- Page 1 User Guide...
- Page 3 Cylinder The disposable CO cylinder is produced from recyclable materials in accordance with the sustainability and environment protection standards. It is recommended to deliver the used cylinders to electronic waste collection points. The Company is responsible for the proper operation of the gas cylinder under the following conditions: •...
- Page 4 User Guide Welcome to Strauss Water, your purchase of the water bar enables you and your family to enjoy tasty and quality water; hot, cold, and sparkling water exactly the way you like it. Why should I read it? The following user guide is the shortest and best way to get to familiarize yourself with your new water bar.
- Page 5 Safety Mark 5452 - defines testing of product that come in contact with drinking water European standard for electrical products safety Strauss Water Co. Israel and its quality system have been certified according to international standard ISO9001:2008. Avishay Shapira Quality Manager...
-
Page 6: Table Of Contents
Table of Contents 1. Overview ............................. 2. Operation/Control Panel....................3. Water Bar Operation ......................a. Dispensing Cold Water ............................11 b. Dispensing a Measured Quantity of Cold Water ................11 c. Dispensing Mixed Water............................. 11 d. Dispensing Hot Water ............................12 e. - Page 7 Table of Contents 5. Actions in the Settings Menu ..................a. Clock ....................................23 a.1. Time & Day Adjustment ..........................23 a.2. Setting Clock Format ............................23 a.3. Clock Display ................................24 b. Child Lock Mechanism ............................24 c. Keypad Sound ................................25 d.
-
Page 9: Overview
1. Overview 1 CO cylinder cover 2 Top cover 3 Operation panel with digital display 4 Dispensing spout 5 Folding tray bars 6 Folding tray 7 Drip tray 8 Ventilation vents 9 Electricity cable and heating switch 10 Water entry 11 CO cylinder housing... -
Page 10: Operation/Control Panel
2. Operation/Control Panel 1. Measured quantity of mix water dispensing button 2. Extra hot - boiling button 3. Boiling control light (blinks until boiling has been completed) 4. Hot water dispensing button 5. Digital display 6. Boiling progress bar - when boiling temperature has been achieved, is replaced with extra hot water icon 7. -
Page 11: Water Bar Operation
3. Water Bar Operation a. Dispensing Cold Water To dispense cold water, press the marked top right button. Dispensing will continue while the button is pressed. Please note that continuous dispensing is limited to 4 minutes. b. Dispensing a Measured Quantity of Cold Water To dispense a measured quantity of cold water, briefly press the marked top right button. -
Page 12: Dispensing Hot Water
*Please note! Due to variations in the water flow rate, the set quantity may vary. After dispensing it is important to check that the required quantity was received (especially when preparing food for infants, medications etc.). In the event of quantity variations, the required quantity can be redefined. d. -
Page 13: Dispensing Water With Child Lock
f. Dispensing Water with Child Lock To dispense hot water with child lock it is necessary to simultaneously press marked top left button and also briefly press the marked top right button. dispensing will continue as long as the top left button is pressed. There is no need to continue pressing the top right button during dispensing. -
Page 14: Dispensing A Cup Of Sparkling Water
i. Dispensing a Cup of Sparkling Water To dispense a cup of sparkling water, press the marked right bottom button. Pressing any button during dispensing will stop the action. The water bar is designed to provide a fixed quantity of sparkling water per cup. It is recommended to wait until dispensing has completed. -
Page 15: Dispensing A Jug Of Sparkling Water
l. Dispensing a Jug of Sparkling Water To dispense a jug of sparkling water, briefly press the menu button. After moving to the next dispensing menu, briefly press the marked bottom right button. The default number of cups to be continuously dispensed into a jug is 5. The setting can be changed to 2-7 cups (see section "a.5. -
Page 16: Preferences Menu Actions
