  • Page 1 NA130 series Network Appliance User’s Manual A1...
  • Page 2 AXIOMTEK does not make any commitment to update the information in this manual. AXIOMTEK reserves the right to change or revise this document and/or product at any time without notice. No part of this document may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of AXIOMTEK Co., Ltd.
  • Page 3 Safety Approvals  CE Marking  FCC Class B  FCC Compliance This equipment has been tested and complies with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 4: Safety Precautions

     When handling boards and components, wear a wrist-grounding strap, available from most electronic component stores. Trademarks Acknowledgments AXIOMTEK is a trademark of AXIOMTEK Co., Ltd. IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation. ® ®...

  • Page 5: Table Of Contents

    Table of Contents Safety Approvals ..................... iii Safety Precautions ....................iv SECTION 1 INTRODUCTION ..................1 General Description ................1 Features ....................1 Specifications ..................2 1.3.1 System ......................... 2 1.3.2 Mechanical / Environmental ................3 Dimensions and Outlines ..............4 I/O Outlets .....................
  • Page 6 APPENDIX A LAN BYPASS CONFIGURATION ..........61 About LAN Bypass .................... 61 LAN Bypass Register Configuration ..............62 APPENDIX B WDT TIMER FOR SYSTEM RESET ..........67 WDT (Watchdog Timer) ..................67 APPENDIX C WARNING ..................69...

  • Page 7: Section 1 Introduction

    This platform can be easily enabled through application programs to make a user-friendly appliance for customers, and provide the cost effective platform of encryption and decryption. Features Low power and high performance for network security field applications. NA130 series supports AMD G-Series LX processor .  AMD G-Series LX processor ...

  • Page 8: Specifications

    NA130 Series Network Appliance User’s Manual Specifications 1.3.1 System   NA130: AMD G-Series LX processor (GX-210KL as default)  BIOS  AMI 32Mbit SPI Flash BIOS with function of BIOS redirected to COM port  Memory  One DDR3L-1600 SO-DIMM , up to 8GB memory ...

  • Page 9: 1.3.2 Mechanical / Environmental

    NA130 Series Network Appliance User’s Manual 1.3.2 Mechanical / Environmental  Form Factor  NA130: 1U desktop   Power, HDD, Link/Act with transfer rate  LAN Bypass and GPIO programmable  Operating Temperature  NA130: 0°C ~ 40°C (32°F ~ 104°F) ...

  • Page 10: Dimensions And Outlines

    NA130 Series Network Appliance User’s Manual Dimensions and Outlines Mechanical dimensions of NA130 Unit: mm Figure 1.4 mechanical dimension Introduction...

  • Page 11: I/O Outlets

    NA130 Series Network Appliance User’s Manual I/O Outlets Locate the rear panel I/O outlets on the NA130 Series server to connect serial and Ethernet interface devices. 1.5.1 Front Panel Figure 1.5.1 front panel LAN Bypass LED Power LED LAN Link LED...

  • Page 12: 1.5.2 Rear Panel

    NA130 Series Network Appliance User’s Manual 1.5.2 Rear Panel Figure 1.5.2 rear panel Default switch Power switch USB 3.0/2.0 HDMI DC jack LAN Ports Console Reset  Reset It is for reset the system to reboot your computer instead of turning off the power switch.
  • Page 13 NA130 Series Network Appliance User’s Manual  Link LED for LAN port #1, port#2, port#3, port#4 The double-color LED light indicates 10/100/1000Mbps transfer rate. When the amber-color LED light is radiating, it should be 1000Mbps transfer rate at this moment.
  • Page 14 NA130 Series Network Appliance User’s Manual This page is intentionally left blank. Introduction...

  • Page 15: Section 2 Hardware Description

    NA130 Series Network Appliance User’s Manual SECTION 2 HARDWARE DESCRIPTION The NA130 Series are convenient for your various hardware configurations. The Section 2 will help you get familiar with the hardware. Checklist The package bundled with your NA130 Series should contain the following items ...

  • Page 16: Board Layout

    NA130 Series Network Appliance User’s Manual Board Layout Figure 2.3 Layout Component Side Hardware Description...

