Page 1: Installation Manual
ENGLISH INSTALLATION MANUAL ESPAÑOL AIR CONDITIONER (SPLIT TYPE) FRANÇAIS ITALIANO DEUTSCH PORTUGUÊS POLSKI ČESKY PУCСКИЙ HRVATSKI MAGYAR NEDERLANDS ΕΛΛΗΝΙΚΑ SVENSKA SUOMI NORSK DANSK ROMÂNĂ БЪЛГАРСКИ EESTI Indoor unit RAS-M05, 07PKVSG-E LATVISKI SLOVENČINA SLOVENŠČINA LIETUVIŲ 11 229 501 99... -
Page 2: Table Of Contents
CONTENTS PRECAUTIONS FOR SAFETY ............................1 ACCESSORY PARTS .................................5 INSTALLATION DIAGRAM OF INDOOR UNIT ........................6 Optional Installation Parts ...............................6 INDOOR UNIT ..................................7 Installation Place ................................7 Cutting a Hole and Mounting Installation Plate .......................7 Wiring Connection ................................8 How to Connect Remote Controller for Wire Operation ....................8 Piping and Drain Hose Installation ..........................9 Indoor Unit Fixing ................................10 Drainage ..................................10... -
Page 3: Precautions For Safety
PRECAUTIONS FOR SAFETY PRECAUTIONS FOR SAFETY Read the precautions in this manual carefully before This appliance is fi lled with R32. operating the unit. • Before installation, please read these precautions for safety carefully. • Be sure to follow the precautions provided here to avoid safety risks. The symbols and their meanings are shown below. - Page 4 DANGER • FOR USE BY QUALIFIED PERSONS ONLY. • TURN OFF MAIN POWER SUPPLY BEFORE ATTEMPTING ANY ELECTRICAL WORK. MAKE SURE ALL POWER SWITCHES ARE OFF. FAILURE TO DO SO MAY CAUSE ELECTRIC SHOCK. • CONNECT THE CONNECTING CABLE CORRECTLY. IF THE CONNECTING CABLE IS CONNECTED WRONGLY, ELECTRIC PARTS MAY BE DAMAGED.
- Page 5 • Do not use any refrigerant different from the one specifi ed for complement or replacement. Otherwise, abnormally high pressure may be generated in the refrigeration cycle, which may result in a failure or explosion of the product or an injury to your body.
- Page 6 CAUTION • Exposure of unit to water or other moisture before installation could result in electric shock. Do not store it in a wet basement or expose to rain or water. • After unpacking the unit, examine it carefully for possible damage. •...
-
Page 7: Accessory Parts
Installation Plate × 1 Battery × 2 Remote control holder × 1 Mounting screw × 6 Toshiba new IAQ fi lter × 1 Flat head wood screw × 2 Owner’s Manual × 1 Flat head wood screw × 1 Installation Manual × 1 "... -
Page 8: Installation Diagram Of Indoor Unit
INSTALLATION DIAGRAM OF INDOOR UNIT INSTALLATION DIAGRAM OF INDOOR UNIT For the rear left and left piping Wall Hook Installation plate Insert the cushion between the indoor unit and wall, and tilt the indoor unit for Flat head better operation. wood screw The auxiliary piping can be connected to Battery... -
Page 9: Indoor Unit
INDOOR UNIT INDOOR UNIT Mounting the installation plate Installation Place • A place which provides the spaces around the indoor unit as shown in the Hook diagram • A place where there are no obstacles near the air inlet and outlet •... -
Page 10: Wiring Connection
How to Connect Remote Controller Wiring Connection for Wire Operation Indoor unit Wiring of the connecting cable can be carried out without removing the front panel. Indoor unit 1. Remove the air inlet grille. Open the air inlet grille upward and pull it toward you. 2. -
Page 11: Piping And Drain Hose Installation
*Remark : 1. Recommend to use double insulation lead wire for connect For remote controller remote control and air conditioner. 2. For wire operation, 1 remote control can control only 1 indoor 1. Remove cover of remote controller by sliding down and take it out. unit. -
Page 12: Indoor Unit Fixing
In case of right or left piping Indoor Unit Fixing • After scribing slits of the back body 1. Pass the pipe through the hole in the wall and hook the indoor unit on the with a knife or a making-off pin, cut installation plate at the upper hook. -
Page 13: Others
OTHERS OTHERS Gas Leak Test Test Operation To switch the TEST RUN (COOL) mode, press [RESET] button for 10 seconds. (The beeper will make a short beep.) Check places for the indoor unit. OPERATION / RESET Button Check places for the outdoor unit.