4. Preferences Menu Actions The menu enables changing general water bar settings and customizing settings. To enter the menu press button no. 1 for a few seconds. Navigating the different menu options is performed using buttons no. 2 & Selecting an option is performed by pressing button no. -
Page 17: Setting The Quantity For Dispensing Mixed Water
COLD CUP COLD CUP Place a cup on the tray. Press and hold the OK button to Recording... start Recording Release OK to Stop a.2. Setting the Quantity for Dispensing Mixed Water This option enables setting the quantity of mixed water that will be dispensed when briefly pressing the mixed water button. -
Page 18: Setting The Quantity For Dispensing A Jug Of Cold Water
Notes: (1) You can set a water quantity of 0-300 ml. (2) It is not possible to dispense a measured amount of hot water when child lock is on. (3) To cancel the set quantity of hot water measured cup, briefly press the button in the DEFINE QUANTITY HOT CUP screen. -
Page 19: Setting The Quantity For Dispensing A Jug Of Sparkling Water
a.5. Setting the Quantity for Dispensing a Jug of Sparkling Water This option enables setting the quantity of a jug of sparkling water that will be dispensed when briefly pressing the jug of sparkling water button. To adjust the measured quantity, enter the DEFINE QUANTITY sub menu. MENU PREFERENCES DEFINE QUANTITY... -
Page 20: Setting Mixedm Water Temperature
b.2. Setting Mixedm Water Temperature The option enables setting the required mixed water temperature. To set the temperature, enter the DEFINE TEMPERATURE sub menu: MENU PREFERENCES DEFINE TEMPERATURE MIX WATER To change the temperature, use the top right and bottom right buttons. To confirm, press the button. -
Page 21: Automatic Heating
To select the preferred sparkling level for display on the home screen, enter the SPARKLING LEVELS sub menu: MENU PREFERENCES SPARKLING LEVELS Select the preferred sparkling level and press the button to confirm. The sparkling level default is REGULAR. PREFERENCES SPARKLING LEVELS DEFINE QUANTITY STRONG... -
Page 22: Wakeup
d.2. Wakeup This option enables predefining two times for waking the heating system, for example: Morning and evening. To turn on the automatic wakeup, enter the WAKEUP sub menu: WAKE UP 1/ MENU PREFERENCES AUTOMATIC HEATING WAKE UP WAKE UP 2 Turning on the automatic wakeup function is performed using the top right and the bottom right buttons. -
Page 23: Actions In The Settings Menu
5. Actions in the Settings Menu a. Clock A clock will appear on the display when the water bar is connected to the electricity supply. It the event of an electricity outage lasting longer than 8 hours, the clock will need to be reset. a.1. -
Page 24: Clock Display
a.3. Clock Display The option enables a permanent time display on screen. The select the clock display, enter the CLOCK DISPLAY sub menu: MENU SETTINGS CLOCK CLOCK DISPLAY The current setting will appear on the display: ON / OFF. To change the setting, use the top right and bottom right buttons. To confirm, press the button. -
Page 25: Keypad Sound
c. Keypad Sound When this option is on, a short beep will sound whenever a button is pressed. To turn on the option, enter the KEYPAD SOUND sub menu: MENU SETTINGS KEYPAD SOUND The current setting will appear on the display: ON / OFF. To change the setting, use the top right and bottom right buttons To confirm, press the button. -
Page 26: Water Bar Maintenance & Periodic Care
6. Water Bar Maintenance & Periodic Care a. Emptying the Drip Tray It is important to empty the drip tray on time (before it fills up). Order of operations for emptying the drip tray. (1) Close the folding tray. Wait a few seconds for the leftover water to drain into the drip tray. -
Page 27: Displaying And Resetting The Filter Replacement Timer
d. Displaying and Resetting the Filter Replacement Timer This option enables showing the time till the next filter replacement on the display; and resetting it if necessary. To display or reset the filter replacement timer, enter the FILTER REPLACEMENT sub menu. MENU MAINTENANCE FILTER REPLACEMENT... -
Page 28: Displaying And Resetting The Uv Lamp Replacement Timer
f. Displaying and Resetting the UV Lamp Replacement Timer It is possible to show the time till the next lamp replacement on the display; and reset it if necessary. To display or reset the UV lamp replacement timer, enter the UV LAMP REPLACEMENT sub menu. MENU MAINTENANCE UV LAMP REPLACEMENT... -
Page 29: Co Cylinder Content