  • Page 17: Jumper Settings

    NA130 Series Network Appliance User’s Manual Jumper Settings This section provides the information about jumpers and connectors of NA130 Series. Proper jumper settings configure the main board in this appliance to meet your application purpose. We are herewith listing a summary table of all jumpers and default settings for onboard devices, respectively.
  • Page 18 NA130 Series Network Appliance User’s Manual NOTE: When the system is turned on, you can select the LAN bypass function by jumper and BIOS when power on state, when enter the OS, you can select LAN Bypass function at power on/ off state by software, the detail information please refer to the appendix A.

  • Page 19: Connectors

    NA130 Series Network Appliance User’s Manual Connectors Connectors connect the board with other parts of the system. Loose or improper connection might cause problems. Make sure all connectors are properly and firmly connected. Here is a summary table shows you all connectors on the main board.

  • Page 20: Hdmi Connector (Hdmi1, Optional)

    NA130 Series Network Appliance User’s Manual 2.5.1 HDMI Connector (HDMI1, Optional) Signal Signal HDMI_DATA2+ HDMI_DATA2- HDMI_DATA1+ HDMI_DATA1- HDMI_DATA0+ HDMI_DATA0- HDMI_CLK+ HDMI_CLK- HDMI_SPC HDMI_SPD HDMI_HTPLG 2.5.2 Rear IO USB 3.0(bottom)/2.0 (upper) Port (USB1) Signal USB_PWR1 USBD0- USBD0+ GND0 SSRX0- SSRX0+ SSTX0-...

  • Page 21: Sim Card (Sim1)

    NA130 Series Network Appliance User’s Manual 2.5.3 SIM Card (SIM1) In order to work properly, the SIM card must be used together with Mini Card (CN5) which is inserted to socket SIM1. It is mainly used in 3G wireless network application.

  • Page 22: Mini Pcie Full & Half (Cn2, Cn4)

    NA130 Series Network Appliance User’s Manual 2.5.4 MINI PCIe Full & Half (CN2, CN4) The CN2 is mini PCIe half, it supports USB2.0 single only and PCIe signal for optional. The CN4 supports m-SATA and USB 2.0 interface only. Signal...

  • Page 23: Mini Pcie Full (Cn5 )

    NA130 Series Network Appliance User’s Manual 2.5.5 MINI PCIe Full (CN5 ) The CN5 is mini PCIe full size form, it supports USB2.0 single only and PCIe signal for optional with with SIM slot (SIM1). Signal Signal WAKE# +3.3VSB No use No use +1.5V...

  • Page 24: Lcm Connector (Lcm1)

    NA130 Series Network Appliance User’s Manual 2.5.6 LCM Connector (LCM1) Signal NRXD No use NTXD 2.5.7 SATA Power Connector (HDD1) Signal +12V 2.5.8 DC Power Jack (CN8) Signal +12V Hardware Description...

  • Page 25: Fan Connectors (Fan1, Fan2)

    NA130 Series Network Appliance User’s Manual 2.5.9 Fan Connectors (FAN1, FAN2) Signal +12V level Sensor Signal +12V level Sensor 2.5.10 VGA Connector (VGA1) Signal Signal CRT_DET# GREEN N.C. BLUE CRT_VCC DDC DATA HSYNC VSYNC DDC CLK N.C. Hardware Description...

  • Page 26: Front Panel (Jp7)

    NA130 Series Network Appliance User’s Manual 2.5.11 Front Panel (JP7) Signal Signal PWRLED+ EXT SPEAKER- Buzzer PWRLED- N.C. N.C. EXT SPK+ PWRSW- PWRSW+ HW RST- HW RST+ HDDLED- HDDLED+ 2.5.12 SATA Connector (SATA1, SATA2) These Serial Advanced Technology Attachment (Serial ATA or SATA) connectors are for high-speed SATA interface ports.

  • Page 27: Com1 Port (Com1)

    NA130 Series Network Appliance User’s Manual 2.5.14 COM1 Port (COM1) The COM1 Port connector is an RJ-type connector Signal Signal RTS1 DTR1 TXD1 RXD1 DSR1 CTS1 2.5.15 Digital IO (DIO1) The board is equipped with an 8-channel (4 inputs and 4 outputs) digital I/O connector that meets requirements for a system customary automation control.

  • Page 28: Lan Port (Lan1-Lan4)

    NA130 Series Network Appliance User’s Manual 2.5.16 LAN Port (LAN1-LAN4) Signal Signal MDI0+ MDI0- MDI1+ MDI1- MDI2+ MDI2- MDI3+ MDI3- Green LED+ Green LED- Amber- Amber+ 2.5.17 DC Power Switch (ATX1) Signal +12V +12V_SB 2.5.18 DC Power In (ATX2) Signal...

