- Page 1 MK7 Installation Instructions...
- Page 2 Thank you for choosing the Double Apex Garage Control. If you have any questions about the installation please do not hesitate to email us at support@doubleapex.co. A PDF version of these in- structions can be found on the product page at doubleapex.co...
- Page 3 LED illuminates. (Figure C) 4. Press and release the smart / learn button on the opener motor unit (Figure A). Figure B © 2016, Double Apex LLC. All rights reserved. Rev3 © 2016, Double Apex LLC. All rights reserved. Rev3...
- Page 4 SW2. Once the control is programmed REMOVE THE BATTERY by hand or with a non-metal tool. © 2016, Double Apex LLC. All rights reserved. Rev3 © 2016, Double Apex LLC. All rights reserved. Rev3...
- Page 5 Programing is complete. Press the chosen button to test. 5. For two button Garage Controls repeat the previous steps with your second opener using button SW2 © 2016, Double Apex LLC. All rights reserved. Rev3 © 2016, Double Apex LLC. All rights reserved. Rev3...
- Page 6 L key. Figure C © 2016, Double Apex LLC. All rights reserved. Rev3 © 2016, Double Apex LLC. All rights reserved. Rev3...
- Page 7 Use a small screw driver to depress and release the connector latches and pull the connector outward. Figure F © 2016, Double Apex LLC. All rights reserved. Rev3 © 2016, Double Apex LLC. All rights reserved. Rev3...
- Page 8 4. Remove the trim panel to the right of the accelerator pedal. Re- move the T20 Torx screw and pull downward on the panel to release it. Figure D Figure D Figure C © 2016, Double Apex LLC. All rights reserved. Rev3 © 2016, Double Apex LLC. All rights reserved. Rev3...
- Page 9 Warning: If the harness becomes caught up do not use ex- cessive force to dislodge. Doing so could cause damage. Figure C Figure D © 2016, Double Apex LLC. All rights reserved. Rev3 © 2016, Double Apex LLC. All rights reserved. Rev3...
- Page 10 Make sure the wires are secure and no bare wire is showing. Take care not to drop the Posi-Taps. Figure C / D Figure D Figure C © 2016, Double Apex LLC. All rights reserved. Rev3 © 2016, Double Apex LLC. All rights reserved. Rev3...
- Page 11 T30 Torx bolt on the left side of the fuse panel. Fig- ure C 5. Remove the 10 amp fuse in postion F36 if equipped. Figure D Figure C © 2016, Double Apex LLC. All rights reserved. Rev3 © 2016, Double Apex LLC. All rights reserved. Rev3...
- Page 12 Figure D For two button kits, the RCA plug corresponding to the 1st button on the button assembly is labeled SW1. Figure C © 2016, Double Apex LLC. All rights reserved. Rev3 © 2016, Double Apex LLC. All rights reserved. Rev3...
- Page 13 Figures B and C Figure C Figure D 5. Install the control cover using the provided screws. Figure D © 2016, Double Apex LLC. All rights reserved. Rev3 © 2016, Double Apex LLC. All rights reserved. Rev3...
-
Page 14: Limited Warranty
Step 9: Limited Warranty Double Apex LLC warrants this product, Garage Control, to be free from de- Reinstall the previously removed trim and you’re done! Any fects in materials and workmanship for one year from date of purchase to the warning lights on the dash should clear themselves after a short original retail Purchaser. -
Page 15: Appendix A - Smart / Learn Settings
For Liftmaster, Do-It, Master Mechanic, Raynor, True Value, and For Liftmaster, Do-It, Master Mechanic, Raynor, True Value, and Craftsman brands use Chamberlain settings. Craftsman brands use Chamberlain settings. © 2016, Double Apex LLC. All rights reserved. Rev3 © 2016, Double Apex LLC. All rights reserved. Rev3... - Page 16 © 2016, Double Apex LLC. All rights reserved. Rev3 © 2016, Double Apex LLC. All rights reserved. Rev3...
- Page 17 www.doubleapex.co email: support@doubleapex.co...
