iSport P118 User Manual

User' s Manual
Bluetooth 4. 0 Pedometer
To ensure the accuracy of data, please read this manual carefully before using it.
1.System Block
Screen
Accessories Figure
Tap=Mode key
Pedometer
silicone belt clip
( without battery)
wristband
2. Battery Assembly
During transport, regular turbulence, vibration, can make B.T Pedometer misjudgment, produce
abnormal data. In order to avoid to product abnormal data, In the process of packaging, battery and
Pedometer separated packing.
Before use, the battery must be installed to the Pedometer.
1. from packaging to take out the Pedometer, then use COINS to unlock the battery cover. Insert a
coin into the back of the battery cover slot, and counterclockwise to turn the battery cover off.
2. After open the battery cover, put battery into the Pedometer, the battery "+" up, put the battery into
the battery compartment.
3. After put the battery, battery cover with the arrow point on the Pedometer "unlocked" sign, the
battery cover should be in place, use COINS clockwise battery cover until the battery cover on the arrow
and "lock" sign on a straight line.
1
- After twisting battery door well, screen shows the default time 00:00, knock on a screen, interface will
cyclic display among time - step - calories – distance.
- Now you can set the Pedometer connection.
3. Setting the connection on mobile devices
The Pedometer only can build connection and synchronization of data with mobile devices which support
Bluetooth 4.0, currently supports Android 4.3 and following specific models.
P118
Bettery hatch
Light Disk USB DONGLE
2 3
Ready to set up the connection
- Copy from the accompanying CD or from the App Store (IOS) and Google App Store (Android)
download and install the isport Activity Monitor (below short called APP).
- If you have installed the APP, please ensure that your APP to the latest version.
- To ensure the Bluetooth is open on a mobile device.
Connect with IOS device
Your B.T Pedometer need match connection with your IOS device only by APP, it can't search by your IOS
device to connect:
- Open the APP, make sure the distance between your B.T Pedometer and the IOS device is not more than 5
m, B.T Pedometer in the awake state.
- Enter the APP equipment list, click refresh device, the APP will search nearby B.T Pedometer, and put
searched B.T Pedometer included in the equipment list.
- In the equipment list, click devices which your need match, the APP will match with devices you clicked,
and automatically synchronize data
- Enter the personal Settings interface, setting up your information, click the "save" to storage your
information to the APP and synchronization to your B.T Pedometer.
Remark: B.T Pedometer must be in the awake state, otherwise, click "save" only can store your information in the APP,
CR2025
+
Until the next Successful sync to synchronize your information on your P118.
- Now, you can use the APP to track your movements.
Cr2025
Battery Synchronous data to iOS devices
- Automatic synchronization: your B.T Pedometer can synchronize data directly to the IOS device.
Every time open the APP, the APP will connect to B.T Pedometer immediately and synchronous
data; every 30 minutes automatically synchronize data.
Remark: iOS bluetooth devices must be in state of opening. If you do not open, the APP will reminder to open bluetooth
device. IOS device did not open the bluetooth device, operating APP may cause APP automatically exit.
When IOS device display is opened, then can automatically synchronize data;If your IOS device
-
display screen is closed, you will not be able to synchronous data automatically.
- Manual sync: if you want to get the latest data, you also can manually synchronize the data. Open
the APP, click right side gear icon sign on the APP to enter setup interface, click the upper left corner
of the icon that can be manually sync data.
Connection with Android devices
The Pedometer need match connection with your Android device only by APP, it can't search by
your Android device to connect.
- Enter the APP equipment list, click refresh device, the APP will search near by the Pedometer, and put
searched P118 included in the equipment list
- In the equipment list, click devices which your need match, the APP will match with devices you
clicked, and automatically synchronize data
- Enter the personal Settings interface, setting up your information, click the "save" to storage your
information to the APP and synchronization to the Pedometer.
Remark: B.T Pedometer must be in the awake state, otherwise, click "save" only can store your information in the APP,
Until the next Successful sync to synchronize your information on your P118.
Synchronous data to Android devices
Automatic synchronization: the Pedometer can synchronize data directly to the Android device. Every
time open the APP, the APP will connect to the Pedometer immediately and synchronous data; every 30
minutes automatically synchronize data.
Remark: Android bluetooth devices must be in state of opening. If you do not open, the APP will reminder to open
bluetooth device. Android device did not open the bluetooth device, operating APP may cause APP automatically exit.
Brand Phone type Operating system
iPhone 4S IOS 6.0.0
iPhone 5 IOS 6.0.0
iPhone 5C IOS 6.0.0
iPhone
iPhone 5S
IOS 6.0.0
iPod IOS 6.0.0
iPad
IOS 6.0.0
Galaxy S3
Android 4.3
Galaxy S4
Android 4.3
Samsung Galaxy S5
Android 4.3
Note II Android 4.3
Note III
Android 4.3
Google
Nexus4/Nexus7 Android 4.3
