Standard 22 Compact GYRO COMPASS
and
Standard 22 GYRO COMPASS
Type 110 - -233 NG002 E01/E02
Operator manual
4201.DOC010102
Edition:
February 2015
Raytheon Anschütz GmbH
Postfach 1166
D - - 24100 Kiel
Germany
Tel +49- -4 31- -30 19- -0
Fax +49- -4 31- -30 19- -501
Email Service@raykiel.com
www.raytheon- -anschuetz.de

Advertisement

Table of Contents
loading

Related Manuals for Raytheon Standard 22 Compact

Summary of Contents for Raytheon Standard 22 Compact

  • Page 1 D - - 24100 Kiel Germany Tel +49- -4 31- -30 19- -0 Fax +49- -4 31- -30 19- -501 Email Service@raykiel.com www.raytheon- -anschuetz.de Standard 22 Compact GYRO COMPASS Standard 22 GYRO COMPASS Type 110 - -233 NG002 E01/E02 Operator manual 4201.DOC010102 Edition:...
  • Page 2 Weitergabe sowie Vervielfältigung dieser Unterlage, Verwertung und Copying of this document, and giving it to others and the use or Mitteilung ihres Inhaltes nicht gestattet, soweit nicht ausdrücklich communication of the contents thereof, are forbidden without express zugestanden. Zuwiderhandlungen verpflichten zu Schadenersatz. authority.

  • Page 3: Table Of Contents

    Operator manual Compass Standard 22 Compass Standard 22 Standard 22 Compact TABLE OF CONTENTS Page General ..............
  • Page 4 Operator manual Compass Standard 22 Standard 22 Compact Due to the introduction of a new Performance Standard “MSC.302(87) Performance standard for Bridge Alert Management” and revised Test Standards “ISO 8728:2014 Ships and marine technology - Marine gyro-compasses“ respectively “ISO 16328:2014 Ships and marine technology - Gyro-compasses for high-speed craft”...
  • Page 5 Operator manual Compass Standard 22 Compass Standard 22 Standard 22 Compact The AC supply voltage (ships mains) may drop out. This leads to a restart of the gyrocompass and a new settling stage. The heading information during this settling stage has a reduced accuracy (see section 2.1.2).
  • Page 6 Operator manual Compass Standard 22 Standard 22 Compact Intentionally left blank 4201.DOC10102 Edition: February 2015...

  • Page 7: General

    Operator Manual Compass Compass Standard 22 Standard 22 Standard 22 Compact General This compass is designed for use as a navigation aid on board ships. As a sensor, and unaffected by the magnetic earth field, it determines the north bearing, and thus enables a heading to be steered in relation to true north.
  • Page 8 -- 24V d.c. voltage supply -- DV--bus (alternative inputs for speed/position at the Distribution Unit Optional feature: -- Other (non Raytheon Anschütz) heading sensors can be connected to the Distribution Unit Outputs: Outputs (at STD 22 compass): -- 2 x Heading (course bus or NMEA)

  • Page 9: Std 22 Compact Gyro Compass

    Compass Compass Standard 22 Standard 22 Standard 22 Compact STD 22 Compact Gyro Compass The position and speed (GPS and Pulse Log) are supplied to the compass as input data. Both types of data are required for the automatic Speed Error Correction function.
  • Page 10 Operator Manual Compass Standard 22 Standard 22 Compact Quick Settling operator unit (Option) This function can be used to reduce the time between switching on the compass and indicating (outputting) a valid heading value to one hour (with a precision of +/--3).

  • Page 11: Std 22 Compact Gyro Compass -- Scope Of Supply

    Operator Manual Compass Compass Standard 22 Standard 22 Standard 22 Compact 1.1.1 STD 22 Compact Gyro Compass - - Scope of Supply Gyrosphere packed separately Gyro compass with outer sphere, -- Tool and spare parts pack distilled water and supporting liquid...

  • Page 12: Std 22 Compact Gyro Compass Optional Features

    Operator Manual Compass Standard 22 Standard 22 Compact 1.1.2 STD 22 Compact Gyro Compass optional features 1.1.2.1 Quick Settling operator unit The “Quick Settling” function reduces the time the compass requires to settle to approximately one hour. The most recent heading is stored when the gyro compass is switched off. When it is switched on the compass uses that value to make a default setting so that the settling time is reduced.

