Your miter saw utility vehicle has been engineered and manufactured to our high standard for dependability, ease of operation,
and operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING:
To reduce the risk of injury, the user must read and understand the operator's manual before using this product.
Thank you for buying a RIDGID product.
SAVE THIS MANUAL FOR FUTURE REFERENCE
OPERATOR'S MANUAL
MITER SAW UTILITY VEHICLE
AC9944
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AC9944 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for RIDGID AC9944

  • Page 1 Your miter saw utility vehicle has been engineered and manufactured to our high standard for dependability, ease of operation, and operator safety. When properly cared for, it will give you years of rugged, trouble-free performance. WARNING: To reduce the risk of injury, the user must read and understand the operator’s manual before using this product.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS  Introduction ... 2  Rules for Safe Operation ... 3  Symbols ... 4  Features ... 5  Tools Needed ... 5  Loose Parts ... 6  Assembly ...7-13  Operation ...14-15  Maintenance ...16-17 ...
  • Page 3: Rules For Safe Operation

    RULES FOR SAFE OPERATION Safe operation of this accessory requires that you read and understand this operator’s manual, the operator’s manual for the miter saw, and all labels affixed to the tool. READ ALL INSTRUCTIONS  KNOW YOUR ACCESSORY. Read the operator’s manual carefully.
  • Page 4: Symbols

    SYMBOLS Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. SYMBOL NAME Wet Conditions Alert Read The Operator’s Manual Eye Protection Safety Alert The following signal words and meanings are intended to explain the levels of risk associated with this...
  • Page 5: Features

    FEATURES QUICK RELEASE SAW MOUNTING EXTENSION TRANSPORT SUPPORT TOOLS NEEDED The following tools (not included) are needed for assembly: ADJUSTABLE WRENCH(S) WORK STOP WORK SUPPORT BRACKET BRACKETS HANDLE WORK SUPPORT LIFT ASSIST HANDLE SUPPORT Fig. 1 SCREWDRIVER Fig. 2...
  • Page 6: Loose Parts

    LOOSE PARTS The following items are included with your miter saw workstand:  Workstand Assembly  Quick Release Saw Mounting Brackets (2)  Work Supports (2)  Work Support Brackets (2)  Adjustment Knobs (4)  End Caps (2)  Wheels (2) ...
  • Page 7: Assembly

    ASSEMBLY UNPACKING This product requires assembly.  Carefully remove the product and any accessories from the box. Make sure that all items listed in the packing list are included.  Inspect the product carefully to make sure no breakage or damage occurred during shipping. ...
  • Page 8 ASSEMBLY SECURING THE LIFT ASSIST HANDLE See Figures 5 - 6.  Insert hex bolt into hole on each side of handle but do not insert through stand table.  Insert plastic washer between handle and stand table onto the bolt. Push bolt through the hole in the stand table. ...
  • Page 9: Attaching The Wheels

    ASSEMBLY ATTACHING THE TRANSPORT HANDLE See Figure 8.  Align transport handle ends with holes in stand table end caps and insert.  Place a spring washer over the screw and insert screw through each hole of the handle and leg support bracket.
  • Page 10  After making sure both brackets are parallel to each other, lightly tighten all four nuts to hold in position. If the saw has holes that do not line up with the sliding adjustment plates in the saw mounting brackets:...
  • Page 11  Check position and adjust, if necessary, to make sure the weight of the saw is evenly balanced over the edges.  Ensure the saw is fully seated and locked in position, then securely tighten the four nuts holding the saw to the saw mounting brackets.
  • Page 12 CAUTION: Do not lift by any part of the miter saw that is attached to the workstand. Failure to heed this warning may result in possible injury and damage the tool.
  • Page 13: Assembly

    See Figures 15 - 17. NOTE: The workstand is heavy. Get help when needed.  If a miter saw is assembled on the stand, make sure to place the blade 90° to the table (if applicable), miter the blade to the right as far as it will go, place the blade in the “locked down”...
  • Page 14: Operation

    OPERATION WARNING: Do not allow familiarity with products to make you careless. Remember that a careless fraction of a second is sufficient to inflict severe injury. WARNING: Always wear safety goggles or safety glasses with side shields when operating products. Failure to do so could result in objects being thrown into your eyes resulting in possible serious injury.
  • Page 15: Operation

    OPERATION USING THE WORK SUPPORT See Figure 20. Rest the workpiece on top of the work support to support the workpiece during cutting operations. NOTE: More than one work support can be used on an extension arm at a time when extra support is necessary. Always lower extension arm support legs when using work supports.
  • Page 16: Maintenance

    MAINTENANCE WARNING: When servicing use only identical RIDGID replacement parts. Use of any other parts may create a hazard or cause product damage. WARNING: Always wear safety goggles or safety glasses with side shields during power tool operation or when blowing dust.
  • Page 17  When the correct position is achieved, wrench-tighten the nut to secure.  Repeat with the second mounting bracket. To purchase additional saw mounting bracket assemblies (part no. 900510802), call RIDGID customer service at 1-866-539-1710. MOUNTING BRACKET BRACKET...
  • Page 18 NOTES...
  • Page 19: Warranty

    Tools covers all defects in workmanship or materials and normal wear items such as brushes, chucks, motors, switch- es, cords, gears and even cordless batteries in this RIDGID tool for three years following the purchase date of the tool. Warranties for other RIDGID products may vary.
  • Page 20: Customer Service Information

    AC9944 Customer Service Information: For parts or service, contact your nearest RIDGID authorized service center. Be sure to provide all relevant information when you call or visit. For the location of the authorized service center nearest you, please call 1-866-539-1710 or visit us online at www.ridgid.com.