h. CO cylinder content This option enables checking the CO cylinder content. To check the contents of the CO cylinder enter the CO CYLINDER STATUS sub menu: MENU MAINTENANCE CYLINDER STATUS The cylinder status will appear on the display: Blue indicates a 5-100% full cylinder. Red indicates 5% CO left in the cylinder... -
Page 30: Initialization
k. Initialization This option enables performing 2 different actions. The first is initializing all the water bar settings and restoring them to the factory defaults. The second option enables resetting the smart heating data (the hot water usage data) learned by the water bar. k.1. -
Page 31: Smart Heating Reset
k.2. Smart Heating Reset This option enables deleting of all the boiling habits learned by the water bar. To reset the smart heating data, enter the SMART HEATING RESET sub menu. MENU MAINTENANCE RESET SMART HEATING RESET To reset the data, select YES using the top right and bottom right buttons. To confirm, press the button. -
Page 32: Turn Off Mode
m. Turn Off Mode This option enables turning off the water bar’s display as well as it’s heating and cooling systems. To turn off, enter the TURN OFF sub menu: MENU TURN OFF Select YES using the top right and bottom right buttons. To confirm, press the button. -
Page 33: Cylinder
7. Replacement Date for the CO Cylinder When the CO cylinder is completely empty, a controlled discharging process will be performed by the water bar. During this process the remaining CO the cylinder is emptied into the water bar and may be accompanied by noise. Please note! Do not remove the CO cylinder before the controlled discharging process is completed. -
Page 34: Cylinder
8. Replacing the CO Cylinder When the CO cylinder empties and the empty cylinder icon appears on the display, it will be possible to replace the CO cylinder using the following steps: 1. Lock the keyboard by simultaneously pressing the and buttons for a few seconds. - Page 35 6. Pull the used cylinder upwards. It is recommended to deliver the used cylinders to electronic waste collection points. The cylinder can also be handed to the Strauss Water delivery person with your next order. 7. Insert the new CO...
-
Page 36: Cleaning The Water Bar
9. Cleaning the Water Bar Please note! When cleaning, lock the keypad of the water bar to avoid unwanted water dispensing. see section "m. Keypad Lock" on page 15. Do not clean the water bar with strong cleaning agents, concentrated cleaning liquids, solvents or accessories that may damage the water bar’s enclosure (e.g. -
Page 37: Safety Warnings
10. Safety Warnings • The water bar dispenses water from 2 different nozzles. Use a wide neck bottle or jug for dispensing. • If the ministry of health or any other official authority announce of a health hazard or any other issue with the supplied water quality, drinking water should be boiled and you should act according to their instructions. -
Page 38: Technical Specifications
11. Technical Specifications Electricity Supply Sparkling Water Output Voltage (single phase) 230 V cylinder 380 grams content Frequency 50 Hz Output by Strong- 80 cups Cooling power* 100 W sparkling level Regular - 120 cups Heating power 1,800 W Light - 150 cups Current rating 8.5 A Water Supply... -
Page 39: Troubleshooting
12. Troubleshooting Before calling for a technician, if the water bar is not working, use the following table to check whether the problem is with the water bar and not with the electricity or water supply. Problem Description Possible Causes Actions for Resolution No water dispensed from The water bar is not connected... - Page 40 Problem Description Possible Causes Actions for Resolution When pressing the sparkling a. The CO cylinder is empty Check if the CO cylinder empty icon water button appears on the display. If it does, then No sparkling water is dispensed replace the CO cylinder with a new at all one (see section 8 on page 32).
-
Page 41: Service And Warranty Options
• Proper system maintenance for ensuring water quality includes using only original disposable parts supplied by the manufacturer. • The manufacturer, Strauss Water, will not be held liable for any malfunction and/or fault and/or damage arising from using non-original parts. - Page 42 With Bubble Plus water bars the family drinks more water Manufacturer: Strauss Water Yoni Netanyahu Street 1c, Or Yehuda 603761, Israel | Manufactured in: Israel...
Need help?
Do you have a question about the Bubble PLUS and is the answer not in the manual?
Questions and answers
No cold water level not showing hot and cold water mixture not working
