Summary of Contents for Aktakom AVS-1050
- Page 1 VIDEO BORESCOPE AVS-1050 User’s Manual www.tmatlantic.com...
-
Page 2: Table Of Contents
Camera Test & Video Borescope Camera Test & Video Borescope Contents Page .................. 1.Warning ................2.Introduction ..............3.Function Description ................4.Specifications ..............5.standard configuration ..........6.Panel name and function description ..............7.Operation Instructions ..................8.Notes www.tmatlantic.com... -
Page 3: Warning
Camera Test & Video Borescope Camera Test & Video Borescope 1.Warning Safety Notes Before using the instrument, please read all safety information and specification of the Video borescope carefully. Application places • Can be apply to detect the internal components of instruments working normally or not(such as: cars or large machines) •... -
Page 4: Function Description
Camera Test & Video Borescope Camera Test & Video Borescope 3.Function Description Support the real-time view Support AV input Highlighted with LED,to support the operation of the dark places Built-in 1400mAh lithium battery, support USB charging Standby function to support the charge NTSC/PAL auto switch www.tmatlantic.com... -
Page 5: Specifications
Camera Test & Video Borescope Camera Test & Video Borescope 4.Specifications Camera 1/4inch CMOS Sensor size Sensor pixel 300,000 Maximum resolution 640 x 480 Maximum frame rate 30FPS/S Fixed focus15cm~25cm(5.9”~9.8”) Focusing method: Gooseneck length 1m(39”) Camera diameter 17mm(0.66”) TFT-LCD 2.4 inch Color TFT-LCD size: Display resolution 480(W) x 234(H) -
Page 6: Standard Configuration
Camera Test & Video Borescope 5.standard con guration • Instrument • 17mm Imager • Hook,Magnet,Mirror Attachments • Lithium batteries 6.Panel name and function description 1.USB Charge 2.(Inside video)Camera 3.Power button/ Mode button 4.External AV input 5.Status Indicator 6.Goose-shaped 7.Light source level 8.Camera connectors 9.System reset DC5V 500mA... -
Page 7: Operation Instructions
Camera Test & Video Borescope Camera Test & Video Borescope 7.Operation Instructions Open and closed systems • Power Switch: long press and hold the on/off button, Video borescope start, and long press and hold the on/off button again to power off the Video borescope. •... - Page 8 Camera Test & Video Borescope Camera Test & Video Borescope Image signal system • Signal path: there are two accesses of the image signal entering, one way is for the image signal of inside camera and the other is for the external AV signal.
- Page 9 Camera Test & Video Borescope Camera Test & Video Borescope • Signal format instructions: When the switch to the external signal,TFT-LCD upper-left corner will indicate the current image signal format. Power Supply Management • Power Supply Instructions:When the system battery voltage is greater than 4.1V when the upper right corner of TFT-LCD display "...
-
Page 10: Notes
Camera Test & Video Borescope Camera Test & Video Borescope 8.Notes • The non-professional persons should not open the machine cover • Put down with caution. • The camera is waterproof, but the scope body isn’t waterproof, so please do not put the microscope instrument under rain or wet areas, or operate it in moist location.
