE LB-H2-HDV-SCL

  • Page 1 /VGA I ISPLAY NPUT BCI reserves the right to make changes to the products described herein without prior notice or consent. No liability is assumed as a result of their use or application. All rights reserved. ©2017 Broadata Communications, Inc.
  • Page 2 LB-H2-HDV-SCL User Manual Link Bridge HDMI 2.0 Scaler w/HDMI/DisplayPort/VGA Input SAFETY INSTRUCTIONS AND COMPLIANCE DECLARATIONS PLEASE OBSERVE THE FOLLOWING SAFETY PRECAUTIONS AS OUR PRODUCTS CONTAIN SURGE PROTECTION DEVICE RECOMMENDED This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lightning strikes, etc. Use of surge protection systems is highly recommended in order to protect and extend the life of your equipment.

  • Page 3: Table Of Contents

    LB-H2-HDV-SCL User Manual Link Bridge HDMI 2.0 Scaler w/HDMI/DisplayPort/VGA Input TABLE OF CONTENTS 1.0 PRODUCT DESCRIPTION ..........5 2.0 OPERATION CONTROL AND FUNCTIONS ....6 2.1 FRONT PANEL ..............6 2.2 REAR PANEL ..............8 2.3 REMOTE CONTROL ............9 3.0 WEBGUI ................. 10 3.1 WEBGUI CONTROL PAGE ...........

  • Page 4: Product Description

    LB-H2-HDV-SCL User Manual Link Bridge HDMI 2.0 Scaler w/HDMI/DisplayPort/VGA Input 1.0 PRODUCT DESCRIPTION Features · A Multi-format HDMI 2.0 Scaler with HDCP 2.2 compliance · Supports HDMI and DisplayPort video resolutions up to 3840×2160@60Hz & 4096×2160@60Hz with 4:4:4 YUV · Auto source detection: automatically select and display the most recently connected source ·...

  • Page 5: Operation Control And Functions

    LB-H2-HDV-SCL User Manual Link Bridge HDMI 2.0 Scaler w/HDMI/DisplayPort/VGA Input OPERATION CONTROLS AND FUNCTIONS 2.1 Front Panel POWER MENU ENTER SOURCE HDMI 10 11 POWER: Press this button to power on the unit or place it into stand-by mode. POWER LED: a.
  • Page 6 LB-H2-HDV-SCL User Manual Link Bridge HDMI 2.0 Scaler w/HDMI/DisplayPort/VGA Input The following hotkey functions are also available: Auto Adjust (only for VGA IN function): Press the ENTER button when the OSD menu is not active and the input source is VGA to execute the auto adjust function.

  • Page 7: Rear Panel

    LB-H2-HDV-SCL User Manual Link Bridge HDMI 2.0 Scaler w/HDMI/DisplayPort/VGA Input 2.2 Rear Panel AUDIO AUDIO HDMI OUT DP IN HDMI IN VGA IN SERVICE CONTROL RS-232 DC 5V HDMI OUT: Connect to HDMI TVs, monitors or amplifiers for digital video and audio output. AUDIO OUT: Connect to powered speakers or an amplifier for stereo analog audio output.

  • Page 8: Remote Control

    LB-H2-HDV-SCL User Manual Link Bridge HDMI 2.0 Scaler w/HDMI/DisplayPort/VGA Input 2.3 Remote Control 720P INFO VGA IN HDMI IN DP IN MENU ENTER MUTE VOL - VOL + 1. POWER: Press to power on the unit or place it into stand- by mode.

  • Page 9: Webgui

    LB-H2-HDV-SCL User Manual Link Bridge HDMI 2.0 Scaler w/HDMI/DisplayPort/VGA Input WEBGUI Install the IP Discovery Tool: (1) Please obtain the Device Discovery software from your authorized dealer and save it in a directory where you can easily find it. (2) Connect the unit and your PC/Laptop to the same active network and execute the Device Discovery software.

  • Page 10: Webgui Control Page

    LB-H2-HDV-SCL User Manual Link Bridge HDMI 2.0 Scaler w/HDMI/DisplayPort/VGA Input (4) Once you are satisfied with the network settings, reboot unit, then you may use them to connect via Telnet or WebGUI. The network information window provides a convenient link to launch the WebGUI directly.