  • Page 29: Section 3 Ami Bios Setup Utility

    NA130 Series Network Appliance User’s Manual SECTION 3 AMI BIOS SETUP UTILITY This Section provides users with detailed description how to set up basic system configuration through the AMI Aptio setup utility. Starting To enter the setup screens, follow the steps below: Turn on the computer and press the <Del>...

  • Page 30: Main Menu

    NA130 Series Network Appliance User’s Manual Main Menu When you first enter the setup utility, you will enter the Main setup screen. You can always return to the Main setup screen by selecting the Main tab. There are two Main Setup options.

  • Page 31: Advanced Menu

    NA130 Series Network Appliance User’s Manual Advanced Menu The Advanced menu allows users to set the configuration of the CPU and other system devices. You can select any of the items in the left frame of the screen to go to the sub menus: ►...
  • Page 32 NA130 Series Network Appliance User’s Manual Trusted Computing This screen provides the function for specifying the TPM settings. Configuration Use this item to enable or disable control TPM function. NOTE: TPM function is available with sku of TPM on board .
  • Page 33 NA130 Series Network Appliance User’s Manual Pending Operation Schedule an operation for Security device . NOTE: Your computer will reboot during restart in order to change state of security device. NOTE: Clearing TPM Secured Data: When TPM State is set to [Enabled], Pending TPM Operation will appear.Set this item to [TPM Clear] to clear all data secured by TPM or...
  • Page 34 NA130 Series Network Appliance User’s Manual Node 0 Information (CPU information) CPU information . AMI BIOS Setup Utility...
  • Page 35 NA130 Series Network Appliance User’s Manual IDE Configuration You can use this screen to select options for the SATA Configuration, and change the mode of the selected option. NOTE: IDE: Integrated Drive Electronics. NA130 does not support IDE configuration. AMI BIOS Setup Utility...
  • Page 36 NA130 Series Network Appliance User’s Manual USB Configuration Select this item to set up USB related parameter. Legacy USB support Enables legacy USB support (like USB, KB/MS) ;Auto option disables legacy support if no USB device are connected; Disable option will keep USB device available only for EFI applications.
  • Page 37 NA130 Series Network Appliance User’s Manual XHCI Hand-off XHCI (eXtensible Host Controller Interface) is for USB 3.0 interface. Enable or disable XHCI controller to operate the function. NOTE: Suggest no to change this default setting. EHCI Hand-off EHCI（Enhanced Host Controller Interface）is for USB2.0 interface. Enable or disable EHCI controller to operate the function.
  • Page 38 NA130 Series Network Appliance User’s Manual USB Mass Storage Driv USB Mass Storage Driver is for USB disk support. Enable or Disable USB mass storage driver support. Port 60/64 Emulation Port 60/64 is PS/2 legacy support for USB keyboard and mice. This enable PS/2 function like keyboard lock, password setting and scan code selection.
  • Page 39 NA130 Series Network Appliance User’s Manual USB transfer time-out The time –out value for control, bulk and interrupt transfers. It is used to cease transfer if there is no response from USB device. Device reset time-out Device reset time-out is used to reset USB device if there is no response after run Start Unit...
  • Page 40 NA130 Series Network Appliance User’s Manual Device power-up delay Maximum time the device will take before it properly reports itself to the Host Controller. ‘Auto’ uses default value: for a Root port it is 100m, for a Hub port the delay is taken from Hub descriptor.
  • Page 41 NA130 Series Network Appliance User’s Manual Super IO Configuration You can use this screen to select options for the Super IO Configuration, and change the value of the selected option. A description of the selected item appears on the right side of the screen.
  • Page 42 NA130 Series Network Appliance User’s Manual Serial Port1 Address This option specifies the base I/O port address and Default setting is 2F8h. Here are the options for your selection, Disabled. AMI BIOS Setup Utility...
  • Page 43 NA130 Series Network Appliance User’s Manual HW Monitor This screen shows the Hardware Health Configuration, and a description of the selected item appears on the right side of the screen AMI BIOS Setup Utility...
  • Page 44 NA130 Series Network Appliance User’s Manual System Temperature Show you the current system temperature. CPU Temperature These read-only fields show the functions of the hardware thermal sensor by CPU thermal diode that monitors the chip blocks to ensure a stable system.
  • Page 45 NA130 Series Network Appliance User’s Manual Serial Port Console Redirection To use the external serial port as console, It is needed to enable serial port console redirection. Console Redirection Console Redirection Enable or Disable. AMI BIOS Setup Utility...
  • Page 46 NA130 Series Network Appliance User’s Manual Console Redirection Settings The settings specify how the host computer and the remote computer (which the user is using) will exchange data. Both computers should have the same or compatible settings. Terminal Type This item allows you to select the target terminal type. Configuration options: ANSI, VT100 and VT-UTF8.
  • Page 47 NA130 Series Network Appliance User’s Manual Bits per second This item allows you to setup the data transfer rate for the console port. The default value is 115200. Available options are “9600”, “19200”, “38400”, “57600” and “115200”. Data Bits This item allows you to select the data bits. The configuration options: 7 and 8.
  • Page 48 NA130 Series Network Appliance User’s Manual Parity This item allows you to select flow control for console redirection. The configuration options: None, Even, Odd, Mark and Space. AMI BIOS Setup Utility...
  • Page 49 NA130 Series Network Appliance User’s Manual Stop Bits This item allows you to select the data bits. The configuration options: 1 and 2. Flow Control This item allows you to select flow control for console redirection. The configuration options: None, Hardware and Software.
  • Page 50 NA130 Series Network Appliance User’s Manual VT-UTF8 Combo Key Support Use this item to “Enabled” or “Disabled” VT-UTF8 combination key supports for ANSI / VT100 terminals. Recorder Mode This item allows you to select the recorder mode. The configuration options: Enabled and Disabled.
  • Page 51 NA130 Series Network Appliance User’s Manual Resolution Enable or disable extended terminal resolution. Legacy OS Redirection This item allows you to select the legacy OS redirection. The configuration options: 80x24 and 80x25. AMI BIOS Setup Utility...
  • Page 52 NA130 Series Network Appliance User’s Manual Putty KeyPad This item allows you to select the putty keypad. The configuration options: VT100, LINUX, XTERMR6, SCO, ESCN and VT400. Install Legacy OS through Remote This item allows you to select the install legacy OS through remote. The configuration options: “Enabled”...
  • Page 53 NA130 Series Network Appliance User’s Manual Redirection After BIOS POST Use this item to enable or disable the function of Console Redirection, which allows you maintain a system from a remote location. The default setting is Always. AMI BIOS Setup Utility...