  • Page 13: Ac/Dc Converter, 121-062

    Operator Manual Compass Compass Standard 22 Standard 22 Standard 22 Compact 1.1.2.2 AC/DC converter, 121-062 The AC/DC converter is supplied with 115 to 230 V AC on the input side, and delivers 24 V DC as output voltage with a maximum output power of 240 W (see separate manual no.

  • Page 14: Std 22 Gyro Compass

    Operator Manual Compass Standard 22 Standard 22 Compact STD 22 Gyro Compass In this application the gyro compass is operated on a bus system (CAN bus). With this application there are more extended options for connecting external equipment, and considerably more heading receivers can be operated.
  • Page 15 -- Pulse Log Direction Status signals or pulses -- Pulse Log Optional features (via a connected Distribution Unit): Magnetic sonde (Raytheon Anschuetz probe, type108--010) FLUXGATE compass MINS Satellite Compass and other non Raytheon Anschuetz heading sensors 4102.DOC010102 Edition: February 2015...
  • Page 16 Operator Manual Compass Standard 22 Standard 22 Compact Voltage is supplied to the gyro compass via the Distribution Unit or is directly connected to the compass itself. There are separate manuals for the Operator Unit and for the Distribution Unit.

  • Page 17: Std 22 Gyro Compass -- Scope Of Supply

    Operator Manual Compass Compass Standard 22 Standard 22 Standard 22 Compact 1.2.1 STD 22 Gyro Compass - - Scope of Supply Gyrosphere packed separately Gyro compass with outer sphere, -- Tool and spare parts pack distilled water and supporting liquid...

  • Page 18: Optional Features For The Std 22 Gyro Compass

    Operator Manual Compass Standard 22 Standard 22 Compact 1.2.2 Optional features for the STD 22 Gyro Compass 1.2.2.1 AC/DC converter, 121-062 The AC/DC converter is supplied with 115 to 230 V AC on the input side, and delivers 24 V DC as output voltage with a maximum output power of 240 W (see separate manual no.

  • Page 19: Technical Data

    Operator Manual Compass Compass Standard 22 Standard 22 Standard 22 Compact Technical data The technical data stated here apply equally to the STD 22 Compact Gyro Compass and the STD 22 Gyro Compass 1.3.1 Mechanical data Gyro compass, see dimensional drawing 110 D 233 HP005 1.3.2...

  • Page 20: General Technical Data

    Operator Manual Compass Standard 22 Standard 22 Compact 1.3.3 General Technical Data “Quick Settling” function Reduces the settling in phase to approximately 1 hour. Quick Settling should only be used when the heading of the vessel has not been changed during the period between switching off the compass and switching it back on and if the compass has been switched off for a duration of min.

  • Page 21: Controls And Indicators On The Gyro Compass

    Operator Manual Compass Compass Standard 22 Standard 22 Standard 22 Compact Controls and Indicators on the Gyro Compass The user information stated here applies equally to the STD 22 Compact Gyro Compass and the STD 22 Gyro Compass. Viewed from above (see Figure 8 )
  • Page 22 Operator Manual Compass Standard 22 Standard 22 Compact After removing the cover: Do not touch live parts. Neither the DIP switches nor the buttons are live. A DIP switch (B37) and two push--buttons (B38 and B39) are used to adjust the...

  • Page 23: Switching On The Std 22 Compass

    Operator Manual Compass Compass Standard 22 Standard 22 Standard 22 Compact Switching on the STD 22 Compass The compass goes into operation when the power supply is switched on from the ship’s mains. The compass goes into the heating stage for the first 30 minutes (this period will vary depending on the temperature of the supporting liquid) and the letter “h”...

  • Page 24: Indications On The Compass During The Heating Stage

    Operator Manual Compass Standard 22 Standard 22 Compact 2.1.1 Indications on the compass during the heating stage heating current temperature approx. 30 minutes until a temperature of 45  C has been reached The temperature for the internal follow up system to switch on has been reached.

  • Page 25: Indications On The Compass During The Settling Stage

    Operator Manual Compass Compass Standard 22 Standard 22 Standard 22 Compact 2.1.2 Indications on the compass during the settling stage No NMEA Heading and NMEA RoT is displayed (output) during the settling stage. Continuous light For 4 hours after switching on (with Quick Settling this is 1 hour) Heading indication still inaccurate.

