Double K Industries Challengair 2000XL Instruction Manual

NOZZLE ASSEMBLY INSTRUCTIONS

Installing nozzle
body on dryer
hose: Screw the
nozzle body onto
the hose in
counter-clockwise
motion. Nozzle
body may be used alone, with a handle or with any of the included nozzle tips.
:
Installing and removing handle
(raised track) at the rear of the nozzle body and
position the handle behind the key. Insert the key
into the slot on the top of the handle. To remove
the handle, slide the handle backwards away from
the nozzle body, taking care to keep fingers away from the
nozzle body and toward the handle bottom.
Attaching nozzle tips: Place the front of the nozzle body towards the back of
the nozzle tip. "Rock" the nozzle tip onto the nozzle body until the nozzle tip
locks into place. Check if it is
secure by gently pulling the
nozzle tip and nozzle body.
To remove a nozzle tip: Firmly grasp
the nozzle body with one hand and
the tip with the other. "Rock" or push and pull side-to-side
while pulling the tip in a motion away from the nozzle body
until the tip is released.
Attachment List
Attachment P/N
825-6
2036
2079
2079-H
2079-TAS
2079-THV
2079-TSHV
8
Locate the key
Description
1½" Hose Black on Blue
Hose to Dryer 1½" Locking Adapter
1½" Airgonomic Nozzle Body
Nozzle Handle
Air Sweep Nozzle Tip
Hi-Velocity Nozzle Tip
Super Hi-Velocity Nozzle Tip
PLEASE READ ALL INSTRUCTIONS AND SAFETY
PRECAUTIONS BEFORE OPERATING PRODUCT.
SAVE FOR FUTURE REFERENCE. WARRANTY
Qty.
1
1
Amperage: 9.40
1
1
Motor Air Volume: 124 CFM
1
1
9711 Mason Avenue, Chatsworth, CA 91311
(818) 772-2887 • (800) 821-9449 • fax: (818) 886-0218
1
www.DoubleKIndustries.com • info@DoubleKIndustries.com
ANIMAL DRYER ANIMAL DRYER
INSTRUCTION MANUAL INSTRUCTION MANUAL
PERTINENT CONTENT.

Product Specifications:

Model - 2000XL™
Voltage: 115v Voltage: 230v
Amperage: 4.5
Horse Power: 3
Wattage: 1035
Wattage: 1081
Hertz: 50/60
Hertz: 60
Motor Air Volume: 124 CFM
TM
TM
0788