  • Page 54: Chipset Menu

    NA130 Series Network Appliance User’s Manual Chipset Menu The Chipset menu allows users to change the advanced chipset settings. You can select any of the items in the left frame of the screen to go to the sub menus: South Bridge South Bridge handles slow speed I/O interface.
  • Page 55 NA130 Series Network Appliance User’s Manual SB SATA Configuration Options for South Bridge SATA configuration. Select OnChip SATA type. NOTE: NA130 supports AHCI SATA type. NOTE: AHCI: Advanced Host Controller Interface. AMI BIOS Setup Utility...
  • Page 56 NA130 Series Network Appliance User’s Manual SB USB Configuration XHCI (eXtensible Host Controller Interface) is for USB 3.0 interface , Enable XHCI controller to operate USB3.0 function or Disable to operate USB2.0 function. NOTE: NA130 can support USB2.0 OR USB3.0 by configuration here.
  • Page 57 NA130 Series Network Appliance User’s Manual North Bridge North Bridge handles high speed interface. For example: RAM and PCIe. Configure related parameters in this item. North Bridge Configuration/ View information related to Socket 0. AMI BIOS Setup Utility...

  • Page 58: Boot Menu

    NA130 Series Network Appliance User’s Manual Boot Menu The Boot menu allows users to change boot options of the system. You can select any of the items in the left frame of the screen to go to the sub menus: For items marked with “”, please press <Enter>...
  • Page 59 NA130 Series Network Appliance User’s Manual Launch PXE OpROM poli This item can enable or disable boot option for legacy mass storage devices with option ROM. In LAN PXE ROM control menu, select [Legacy only] and go to LAN port selection.
  • Page 60 NA130 Series Network Appliance User’s Manual LAN Bypass Model Configuration LBP@power on Use LBP @Power On item to configure Power On LAN Bypass to “Disabled” ,“Enabled” or “ Last State” for LAN Bypass. LBP@power off Power off LAN Bypass setting, use LBP @Power Off item to “Disabled” ,“Enabled” or “ Last State”...

