Pioneer AVX-P7000CD UC Service Manual

7 inch wide av system display/cd player.
Hide thumbs

Advertisement

QQ
3 7 63 1515 0
Service
Manual
7 INCH WIDE AV SYSTEM DISPLAY/CD PLAYER
AVX-P7000CD
AVX-P7000CD
AVX-P7000CD
NOTE:
- See the separate manual CX-680(CRT2216) for the cassette mechanism description.
TE
L 13942296513
- The CD mechanism assy employed in this model is one of H1 series.
