Inteset Wireless IR Repeater System User Guide
Installation Steps
Step1: Place the IR Receiver Unit (Yellow Logo) in your desired location (For Example: on or next
to the bezel of your TV or Display). Plug the IR Receiver Cable into the jack on the IR Receiver
Unit and mount the Receiver bud within the line-of-sight of where you will point your remote.
Step 2: Place the IR Emitter Unit (White Logo) and IR Emitter Cable on or near the device(s) you
want to control. (Cable box, STB, etc.). Mount one of the emitter buds on the Emitter Cable
directly on each of the IR sensor(s) of the device(s) you want to control.
Step 3: Press all cables FIRMLY into their respective jacks.
Step 4: Connect the 5v. power supply adapter to each unit where labeled "5VDC". Press in
FIRMLY. Plug the power supply adapter into any 110v wall outlet. Tip: You can replace power
adapters with a USB cable plugged into any 2.0v USB jack. USB cables are available.
Step 5: Point the remote at the IR Receiver bud and press a button. The Blue LED should flash.
Troubleshooting- (Check our Forum at: https://intesettech.com/index.php/forum/)
Issue Problem
The "IR CON"(Confirm) LED doesn't
1
blink when I press the remote control.
Note: Dish, DirectTV, Tivo and some
other SAT/Cable boxes use Radio
Frequency(RF) remotes in some
models of their products. Be sure that
you switch your box to IR, if that is the
case. This product only works with IR
remotes and devices that accept IR
signals.
This device only uses RF between base
units. It cannot communicate with RF
devices other than our receiver and
emitter units.
Solution
Make sure the power supplies are firmly plugged
into the IR Receiver and IR Emitter Units.
Press a remote control button near the IR
Receiver to see if the IR signal from the remote is
received. The Blue LED will flash on both units.
There should be a clear line-of-sight to the IR
Receiver Unit (Yellow Logo). Use the IR Receiver
Cable and plug it into the "EXT IR REC" jack on
the Receiver Unit and mount on your TV bezel.
Make sure the IR Emitter Cable is connected to
the "EXT IR EMITTER" jack on the IR Emitter
Unit (White Logo). One of the two Emitter Buds
of the IR Emitter Cable should be placed over the
IR sensor of the device you want to control.
(Cable Box, BR Player, etc.). See our Forum.
After the system has been set-up, press a button
on the remote control. The "IR CON LED" should
flash Blue on both base units.