  • Page 26: Overview Of Indications (Digital Display) During Operation

    Operator Manual Compass Standard 22 Standard 22 Compact 2.1.3 Overview of indications (digital display) during operation Once the compass is switched on the digital display indicates as follows: Indications Comments, Information Heating stage ¡ The temperature of the supporting liquid is Example displayed during the heating stage.

  • Page 27: Heading Correction

    Operator Manual Compass Compass Standard 22 Standard 22 Standard 22 Compact Heading correction The information given here, in particular with regard to Speed Error Correction, applies in general to the STD 22 Compact compass and the STD 22 compass. Where there is an exception, your attention is drawn to this.

  • Page 28: Procedure For Setting The Compass Zero (A-Error)

    Operator Manual Compass Standard 22 Standard 22 Compact 2.2.1.1 Procedure for setting the compass zero (A-error) Display Button B39 Button B38 B37 DIP switch Figure 12 : Arrangement of operating elements inside the compass Remove the cover of the compass (unfasten the 5 cross--slotted screws) Move switch B37 (DIP switch), contact (1) to the “OPEN”...
  • Page 29 Operator Manual Compass Compass Standard 22 Standard 22 Standard 22 Compact DIP switch B 37 DIP switch B 37 OPEN OPEN 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 OPEN OPEN 176.9 176.8...

  • Page 30: Speed Error

    Operator Manual Compass Standard 22 Standard 22 Compact 2.2.2 Speed error A speed error occurs while the ship is travelling. This becomes greater as the speed increases and is more pronounced on northerly and southerly headings than on easterly and westerly headings.
  • Page 31 Operator Manual Compass Compass Standard 22 Standard 22 Standard 22 Compact Example of heading calculation Compass heading 345 223.7 Latitude 55 55 Speed 16 Kts 16 Kts Correction value from table -- 1.7 + 1.3 True heading 345 -- 1.7 = 343,3...

  • Page 32: Speed Error Table

    Operator Manual Compass Standard 22 Standard 22 Compact 2.2.2.1 Speed error table north south Latitude Headings in  Speed in Kts in  sign for correction value 4201.DOC010102 Edition: February 2015...
  • Page 33 Operator Manual Compass Compass Standard 22 Standard 22 Standard 22 Compact north south Latitude Headings in  Speed in Kts in  sign for correction value 4102.DOC010102 Edition: February 2015...
  • Page 34 Operator Manual Compass Standard 22 Standard 22 Compact north south Latitude Headings in  Speed in Kts in  sign for correction value 10.9 10.5 4201.DOC010102 Edition: February 2015...
  • Page 35 Operator Manual Compass Compass Standard 22 Standard 22 Standard 22 Compact north south Latitude Headings in  Speed in Kts in  sign for correction value 10,3 10,9 10,5 10,5 11,2 12,0 12,7 13,5 10,1 10,8 11,6 12,3 13,0 10,3...

  • Page 36: Operating Conditions Requiring Attention

    Operator Manual Compass Standard 22 Standard 22 Compact Operating conditions requiring attention An operating condition that indicates a malfunction but has no immediate effect on the heading output is indicated by a flashing decimal point. It is not necessary to acknowledge such a condition on the compass.

  • Page 37: Operating Conditions Requiring Attention, Their Causes, And What To Do

    Operator Manual Compass Compass Standard 22 Standard 22 Standard 22 Compact Operating conditions requiring attention, their causes, and what to do There are five different operating conditions requiring attention (numbered 1 to 6, 6 is not used). These are displayed on the compass’s digital display after the B38 or B39 buttons have been pressed once.
  • Page 38 Operator Manual Compass Standard 22 Standard 22 Compact flashing Examples of OPEN conditions: Condition 4 1 2 3 4 5 6 7 8 Conditions 4 and 5 OPEN Condition 1 Conditions 1 to 3 1 2 3 4 5 6 7 8 Figure 14 : How to display information about operating conditions 4201.DOC010102...

  • Page 39: Operating Condition 1 "Fan Failure

    Operator Manual Compass Compass Standard 22 Standard 22 Standard 22 Compact 3.1.1 Operating condition 1 “Fan failure” This condition is generated if the fan does not switch itself on as a result of the temperature of the supporting liquid (it should switch on when the supporting liquid reaches 51C).

  • Page 40: Operating Condition 2 "Heater Failure

    Operator Manual Compass Standard 22 Standard 22 Compact 3.1.2 Operating condition 2 “Heater failure” This condition is output when the heater (45C) has failed. Compass operation is not restricted if the temperature is more than 45C (see also “fan failure”.

