Summary of Contents for Innova C01R2W
- Page 1 Adjustable Base C01R2W Wireless Owner Manual CONTENTS Advisory Setup and Installation Wireless Hand Control 1-2-20 year Warranty 1- 1 1...
-
Page 2: Warranty Warning
WARNING Attention: Read the following information before using this product . Failure to use a surge protection device could compromise safety or cause product malfunction and could void the electrical portion of your warranty. - Electrical surges are by far the biggest cause of problems with electrical circuits. -
Page 3: Location Environment
PRODUCT RATINGS: The bed lift motors are not designed for continuous use of more than 2 minutes in an 18 minutes period, or approximately 10% duty cycle. Any attempt to circumvent or exceed this rating will shorten the life expectancy of the product and may void the warranty. WEIGHT UNITS: The limitation for this adjustable bed is 750 lbs. - Page 4 Make sure the base is in a flat position. Always unplug the base from the electrical outlet before cleaning or servicing the base. If the cord or plug is damaged, discontinue use of the bed base and contact qualified service personnel for examination and repair. FCC COMPLIANCE: This device complies with part 15 of the FCC Rules for residential use.
-
Page 5: Setup And Installation
SETUP and INSTALLATION Important: We strongly recommend Two able-bodied adults setup and Step 1: assemble this product. Check and verify all parts are included before discarding any packing materials. All electronics and components that need to be installed are located in boxes under the base or attached to the frame. - Page 6 Step 4: Locate the Wireless Remote control and insert 2 AAA batteries (See Figure 3) Step 5& 6: Plug electrical cord into a grounded electrical outlet . Using the Wireless Remote, push the Head Up button, Foot Up button for a momentary test of the Wireless Remote.
- Page 7 Step 8: -Unplug the Power Cord. -Install the four legs firmly into the base of the frame. The legs screw into the threaded holes in each corner of the adjustable base frame (See Figure 2). -Do not over tighten Step 9: With the help of your able-bodied assistant , carefully lift the F i g u r e 2 adjustable bed frame and set it in place upright on its legs .
- Page 8 USING SAME REMOTE The bed base is designed to allow two twin X-Long bases to become an Eastern King base and two Split-Cal-King bases to become a Cal-King base. And you can use the same remote to control two side by side beds bases by following Step 7 on the installation guide to synchronize the remote with the two control boxes of the two units.
- Page 9 Wireless Remote Adjustable Beds Indicator light Head down button Head up button Press to Raise the Press to low the head of the bed head of the bed Foot down button Foot up button Press to raise the Press to low the foot of the bed foot of the bed Head&Foot down button...
-
Page 10: Year Limited Warranty
Upon notice during the first year after the warranty commencement date, Innova will repair or replace (at no cost to the purchaser) any defective adjustable bed part, and INNOVA will pay all authorized labor and transportation costs associated with the repair of replacement of any parts found to be defective . - Page 11 INNOVA at its option and in its sole discretion. Repair or replacement shall be the sole remedy of the purchaser. There shall be no liability on the part of Innova for any special, indirect, incidental, or consequential damages or for any other damage, claim, or loss not expressly covered by the terms of this warranty.