  • Page 61: Security Menu

    NA130 Series Network Appliance User’s Manual Security Menu The Security menu allows users to change the security settings for the system. Administrator Password This item indicates whether an administrator password has been set (installed or uninstalled). User Password This item indicates whether a user password has been set (installed or uninstalled).

  • Page 62: Save & Exit Menu

    NA130 Series Network Appliance User’s Manual Save & Exit Menu The Exit menu allows users to load your system configuration with optimal or failsafe default values. Save Changes and Exit When you have completed the system configuration changes, select this option to leave Setup and reboot the computer so the new system configuration parameters can take effect.
  • Page 63 NA130 Series Network Appliance User’s Manual Save Changes and Reset Reset the system after saving the changes. Discard Change and Reset Reset system setup without saving any changes. AMI BIOS Setup Utility...
  • Page 64 NA130 Series Network Appliance User’s Manual Save Change Save Change done so far to any of the setup options. Discard Changes Use this item to abandon all changes. AMI BIOS Setup Utility...
  • Page 65 NA130 Series Network Appliance User’s Manual Restore Defaults Restore/Load default value for all the setup options. Save as User Defaults Save the changes done so far as User Defaults. AMI BIOS Setup Utility...
  • Page 66 NA130 Series Network Appliance User’s Manual Restore User Default Restore the User Default to all the setup options. NOTE: There are 2 kind of BIOS default setting: factory default and optimized default. Boot Override Launch EFI Shell from filesystem device Attempts to launch EFI shell application(Shellx64.efi) from one of the available filesystem...

  • Page 67: Appendix Alan Bypass Configuration

    LAN bypass gives us a solution for this problem. The NA130 series LAN bypass function is very flexible. It can be selected at any time and any stage. You can enable LAN bypass for power on state by jumper, BIOS, or by software program when entering into the OS.

  • Page 68: Lan Bypass Register Configuration

    Select each segment by setting the corresponding bit to 1. When the bit is set to 0, no action happens upon the segment. NOTE: NA130 series support SEGN1 for LAN3 and LAN4. Data read back from this register is not defined and therefore must be ignored. Reading from this register makes no effect on LAN bypass function.
  • Page 69 LAN bypass on the segment when power off. Clearing the bit to 0 disables LAN bypass on the segment when power off. NOTE: NA130 series support SEGF1 for LAN3 and LAN4. Data read back from this register is not defined and therefore must be ignored. Reading from this register makes no effect on LAN bypass function.
  • Page 70 LAN bypass on selected segment(s) based on the setting of Power On Bypass Control register (SEGN1). NOTE: NA130 series support SEGN1 for LAN3 and LAN4. Data (bits 6~0) read back from this register is not defined and therefore must be ignored.
  • Page 71 NA130 Series Network Appliance User’s Manual LAN Bypass Status Register (0x8E3) VER3 VER2 VER1 VER0 LAN Bypass Seg.1 status  Disable=0; Enable=1 Bit 0 Bit 1-3 Not used Bit 7~4 Firmware version Without LAN Bypass function=1111 LAN Bypass Configuration...
  • Page 72 NA130 Series Network Appliance User’s Manual This page is intentionally left blank. LAN Bypass Configuration...

  • Page 73: Appendix Bwdt Timer For System Reset

    NA130 Series Network Appliance User’s Manual APPENDIX B WDT TIMER FOR SYSTEM RESET WDT (Watchdog Timer) The hardware supports the WDT (Watchdog Timer) function. While time-out happens after a defaulted period, the WDT will reset the system. NOTE: If you need sample codes, please contact our FAE directly, and they are for reference purposes only.
  • Page 74 NA130 Series Network Appliance User’s Manual This page is intentionally left blank. WDT Timer for System Reset...

  • Page 75: Appendix Cwarning

    NA130 Series Network Appliance User’s Manual APPENDIX C WARNING  This is a class B Product. In a domestic Environment this Product may cause radio interference in which case the user may be required to take adequate measures.  It will be danger if battery is incorrectly replaced. Replacing only with the same or equivalent type is highly recommended by the manufacturer.
  • Page 76 NA130 Series Network Appliance User’s Manual This page is intentionally left blank. Warning...
