Samsung SV-A10G Service Manual

Vhs video cassette player.
Hide thumbs

Advertisement

SERVICE
For mechanical disassembly and adjustment, refer to the "Mechanical Manual"
(DX7-R/DX-7RC, DX8-R/DX-8RC
VIDEO CASSETTE PLAYER
SV-A10G/SP-A10G
SVR-17A/SPR-17A
SV-A11G/SP-A11G
SVR-17B/SPR-17B
© Samsung Electronics Co., Ltd. FEB. 1997
VIDEO CASSETTE PLAYER
SV-A10G/SP-A10G
SV-A11G/SP-A11G
SVR-17A/SPR-17A
SVR-17B/SPR-17B
AC68-20316A).
9. PCB Diagrams
Manual
CONTENTS
AC68-20327A
PAL

Advertisement

Chapters

Table of Contents

   Related Manuals for samsung SV-A10G

   Summary of Contents for samsung SV-A10G

  • Page 1: Table Of Contents

    4. Disassembly and Reassembly SV-A10G/SP-A10G 5. Alignment and Adjustment SVR-17A/SPR-17A 6. Exploded View and Parts List 7. Electrical Parts List 8. Block Diagrams 9. PCB Diagrams SV-A11G/SP-A11G SVR-17B/SPR-17B 10. Wiring Diagram 11. Schematic Diagrams © Samsung Electronics Co., Ltd. FEB. 1997 AC68-20327A...
  • Page 2: Precautions

    Alternatively, wear a discharging Wrist-strap device. (Be sure to remove it prior to applying power--this is an electric shock precaution.) Samsung Electronics...
  • Page 3 Always inspect for pinched, out- of-place, or frayed wiring. Do not change the spacing between components and the printed circuit board. Check the AC power cord for damage. Make sure that leads and components do not touch thermally hot parts. Samsung Electronics...
  • Page 4 Note : Accurate repair may not be possible due to external noise between the deck assÕy and main PCB. 2-1-2 Servicing Jig Jig Item Part No. X-5 Chassis Jig 68140-500-013 Connects the deck ass’y to the main PCB connecting cable. Samsung Electronics...
  • Page 5 9. If the test tape is ejected while the jig is in use, attempt to re-load the tape by simultaneously 6. Apply power to the function PCB. touching the start and end sensor LEDs. 7. Insert a test tape into the housing assÕy. Samsung Electronics...
  • Page 6: Reference Information

    CONNECTS TO THE MAIN PCB CN601. CONNECTS TO THE CAPSTAN MOTOR CONNECTOR OF DECK ASS'Y. CONNECTS TO THE LOADING MOTOR CONNECTOR OF DECK ASS'Y. DECK ASS'Y MAIN BOARD CN604 OPTION CN606 CN601 1 SCREW (1-3X10) 2 SCREWS (2-3X10) Samsung Electronics...
  • Page 7 Reference Information 2-2 IC Blocks 2-2-1 IC601 (KS88C8016) Samsung Electronics...
  • Page 8 Reference Information 2-2-2 IC301 (SS11501M) Samsung Electronics...
  • Page 9 Reference Information 2-2-3 IC302 (LA7411) Samsung Electronics...
  • Page 10 Reference Information 2-2-4 IC303 (SS23378M) Samsung Electronics...
  • Page 11 Reference Information MEMO Samsung Electronics...
  • Page 12: Product Specifications

    Power Requirement AC 100 ~ 240V 50/60Hz, DC 12V (CAR BATTERY ONLY) Power Consumption Approx. 17 watts Operation Temperature 41°F-104°F (5°C-40°C) Operation Humidity 10%-75% Weight 4.0 Kg Dimensions (W x H x D) 360 x 92 x 309 mm Samsung Electronics...
  • Page 13 Product Specifications 3-2 Comparison Chart FUNCTION LINE RECORD REMARK MODEL SV-A10G SV-A11G SP-A10G SP-A11G SVR-17A SVR-17B SPR-17A SPR-17B Samsung Electronics...
  • Page 14: Disassembly And Reassembly