  • Page 11: Power On/Off

    LB-H2-HDV-SCL User Manual Link Bridge HDMI 2.0 Scaler w/HDMI/DisplayPort/VGA Input 3.2 Power On/Off The unit can be powered on or off (placed into stand-by mode) from this tab. 3.3 UHD 4K Bypass The UHD 4K bypass input is able to be selected bypass or down scale.
  • Page 12 LB-H2-HDV-SCL User Manual Link Bridge HDMI 2.0 Scaler w/HDMI/DisplayPort/VGA Input 3.4 Input Source Selection and Auto Source Detection (a) Source: The input source can be selected here. Four input source options are available: HDMI, DisplayPort, VGA and Default (HDMI is the normal default input. This can be changed via the WebGUI, RS-232 or telnet).

  • Page 13: Edid And Hdcp Settings

    LB-H2-HDV-SCL User Manual Link Bridge HDMI 2.0 Scaler w/HDMI/DisplayPort/VGA Input 3.5 EDID & HDCP Settings (a) EDID: Four EDID options are available: Internal 4K2K, Internal 1080p, External TV (EDID is copied from the connected display device) and External TV+2ch (EDID is copied from the connected display device but the audio is set to LPCM 2.0).

  • Page 14: Display Settings

    LB-H2-HDV-SCL User Manual Link Bridge HDMI 2.0 Scaler w/HDMI/DisplayPort/VGA Input 3.7 Display Settings The output timing, aspect ratio, and other video processing functions can be configured in this tab. (a) Output: The preferred output timing can be selected here. Selecting NATIVE will use the native timing reported by the EDID of the connected display device.

  • Page 15: Osd Settings

    LB-H2-HDV-SCL User Manual Link Bridge HDMI 2.0 Scaler w/HDMI/DisplayPort/VGA Input (c) Contrast, Brightness, Saturation, Hue and Sharpness: These settings control the image quality of the output. Each setting can be adjusted from 0 to 100 based on user preference. 3.8 OSD Settings This tab allows for the control and adjustment of all available OSD (On Screen Display) settings.

  • Page 16: Ethernet Settings

    LB-H2-HDV-SCL User Manual Link Bridge HDMI 2.0 Scaler w/HDMI/DisplayPort/VGA Input 3.9 Ethernet Settings The unit’s Ethernet settings are configured in this tab. The IP connection timeout can be set to a time between 10 and 60 minutes, or it can be disabled (OFF). The IP address can be configured by your network automatically (DHCP) or the unit’s IP settings can be manually configured (STATIC).

  • Page 17: Reset Options

    LB-H2-HDV-SCL User Manual Link Bridge HDMI 2.0 Scaler w/HDMI/DisplayPort/VGA Input 3.11 Reset Options This tab provides options for returning the Display, Audio, OSD and Ethernet settings to their individual factory defaults. It also allows you to perform a system-wide Factory Reset (returns all settings to the factory defaults).

  • Page 18: Telnet/Rs-232 Control

    LB-H2-HDV-SCL User Manual Link Bridge HDMI 2.0 Scaler w/HDMI/DisplayPort/VGA Input TELNET/RS-232 CONTROL Before attempting to use telnet control, please ensure that both the unit and the PC/Laptop are connected to the same active networks. To access Telnet in Windows 7, click on the “Start” menu and type “cmd”...
  • Page 19 LB-H2-HDV-SCL User Manual Link Bridge HDMI 2.0 Scaler w/HDMI/DisplayPort/VGA Input This will connect us to the unit we wish to control. Type “help” or “?” to list the available commands. Note: Commands will not be executed unless followed by a carriage return.

