(See Note under Troubleshooting about using DirectTV, Dish, Tivo and other SAT boxes)
Features:
1. Connect wired devices wirelessly using IR signals.
2. Control most home entertainment devices within hundreds of feet of open space.
Specifications:
IR (20-60kHz):
1. Works great with the Inteset INT422 remote and most/all Universal full band carrier frequency
infrared (IR) Remotes
2. Better IR Signal sensitivity creates improved signal distance
RF:
1.
915MHz RF technology built to ignore current 433MHz RF-interference (Base Units)
2.
FSK modulation:
Better signal sensitivity than ASK modulation
Better Anti RF-interference than ASK modulation & Better noise suppression
3.
Digital technology with frequency hopping to minimize RF-interference
4.
Digital encrypted function to ensure privacy, safety and reliability
5.
Power: 5VDC/500mA -You can use the adapter included or you can use a USB cable which
is available on Amazon-Contact us if you have any questions or cannot find the listing.
Kit Includes:
Switching
Dual IR Emitter cable
power supply
w/extra adhesive pads
Adapter
Wireless IR Repeater System User Manual (V4)
Model # INT-3856A-WRLS
Contact us at: Universalremotes.net or Intesettech.com
IR Receiver cable
IR Receiver Unit
IR Emitter Unit
Yellow Logo-Top
White Logo-Top
Yellow Print
White Print
User Manual
Advertisement
Summary of Contents for Inteset INT-3856A-WRLS
- Page 1 2. Control most home entertainment devices within hundreds of feet of open space. Specifications: IR (20-60kHz): 1. Works great with the Inteset INT422 remote and most/all Universal full band carrier frequency infrared (IR) Remotes 2. Better IR Signal sensitivity creates improved signal distance...
- Page 2 Inteset Wireless IR Repeater System User Guide Setup Illustrations-Multiple Receiver and or Emitter units can be used in the same system Additional IR Emitter Units available upon Request...
- Page 3 Inteset Wireless IR Repeater System User Guide Installation Steps Step1: Place the IR Receiver Unit (Yellow Logo) in your desired location (For Example: on or next to the bezel of your TV or Display). Plug the IR Receiver Cable into the jack on the IR Receiver Unit and mount the Receiver bud within the line-of-sight of where you will point your remote.
- Page 4 Inteset Wireless IR Repeater System User Guide The IR CON LED, blinks upon receiving Make sure the embedded IR Emitter in the base a signal from the remote control, but the Unit (White Logo) is pointing directly at the IR target device does not react as expected.