  • Page 41: Operating Condition 4 "Supporting Liquid Level Too Low" And Its Immediate

    Operator Manual Compass Compass Standard 22 Standard 22 Standard 22 Compact 3.1.4 Operating condition 4 “Supporting liquid level too low” and its immediate measure This condition is output when the level of the supporting liquid in the outer sphere is too low.
  • Page 42 -- Open the ventilation outlet (Figure 15 /1), the supporting liquid screw (Figure 15 /3) and the distilled water screw ( Figure 15 /2). -- Fill in distilled water (only distilled water from Raytheon Anschütz, part number 148--398, one 230cm bottle) into the inlet for supporting liquid until the measuring cone shows “Level O.K.”, see Figure 16 .
  • Page 43 Operator Manual Compass Compass Standard 22 Standard 22 Standard 22 Compact distilled water vent Figure 15 : Immediate measure to fill up with distilled water Level: OK (at operational temperature (appr. 50 C)) Level: too low Figure 16 : Measuring cone (top view) 4102.DOC010102...
  • Page 44 Operator Manual Compass Standard 22 Standard 22 Compact Dip--Stick Figure 17 : Dip--Stick levels 4201.DOC010102 Edition: February 2015...

  • Page 45: Without Switching Off The Gyro Compass

    Operator Manual Compass Compass Standard 22 Standard 22 Standard 22 Compact 3.1.4.2 Without switching off the gyro compass The measure below does not compensate the planned replacement of the supporting liquid! In certain circumstances (if the level of the supporting liquid falls suddenly) you must establish the cause (possibly a leak) and correct the fault.
  • Page 46 Operator Manual Compass Standard 22 Standard 22 Compact It is not necessary to switch off the gyro compass for this measurement. -- Undo the two screws at the top and the bottom of the door of the gyro compass enclosure and lift out the door, paying attention to the earthing strip.
  • Page 47 -- Open the ventilation outlet (Figure 15 /1), the supporting liquid screw (Figure 15 /3) and the distilled water screw ( Figure 15 /2). -- Fill in distilled water (only distilled water from Raytheon Anschütz, part number 148--398, one 230cm bottle) into the inlet for supporting liquid until the measuring cone shows “Level O.K.”, see Figure 16 .

  • Page 48: Operating Condition "Voltage Cut-Off

    Operator Manual Compass Standard 22 Standard 22 Compact 3.1.5 Operating condition “Voltage cut-off” This operating condition is output if the supply voltage is cut off for a short time. The cut-off period is determined by the fall in supporting liquid temperature. If the temperature falls below 45C the compass recognises that the voltage supply has been...

  • Page 49: Alert Signalling

    Operator Manual Compass Compass Standard 22 Standard 22 Standard 22 Compact Alert signalling Alerts are indicated on the compass as follows: The heading is not displayed and not output to the connected heading receivers! An alert signal is indicated on the digital display by means of a flashing Erro (for Error) (flashing “OFF”), flashing “OFF”...
  • Page 50 Operator Manual Compass Standard 22 Standard 22 Compact Display Button B38 B37 DIP switch Button B39 Figure 21 :Operating elements on the compass (after removing the cover) The following failed PC--boards are possible: PCbP = power PCB faulty PCbS = sensor PCB faulty...
  • Page 51 Operator Manual Compass Compass Standard 22 Standard 22 Standard 22 Compact Error Comment Error- group code PCbP Serial connection of sensor PCB to power PCB faulty E.L.01 PCbP Inductive transmission faulty E.L.02 PCbP System voltage (B5.5  B5.8) on power PCB faulty E.L.03...

  • Page 52: Switching Off The Gyro Compass

    Operator Manual Compass Standard 22 Standard 22 Compact Switching off the Gyro Compass The gyro compass is switched off by switching off the power supply. Caution!  Maintenance and repair work should be carried out only by trained and qualified staff who are well versed in national safety regulations.

  • Page 53: Maintenance

    Compass Compass Standard 22 Standard 22 Standard 22 Compact Maintenance Supporting liquid, distilled water and Pump Rotor have to be replaced every 18 -- 24 months. It is additionally recommended to clean the internal of the outer sphere and the gyro compass.
  • Page 54 Operator Manual Compass Standard 22 Standard 22 Compact Intentionally left blank 4201.DOC010102 Edition: February 2015...
