Hobo U10-003 Manual

HOBO U10 Temp/RH Data Logger (Part # U10-003)
®
Inside this package:
• HOBO U10 Temp/RH
Logger
• Mounting kit with magnet, hook-and-loop
tape, and 3/8" double-sided tape.
Doc # 11196-B, MAN-U10-003
Onset Computer Corporation

Specifications

Temperature: -20° to 70°C (-4° to 158°F)
Measurement
range RH: 25% to 95% RH
Temperature: ± 0.53°C from 0° to 50°C (± 0.95°F
from 32° to 122°F), see Plot A
RH: ± 3.5% from 25% to 85% over the range of
Accuracy
15° to 45°C (59° to 113°F), see Plot B; ± 5%
from 25% to 95% over the range of 5° to 55°C
(41° to 131°F), see Plot B
Temperature: 0.14°C at 25°C (0.25°F at 77°F),
see Plot A
Resolution
RH: 0.07% @ 25°C and 30% RH
Temperature: 0.1°C/year (0.2°F/year)
Drift
RH: <1% per year typical
Response time in
Temperature: 10 minutes, typical to 90%
airflow of 1 m/s
RH: 6 minutes, typical to 90%
(2.2 mph)
Approximately ± 1 minute per month at 25°C
Time accuracy
(77°F), see Plot C
Logging: -20° to 70°C (-4° to 158°F); 0 to 95%
Operating range
RH (non-condensing)
Battery life 1 year typical use
Memory 64K bytes (52,000 10-bit measurements)
Weight 26 g (0.82 oz)
Dimensions 45 x 60 x 20 mm (1.8 x 2.38 x 0.77 inches)
The CE Marking identifies this product as
complying with the relevant directives in the
European Union (EU).
© 2005–2012 Onset Computer Corporation
Part #: MAN-U10-003, Doc #: 11196-B
Thank you for purchasing a HOBO data
logger. With proper care, it will give you
years of accurate and reliable measurements.
The HOBO U10-003 is a two-channel
Temperature/Relative Humidity Data Logger
with 10-bit resolution and capacity for
52,000 measurements. The logger uses a
direct USB interface for launching and data
readout by a computer.
HOBOware
operation. Visit www.onsetcomp.com for
details.
Plot A
®
software is required for logger
100%
90%
80%
70%
60%
50%
40%
30%
20%

Connecting the logger

The U-Series logger requires an Onset-supplied USB interface cable to
connect to the computer. If possible, avoid connecting at temperatures
below 0°C (32°F) or above 50°C (122°F).
1. Plug the large end of the USB interface cable into a USB port on the
computer.
2. Plug the small end of the USB interface cable into the side of the
logger as shown in the following diagram.
3. Load and use logger software to operate the logger (see software
manual).
U10 RH Accuracy
Not Specified
+/- 5%
+/-3.5%
0 10 20 30 40
°C
Plot B
Plot C
50 50 60
