Installation and Operation Instructions for the Point Sensor Analog transmitter.
Wireless Analog Sensor Model Point Sensor Analog
Installation and Operation Instructions
The Point Sensor Analog wireless analog level sensor transmits a digital value
representing either 0-20 MilliAmp, 0-5Volt or 0-10Volt levels and a unique serial
number to a 418 MHz receiver. The Point Sensor Analog is enclosed in a high impact
ABS enclosure for direct surface mounting in the environment to be measured. Point
Sensor Analog is battery operated
Application: Apply the sensor to a surface to with double-sided adhesive tape. Make
sure that the side labeled with FCC ID is visible and away from any metal surfaces.
Service Function: The wireless analog sensor has an installation mode switch. A
momentary push of this switch will start the convert/transmit cycles. When new and until
this button is pushed the Point Sensor Analog will not transmit. The Point Sensor
Analog will transmit a special installation status mark in the data packet immediately
after the installation/start switch is pushed. After the start a push of the installation
switch will result in the immediate transmission of data and ID and installation status
mark.
Battery: A 3.6 Volt lithium battery powers the Point Sensor Analog wireless sensor.
The battery will last for more than 10 years in the idle state (as shipped from the
manufacturer). The Point Sensor Analog will transmit data for as long as 10 years at a
rate of once each minute once started. The Point Sensor Analog is completely covered
with a water resistant conformal coating to protect the electronics from the environment
and condensation. The user may replace the battery. The Point Sensor Analog may be
placed in a quiescent state (battery life greater than 10 years) by holding the installation
switch closed for more than 4 seconds.
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES, OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY
NOT CAUSE HARMFUL INTERFERENCE AND (2) THIS DEVICE MUST ACCEPT
ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY
CAUSE UNDESERED OPERATION
Point Six, Inc.
FCC ID: M5ZANA
MADE IN USA
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Point Six Point sensor analog
- Page 1 0-20 MilliAmp, 0-5Volt or 0-10Volt levels and a unique serial number to a 418 MHz receiver. The Point Sensor Analog is enclosed in a high impact ABS enclosure for direct surface mounting in the environment to be measured. Point Sensor Analog is battery operated Application: Apply the sensor to a surface to with double-sided adhesive tape.
- Page 2 FCC ID: M5ZANA Point Sensor Analog Data Format The Point Six, Inc. 418 MHz wireless sensors require a compatible receiver with the ability to receive, error check and provide RS232 and RS422/485 interface. This document describes the data format provided by the HA8-wow 418 MHz. Receiver.
- Page 3 FCC ID: M5ZANA Example: C1283FA60B000000EC000F8AD0AB<CR> This field is the mode indicator, the LS-bit which indicates the service state of the transmitter, C1=normal, C0=service mode. C1283FA60B000000EC000F8AD0AB <CR> This field is the unique serial number of the 1-Wire sensor. C1283FA60B000000EC000F8AD0AB <CR> This is analog data field stored MSByte first as a 12-bit number in a 16-bit field.
-
Page 4: Fcc Radio Frequency Interference Statement
Connect the equipment and the affected receiver to power outlets on separate circuits. Consult the dealer or an experienced radio/TV technician for help. MODIFICATIONS Changes or modifications not expressly approved by Point Six Inc. could void the user's authority to operate the equipment.
