- Page 1 User Manual Operator Level Controller APM303 Soft version : 2.0.0 33508000401_2_1 26/02/2016 CALL US TODAY REQUEST A QUOTE SHOP ONLINE 1-888-POWER-58 parts@genpowerusa.com www.genpowerusa.com...
- Page 2 The "user level" user manual is designed for users who are qualified to set up an installation (generating set and environment). These users must be able to monitor that the generating set is operating correctly (start, stop, basic settings), to interpret any indications (mechanical, electrical) and may be required to check one or more parameters. The "operator level" user manual is designed for those who – in addition to the skills required for users ...
-
Page 3: Table Of Contents
Identification of the modules .............................. 4 APM303 module ................................4 CAN display module ..............................4 Powering up the APM303 and associated configurations ....................4 Single generator ................................4 Generating set with Automatic Transfer Switch ......................4 General description of the APM303 module ........................5 Selecting the operating mode ............................. - Page 4 List of figures Figure 1 - integration of the APM303 .............................. 3 Figure 2 - front panel of the APM303 .............................. 5 Figure 3 - viewing data ................................... 7 Figure 4 - main ....................................7 Figure 5 - current and voltage ................................. 7 Figure 6 - outputs ....................................
-
Page 5: Preface
To do this, the operator will have completed training provided by SDMO Industries beforehand. Note: for the APM303, no distinction is made between the user and the operator. This means that a user can modify all the internal parameters (no access code in the APM303). -
Page 6: Identification Of The Modules
0/1 switch, located on the front of the central console. On powering up, the APM303 automatically runs in the operating mode which was pre-set before it was switched on (see section ‘Selecting the operating mode’). -
Page 7: General Description Of The Apm303 Module
When MANU mode is selected ( AUTO LED off), if there is a remote start order (activation of the "remote start/stop" input, nothing happens, the APM303 remains in MANU mode, but the AUTO LED flashes to signal that there is a remote order. -
Page 8: Auto Mode
This input must be a potential-free contact ( ), this means that the user must not connect an external power supply to the terminals provide for this purpose. This will destroy the APM303. ( ) In general, the external input comes from an automatically controlled ATS. -
Page 9: Display Of Data
Display of data To view the data measured and recorded by the APM303, the user has 6 or 7 screens available: - 7 screens are automatically displayed one after the other, with a delay of 7 seconds, - 6 screens are displayed by successively pressing the... -
Page 10: Metering, Screen 5
(e.g.: 10). Figure 8 - meters Events and anomalies, screen 6 Screen 6 shows the list of events and anomalies recorded by the APM303 . A maximum of 12 events and anomalies can be recorded (the last 4 appear on screen). -
Page 11: Events And Anomalies
Events and anomalies Events An event is either a change in APM303 status (powering up), or activation of one the 3 buttons, or any change in the PLC status (e.g. start-up). The table below lists all the events which can be recorded in the stack. -
Page 12: Alarm Chart
3 minutes. This symbol also appears if there is a charging alternator malfunction. Flat battery: if the APM303 cannot start up the generating set (because the battery voltage is too low), this alarm will be activated, but the starting sequence is not blocked. -
Page 13: Fault Chart
2 rpm, or if the voltage exceeds 10V, or if the oil pressure remains higher than 3Bar, or if the generating set is started up when no start demand has been given by the APM303. The safety feature is taken into account after fixed delay of 60 seconds. -
Page 14: Settings
(see user/operator level manual - configuration software). Accessing settings (Main menu) The settings can only be accessed if the APM303 is in Manual mode. Access to the settings varies according to whether or not the home screen is displayed. -
Page 15: Basic Settings Screen
) in percentage of nominal I (parameter B09) ) in percentage of nominal P (parameter B12) This document is the property of SDMO Industries. Any communication, reproduction, publication, even partial, is forbidden, except with the written authorisation of the owner. -
Page 16: Modbus Communication Screen
"normally closed contact" type action Confirm the output action type, by pressing the button. This document is the property of SDMO Industries. Any communication, reproduction, publication, even partial, is forbidden, except with the written authorisation of the owner. CALL US TODAY... -
Page 17: Confirming The Output
"normally closed contact" type action Confirm the input action type, by pressing the button. This document is the property of SDMO Industries. Any communication, reproduction, publication, even partial, is forbidden, except with the written authorisation of the owner. CALL US TODAY... -
Page 18: Confirming The Input
Return to section ‘Selecting an input’ to select a new input. 8.10 Miscellaneous information screen This screen displays general information about the generating set and the APM303 module. This screen corresponds to screen 0 described in section ‘INIT, screen 0’. 8.11 Setting principle in other screens... -
Page 19: Connections
Figure 21 - two phase 2P+N (3 wires) Figure 22 - single phase 1P+N (2 wires) This document is the property of SDMO Industries. Any communication, reproduction, publication, even partial, is forbidden, except with the written authorisation of the owner. -
Page 20: 10 Technical Specifications
1 input/output, 3 terminals ( A , COM , B ) RS485 type (on 3-pin connector) . on the module This document is the property of SDMO Industries. Any communication, reproduction, publication, even partial, is forbidden, except with the written authorisation of the owner. CALL US TODAY REQUEST A QUOTE... -
Page 21: 11 Packaging, Storage And Handling Of The Modules
11.2 Storage The storage conditions described below must be strictly adhered to, otherwise there is a risk that the product warranty will be completely voided by SDMO and/or by the manufacturer of the products. Store in a location free from dust. -
Page 22: Call Us Today 1-888-Power
……………………………………………………………………………………………… ……………………………………………………………………………………………… ……………………………………………………………………………………………… ……………………………………………………………………………………………… ……………………………………………………………………………………………… ……………………………………………………………………………………… This document is the property of SDMO Industries. Any communication, reproduction, publication, even partial, is forbidden, except with the written authorisation of the owner. CALL US TODAY REQUEST A QUOTE SHOP ONLINE 1-888-POWER-58 parts@genpowerusa.com...
Need help?
Do you have a question about the APM303 and is the answer not in the manual?
Questions and answers
有220KW发电机想接成自动启、停控制，求完整的电气控制原理图。
The complete electrical control schematic for automatic start and stop of the SDMO APM303 generator includes:
1. Generating Set – The main generator unit.
2. APM303 Control Module – Manages generator operations.
3. CAN Display – Optional, depending on motor type.
4. Manually Controlled Circuit Breaker – Connects or disconnects the load.
5. Automatic Transfer Switch (ATS) – Automatically switches between the generator and the electrical network.
6. Electrical Network – Main utility power supply.
7. 2-Wire Remote Start Connection – Between the ATS and the generator for sending automatic start/stop signals.
8. Voltage Measurement via K6 Connector – Terminals 20 (N), 21 (L1), 22 (L2), 23 (L3) for 3-phase connection.
9. AUTO Mode on APM303 – Enables automatic control based on remote start signals; press AUTO button to activate.
In AUTO mode, the APM303 automatically starts and stops the generator based on mains power availability detected by the ATS. The ATS monitors the mains and sends start/stop signals through the 2-wire connection.
This answer is automatically generated
