SWIT S-8770 User Manual

Rechargeable Li-ion Battery Pack

Characteristics

1. High performance Li-ion battery pack, rechargeable.
2. Battery digital information readable by cameras.
3. Build-in multiple protective circuit design.
Caution
1. Never attempt to open the battery pack.
2. Use SWIT charger or the chargers recommended by SWIT.
3. Keep the battery pack terminals clean.
4. Never short-circuit the battery pack terminals.
5. Never expose the battery pack to rain, fire or moisture.
6. Never expose the battery pack to temperature above 60
7. Avoid strong mechanical shock.
8. The battery pack may become warm in use or while being
charged. This is normal.

Specifications

Nominal
Model
voltage
S-8770 7.2V
S-8970 7.2V
S-8M71 7.2V
S-8M91 7.2V
S-8D28 7.2V
S-8D54 7.2V
S-8428 7.2V
S-8945 7.2V
S-8PE6 7.2V
Capacity
31Wh 4400mAh 30W
47Wh 6600mAh 30W
21Wh 3000mAh 30W
32Wh 4500mAh 30W
21Wh 3000mAh 30W
32Wh 4500mAh 30W
21Wh 3000mAh 30W
47Wh 6600mAh 30W
10Wh 1500mAh 25W

Charging

1. The battery pack is not fully charged when it is purchased.
Charge the battery before use.
2. Use SWIT charger or the chargers recommended by SWIT.
3. The battery pack should be charged within a temperature
range of 0-40

Discharging

1. Fully charged battery pack will discharge naturally and please
use it as soon as it gets charged.
2. At low temperature, the running time of battery pack usually
. decreases.
℃
3. The internal impedance of battery pack will be greater at low
temperature, which may cause the automatically circuit cutting.

Storage

Please keep in cool, dry and clean place.
Max output Original battery
4A SONY NP-F970
4A SONY NP-F770
4A SONY NP-QM71D
4A SONY NP-QM91D
4A Panasonic CGR-D28S
4A Panasonic CGA-D54S
4A JVC BN-V428U
4A Canon BP-945
3.5A Canon LP-E6
Tel: +86-25-85805753
Fax: +86-25-85805296
http://www.swit.cc
E-mail: contact@swit.cc
℃
71×39×40mm
71×39×60mm
56×38×40mm
56×38×60mm
60×36×55mm
66×37×62mm
55×37×55mm
71×39×57mm
57×39×22mm
Dimension Mass
190g
280g
150g
220g
181g
248g
181g
286g
300g
