Summary of Contents for Moimstone MWP1100
-
Page 2: User Precaution
User Precaution Please read the instruction carefully to protect yourself and others Precaution when using from personal injury or damage to property. · Please do not touch the phone with wet hands. Departure Wi-Fi phone coverage cannot be used. · Please do not use the phone for any other purposes. Discontinued the use of the Internet because of a power outage, ·... - Page 3 Precaution when using of battery FCC SAR Compliance Statement · Please don’t use any other battery from other manufacturer. Your wireless phone is a radio transmitter and receiver. It can occur danger or damage to device. It is designed and manufactured not to exceed the emission limits ·...
- Page 4 User Precaution Warning · This device shell be used indoors only in 5150~5250Mhz frequency range. · This device was tested for typical body-worn operations. To comply with RF exposure requirements, a minimum separation distance of 1.5cm must be maintained between the user's body and the headset, including the antenna.
-
Page 5: Table Of Contents
Contents User Precaution Extra Function ····················· Accessories ···························· Basic Instrunction Display ····································· Components ·························· HD Voice Features ················ Supplement About Phone ·························· Trouble shooting ···················· LCD Status ····························· Treatment before Disposal ··· Insert the battery ··················· Warranty ·································· Way to set the adapter ·········... -
Page 6: Components
Components HD Voice Features The components must be checked when the package is - To support HD Voice, High-end speakers and receivers opened. Please contact the store where you purchased it are adopted. if there are any missing items. - Implement HD Voice Clarity such as HD TV. - High Voice quality is available than normal internet phone. -
Page 7: About Phone
About Phone Volume : Adjust the sound volume. Menu : Enter the menu. Search : Search the registered phone number. Wireless line : Find the Wi-Fi. Phone book : Move to phone book. Additional channel : Depends on service carrier’s service. Message : Start to Message menu. -
Page 8: Lcd Status
LCD Status Indicate the Wi-Fi signal strength. Status Icon Strong signal Week signal Indicate the phone It is unavailable status of phone call function. status. Please refer the detail contents. It is available status of phone call function. It appears when you set the alarm. It appears unchecked message exist. -
Page 9: Insert The Battery
Insert the battery Way to set the adapter When you first setting Wi-Fi phone, Please use the battery which included gift box. If you need exchange the Connect the adapter battery, you have to contact service center to buy. provided with Rear connector. -
Page 10: Way To Register Wi-Fi Device
Way to register Wi-Fi device Press the start/end button If profile is not registered. to power on. [Menu] → 8.Setting → 1.Wifi setting → 1.Profile Check the Wi-Fi status of AP. Check the WLAN list on the current searching. Case of the connect automatically case. -
Page 11: Make A Phone Call And Hang Up
Make a phone call and Hang up Input the call Press the Answer setting way is [Menu] → 3.Manage call → number phone number 3.Answer call. Using Phone Select the number history on history. Answer a call as outside function Using Search and select If the condition which set outside function, It will notice... -
Page 12: Transfer
Transfer Adjust volume You can transfer the call to other number or another On the waiting mode, Press [Volume] and click the phone in the same group. button, You can adjust the button volume, bell, call, power on/off, alarm, message sound. Allow to adjust volume for 8 steps when you press the [Volume] button or On the call Input the number... -
Page 13: Cfa
Phone Book → 1.Search the contacts → Select → · Specifies the group can be set on the → 3.Group management. Press the [Menu] on the list to delete, edit, send Add, Edit, Delete the group is available with Pressing the the message. -
Page 14: Message
Message Allow to send and receive the message. Please ask to manager for service. Write the message Spam Message → 1.Write → → input the number → → select → 3.Spam message save mode → → input the sender number → ■ Register spam number : Register the spam number up to 5. -
Page 15: Accessories
Accessories Outside function Alarm [Menu] → 5.Accessories → 1.Outside function You can set and clear the alarm. ■ Auto answer setting : When you go out, you can set ■ How to set : [Menu] → 5.Accessories → 3.Alarm → the auto answer and clear the auto answer. -
Page 16: Display
Accessories Display Calculator Display setting Direction or Ok button is works as operator on the You can choose wall paper on the display. displayed screen. There are 10 kinds of wall paper. Press the [Back] button to delete one letter, Press the [Menu] button to delete all. - Page 17 Display Brightness Menu style You can adjust the brightness on the display from 1 level You can select the menu style between Rotate menu and to 10 level. Greed menu. ■ H ow to set : [Menu] → 7.Display → 3.Brightness → ■ H ow to set : [Menu] → 7.Display → 5.Menu style → Select brightness →...
- Page 18 Display Clock/Calendar You can put the desired time and date. ■ How to set : [Menu] → 7. Display → 6. Clock/Calendar → Select the time → Power ON/ OFF You can select the power on/ off wall paper. ■ How to set : [Menu] → 7.Display → 7.Power ON/OFF → Select the display →...
-
Page 19: Trouble Shooting
Trouble shooting Solution for simple issues / Following issues may occur although the phone is working correctly. Symptoms How to solve The battery must be charged enough. Please charge the phone on the cradle to make sure positioned 1. The phone does not work. correctly. -
Page 20: Treatment Before Disposal
Please follow the instructions when you dispose The products which are produced and sold from the product. Moimstone Co, Ltd are guaranteed for 12 months from the date you purchased if the products have been used in accordance with those specified in the documentation ·... -
Page 21: Damage Compensation
Damage Compensation Free of charge Free compensation services will be provided for manufacturer’s defects or spontaneous failure within 12 months of warranty. Compensation Types of damage Within warranty After warranty Major repair within 10 days from the purchase Exchange or refund Major repair within 1 months from the purchase Exchange or free repair Damages occurred during shipping or installation... -
Page 22: Specification
Specification H/W Specification Section Description 240Mhz ARM9, 169Mhz TeakLite DSP FLASH MEMORY 128MBYTE SDRAM MEMORY 64MBYTE System Linux Narrowband : G.711, G.729 CODEC Wideband : G.711.1_R2B, G.711.1_R3, G.722(Option) SIP : RFC3261, RFC2976, RFC3264, RFC3428, RFC3515 and related RFC draft standards. Signaling SRTP(Secure RTP), TLS Protocol... - Page 23 Cradle : 100 x 84 x 46 Weight Handset : 90g, Cradle : 30g Operating Temperature -10 ℃ ~ 50 ℃ Ambient Temperature Humidity 10 ~ 95%, Atmospheric Humidity · MWP1100 supported 802.11 b/g/n& 2.4G, 802.11 a/b/g/n on 5G band is supported only MWP1100A.
- Page 24 MWP-1100E-01(20130710) ·Usual manual can be changed as IP Phone software version without any notice.
