Installation instructions
Combination hob induction/gas
The fitting of the appliance should only be carried out by a authorised person/licensed gasfitter. Please read the safety regulations.
See the data plate for information regarding the total gas consumption, gas type and gas pressure.
Preparations for installation
Pictograms used
Important information
Gas connection
Electrical connection
This appliance must be earthed
The electrical connection must comply with national and local regulations.
Connected load
L1 (W)
L2 (W)
HIG1944
3700
3700
A (mm)
B (mm) C (mm) D (mm) E (mm)
HIG1944
904
522
54
oven
L3 (<W) Total load (W)
5
7400
A
B
C
265
180
Accessibility!
Free space around appliance
Rangehoods and exhaust fans shall be
installed in accordance with
manufacturers instructions.
For an overhead exhaust fan A>750 mm!
A (>mm) C (>mm) D (>mm)
E (> mm)
650
450
40
120
05
1/2" ISO 228 / 1/2" ISO 7-1
The gas connection must comply with national and local regulations.
The hotplate can be connected with rigid pipe as specified in
AS/NZS 5601.1current edition.
When the appliance is connected with a hose assembly,
the supply point shall be accessible with the appliance installed.
F
H
E
G
E/F
C
D
A (>mm) B (mm) C (mm) D (>mm) E (>mm) F (>mm) G (>mm) H (>mm)
HIG1944 600
860
490
60
oven
y
>60º C
x
<60º C
x
A
min.
B+D
D
B
C
E
A
B
40
50
66
100
Y:
metal
y
Gas supply valve
shall be accessible
X:
safety hose
Gas supply valve
shall be accessible
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Asko HIG1944MF
Summary of Contents for Asko HIG1944MF
- Page 1 Installation instructions Combination hob induction/gas The fitting of the appliance should only be carried out by a authorised person/licensed gasfitter. Please read the safety regulations. See the data plate for information regarding the total gas consumption, gas type and gas pressure. Preparations for installation Pictograms used Free space around appliance...
