RIDGID R884 Operator's Manual

RIDGID R884 Operator's Manual

18 volt/24 volt maxselect reciprocating saw variable speed
Hide thumbs
Table of Contents

Advertisement

Quick Links

Your reciprocating saw
has been engineered and manufactured to our high standards for dependability, ease of operation,
and operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING:
To reduce the risk of injury, the user must read and understand the operator's manual before using this product.
Thank you for buying a RIDGID product.
SAVE THIS MANUAL FOR FUTURE REFERENCE
OPERATOR'S MANUAL
18 VOLT/24 VOLT MaxSelect
RECIPROCATING SAW
VARIABLE SPEED
R884
NEW LITHIUM-ION BATTERY PACKS MUST
BE CHARGED BEFORE FIRST USE
BATTERIES AND CHARGERS SOLD
1
™
SEPARATELY
