Fortinet FortiAnalyzer 100C Quick Start Manual

LED State
Green
Power
Off
Flashing Green
Status
Green
Green
Port1, Port2, Port3*
Flashing green
Off
Alarm Off
HDD Flashing green
*Port 3 LED is always green independant of the state.
Visit these links for more information and documentation for your Fortinet product.
• Technical Documentation - http://docs.fortinet.com
• Knowledge Center - http://kb.fortinet.com
• Technical Support - http://support.fortinet.com
• Training Services - http://campus.training.fortinet.com
Package Contents
Interface Type
Console RJ-45
PORT1 and PORT2 RJ-45
PORT3 RJ-45
USB USB
FortiAnalyzer 100C
DC+12V CONSOLE USB
Power
USB
Connection
Ground
Cable Tie
RJ-45 Serial
mounting
Connection
hole
Connecting
Connect the following to the FortiAnalyzer unit. Ensure the FortiAnalyzer unit is placed on a stable surface.
• Connect the RJ-45 to DB-9 serial cable into the Console port on the unit. Insert the other end into the management computer.
• Insert the ethernet cable into WAN1. Insert the other end to the router connected to the Internet, or to the modem.
• Connect the AC power cable to the Power Supply shipped with this product.
• Connect the AC power cable to a surge protected power bar or power supply.
• Insert the pointed end of the cable tie into the hole in the rear panel of the chassis to anchor the cable tie to the chassis.
• Loop the loose end around the adapter cable and insert the loose end into the locking latch.
• Pull the loose end to adjust the tightness of the loop around the adapter cable to prevent cable from being accidentally pulled out the unit.
Configuration Tools
Web-based manager
The FortiAnalyzer web-based manager is an easy to use management tool.
Use it to configure the administrator password, the interface and default gateway addresses,
and the DNS server addresses, add devices for log collection and configure reports.
Requirements:
• An Ethernet connection between the FortiAnalyzer unit and management computer.
• A web browser such as FireFox or Internet Explorer on the management computer.
Description
The unit is on.
The unit is off.
The unit is starting up.
The unit is running normally.
The correct cable is in use and the connected
equipment has power.
Network activity at this interface.
No link established.
Not in use.
The internal hard drive is in use.
Speed Protocol
Ethernet
10/100/1000 Base-T Ethernet
10/100 Base-T Ethernet
USB
POWER STATUS ALARM PORT1 PORT2 PORT3
Power Status
Hard disk
LED LED
Interface
Status LEDs
PORT3 PORT2 PORT1
PORT1
PORT3
PORT2
DC+12V CONSOLE
Power cable
Serial cable
connects to
connects to serial
power supply
port on manage-
ment computer
QuickStart Guide
FortiAnalyzer 100C
© Copyright 2009 Fortinet Incorporated. All rights reserved.
Products mentioned in this document are trademarks or registered trademarks
of their respective holders.
Regulatory Compliance
FCC Class B Part 15 CSA/CUS
22 July 2009
Description
Connection to the management computer. Provides access to the command line interface (CLI).
Connection to the network.
Connection to the network. The speed cannot be changed.
Two optional connections for the USB key, modem, or backup operation.
HDD
Tools and Documenation
drive LED
PORT3
USB
Straight-through
Ethernet cable
connects to Internet
Command Line Interface (CLI)
The CLI is a full-featured management tool. Use it to configure the administrator password,
the interface addresses, the default gateway address, and the DNS server addresses. To
configure advanced settings, see the Tools and Documentation CD-ROM.
Requirements:
• The RJ-45 to DB-9 serial connection between the FortiAnalyzer unit and the
management computer.
• A terminal emulation application (HyperTerminal for Windows) on the management
computer.
POWER STATUS ALARM
QuickStart Guide
FortiGate-30B
FortiAnalyzer 100C
POWER STATUS ALARM PORT1 PORT2 PORT3 HDD
Copyright 2009 Fortinet Incorporated. All rights reserved.
Trademarks
Straight-through
Ethernet cable DB-9 Serial Cable
AC Power Cable
PORT2 PORT1
FortiAnalyzer-100C
PORT1 PORT2 PORT3 HDD
05-40001-101293-20090722
REGISTER
Rack-Mount
4 Rubber feet
Brackets
Cable Tie
RJ-45 to
Power Supply (12V)