  • Page 20: Command List

    LB-H2-HDV-SCL User Manual Link Bridge HDMI 2.0 Scaler w/HDMI/DisplayPort/VGA Input 4.1 Command List On a PC/Laptop that is connected to an active network system, open a web browser and type device’s IP address on the web address entry bar. A security page will appear to ask for User and Password, please key in “Admin”...
  • Page 21 LB-H2-HDV-SCL User Manual Link Bridge HDMI 2.0 Scaler w/HDMI/DisplayPort/VGA Input Broadata Technical Support, (800) 214-0222...
  • Page 22 LB-H2-HDV-SCL User Manual Link Bridge HDMI 2.0 Scaler w/HDMI/DisplayPort/VGA Input Broadata Technical Support, Sales@Broadatacom.com...
  • Page 23 LB-H2-HDV-SCL User Manual Link Bridge HDMI 2.0 Scaler w/HDMI/DisplayPort/VGA Input Broadata Technical Support, (800) 214-0222...
  • Page 24 LB-H2-HDV-SCL User Manual Link Bridge HDMI 2.0 Scaler w/HDMI/DisplayPort/VGA Input Broadata Technical Support, Sales@Broadatacom.com...
  • Page 25 LB-H2-HDV-SCL User Manual Link Bridge HDMI 2.0 Scaler w/HDMI/DisplayPort/VGA Input Broadata Technical Support, (800) 214-0222...
  • Page 26 LB-H2-HDV-SCL User Manual Link Bridge HDMI 2.0 Scaler w/HDMI/DisplayPort/VGA Input Broadata Technical Support, Sales@Broadatacom.com...
  • Page 27 LB-H2-HDV-SCL User Manual Link Bridge HDMI 2.0 Scaler w/HDMI/DisplayPort/VGA Input 4.2 OSD (On Screen Display) Menu Broadata Technical Support, (800) 214-0222...
  • Page 28 LB-H2-HDV-SCL User Manual Link Bridge HDMI 2.0 Scaler w/HDMI/DisplayPort/VGA Input ADJUSTABLE PARAMETERS AND Broadata Technical Support, Sales@Broadatacom.com...
  • Page 29 LB-H2-HDV-SCL User Manual Link Bridge HDMI 2.0 Scaler w/HDMI/DisplayPort/VGA Input ADJUSTABLE PARAMETERS AND Broadata Technical Support, (800) 214-0222...
  • Page 30 LB-H2-HDV-SCL User Manual Link Bridge HDMI 2.0 Scaler w/HDMI/DisplayPort/VGA Input ADJUSTABLE PARAMETERS AND Broadata Technical Support, Sales@Broadatacom.com...
  • Page 31 LB-H2-HDV-SCL User Manual Link Bridge HDMI 2.0 Scaler w/HDMI/DisplayPort/VGA Input ADJUSTABLE PARAMETERS AND Note: In the following scenarios deep color will be kept from the input source. Input timing: 3840X2160P/23 & output timing: 3840X2160P/23 Input timing: 3840X2160P/24 & output timing: 3840X2160P/24 Input timing: 3840X2160P/25 &...

  • Page 32: Supported Timing Table

    LB-H2-HDV-SCL User Manual Link Bridge HDMI 2.0 Scaler w/HDMI/DisplayPort/VGA Input 5.0 SUPPORTED TIMING TABLE Broadata Technical Support, Sales@Broadatacom.com...

  • Page 33: Maxiumu Hdmi Cable Length

    LB-H2-HDV-SCL User Manual Link Bridge HDMI 2.0 Scaler w/HDMI/DisplayPort/VGA Input 6.0 MAXIMUM HDMI CABLE LENGTH Broadata Technical Support, (800) 214-0222...

  • Page 34: Specifications

    LB-H2-HDV-SCL User Manual Link Bridge HDMI 2.0 Scaler w/HDMI/DisplayPort/VGA Input 7.0 SPECIFICATIONS SCALER Input One (1) HDMI portOne (1) DisplayPortOne (1) VGA port (HD-15)One (1) Analog Audio port (3.5mm jack) Output One (1) HDMI portOne (1) Analog Audio port (3.5mm jack) Control RS-232, 3.5mm jackLAN, RJ-45 Service...

  • Page 35: Service Procedure

    U.S. Please call Customer Service at 800-214-0222 for information. 8.2 Return/Repair Service The Link Bridge LB-H2-HDV-SCL System contains no user serviceable components. If you have a problem with your unit, please contact the Customer Service Department. To facilitate our return/repair processing please contact Broadata Communications, Inc.

  • Page 36: Limited Warranty

    HDMI 2.0 Scaler w/HDMI/DisplayPort/VGA Input 9.0 LIMITED WARRANTY Broadata Communications, Inc. (BCI) warrants, for a period of one year from date of shipment, each product sold shall be free from defects in material and workmanship. BCI will correct, either by repair, or at BCI’s...
  • Page 37 LB-H2-HDV-SCL User Manual Link Bridge HDMI 2.0 Scaler w/HDMI/DisplayPort/VGA Input Broadata Technical Support, (800) 214-0222...
  • Page 38 LB-H2-HDV-SCL User Manual Link Bridge HDMI 2.0 Scaler w/HDMI/DisplayPort/VGA Input Broadata Technical Support, Sales@Broadatacom.com...
  • Page 39 Broadata Communications, Inc. 2545 West 237th Street, Suite K Torrance, CA 90505 1-800-214-0222 (310) 530-1416 (310) 530-5958 (Facsimile) e-mail: CustomerService@Broadatacom.com Website: www.broadatacom.com 60000-LBH2HDVSCL...