    4-1 Cabinet Assembly Note : Disassemble in the order shown. Reassemble in reverse order. 4-1-1 Top Cabinet removal 1. Remove 5 screws and slide the top cabinet to the rear to remove. REMOVE 5 SCREWS Fig. 4-1 Top Cabinet removal Samsung Electronics...
  • Page 15 Disassembly and Reassembly 4-1-2 Bottom cover removal 1. Remove 1 screw. 2. Lift up the bottom cover toward arrow ÒAÓ. SV-A10G/SP-A10G/SVR-17A/SPR-17A REMOVE 1 SCREW (BH;1-3X12 YELLOW) "A" LIFT UP THE BOTTOM COVER IN THE DIRECTION ARROW "A" SV-A11G/SP-A11G/SVR-17B/SPR-17B REMOVE 1 SCREW (BH;1-3X12 YELLOW)
  • Page 16 2. Release 4 hooks on the top side and 3 hooks on the bottom side and then, pull the assÕy front panel to remove. RELEASE 4 TABS (Top view) RELEASE 3 TABS (Bottom view) Fig. 4-3 Ass’y Front Panel removal Samsung Electronics...
  • Page 17 Disassembly and Reassembly 4-1-4 Ass’y Function removal 1. Release 5 hooks and remove the assÕy function. Note : Take extreme care not to damage the PCB when removing it. SV-A10G/SP-A10G/SVR-17A/SPR-17A RELEASE 4 TABS SV-A11G/SP-A11G/SVR-17B/SPR-17B RELEASE 4 TABS Fig. 4-4 Ass’y Function Removal...
  • Page 18 REMOVE 2 SCREWS (BH;2-3X12 YELLOW) (BH;2-3X12 YELLOW) ASS'Y FULL DECK REMOVE 2 SCREWS CONNECTOR BOARD ASS'Y (BH;2-3X12 YELLOW) ASS'Y MAIN FRAME RELEASE 2 HOOKS REMOVE 2 SCREWS REMOVE 2 SCREWS (BH;2-3X12 YELLOW) (BH;2-3X12 YELLOW) Fig. 4-5 Chassis Removal Samsung Electronics...
  • Page 19 Disassembly and Reassembly 4-2 Circuit Board Locations SV-A10G/SP-A10G/SVR-17A/SPR-17A Fig. 4-6 Circuit Board Locations (SV-A10G/SP-A10G) Samsung Electronics...
  • Page 20 Disassembly and Reassembly SV-A11G/SP-A11G/SVR-17B/SPR-17B Fig. 4-6 Circuit Board Locations (SV-A11G/SP-A11G) Samsung Electronics...
  • Page 21 Disassembly and Reassembly MEMO Samsung Electronics...
  • Page 22: Alignment And Adjustment

    SCREW(C) AZIMUTH ADJUST TILT ADJUST TP3 : CTL PULSE X-POSITION ADJUST GEAR TP5 : ENVELOPE HOLE TP6 : AUDIO OUT SCREW(A) SCREW(D) HEIGHT ADJUST X-POINT LOCKING Fig. 5-4 Location of A/C Head adjustment screw Fig. 5-3 PCB Layout Samsung Electronics...
  • Page 23: Electrical Adjustment

    CH-2 to TP7. 4. Adjust VR601 so that the head switching point is positioned 6.5 ± 0.5H from the V-SYNC left edge as shown. SW25HZ SWITCHING POINT PULSE CH-2 CH-1 VIDEO OUT 6.5H 0.5H (Main PCB - Component Side) Samsung Electronics...
  • Page 24 ACTION MODE EJECT EJECT CASSETTE IN CASSETTE IN UNLOAD UNLOAD R. PS R. PS, Z-R. PS R. SLOW PINCH ROLLER OFF POSITION STILL STILL PLAY PB, T-STOP, REC, PAUSE, F. PS, Z-FPS STOP STOP, POWER OFF FF/REW FF, REW Samsung Electronics...
  • Page 25 Alignment and Adjustment MEMO Samsung Electronics...
  • Page 26 Mechanical Parts (Bottom Side) - - - - - - - - - - - - - Housing Assembly - - - - - - - - - - - - - - - - - - - - - - - Samsung Electronics...
  • Page 27 SC301 PT601A S.N.A LD601A PT602A SV-A10G/SP-A10G SVR-17A/SPR-17A S601A 601(S.N.A) S602A 670(S.N.A) SV-A11G/SP-A11G SVR-17B/SPR-17B S.N.A : SERVICE NOT AVAILABLE...
  • Page 28: Exploded View And Parts List

    (TSEC LOCAL) S601A AC61-22321A HOLDER-TR;POM,-,-,-,-,- S602A AC61-22321A HOLDER-TR;POM,-,-,-,-,- SC301 AC63-42222A SHIELD-CASE P/AMP(AS;3516ET,T0.3,SIL,SV-80Z,- (TSEC LOCAL) Note : Location number 1, 21 are only for model SV-A10G/SVR-17A/CIS (SMSC, SALSC, SUSC). Please, refer to the separate information for the other models combind. Samsung Electronics...
  • Page 29 T220 T221 T300 T303 T224 T216 T233 T302 DX7-R DX7-RC T204 DX8-R DX8-RC T237 T222 T230 T228 T309 T229 T218 T201 T231 T203 T207 T209 T212 T234 T219 T240 T233 T217 T238 T239 T232 T225 T210 T227 T208 T226 T236 T211 T223 T202...
  • Page 30 (TSEC LOCAL) T238 AC61-60132A SPRING ARM PINCH;CS,SUS304WPB,PI0.4,D7.1,OD7.9, T239 AC66-30132A LEVER JOG-ASSY;-,-,-,-.X5,- (DX8-R/RC ONLY) T240 AC61-60505A SPRING-REC S/W;-,ES,SUS304 WPB,PI0.29,PI3.5,- T300 AC96-10011L ASSY-CYLINDER;CX5-S2P/DLC,- (TSEC LOCAL) T302 AC31-12001M MOTOR-CYLINDER;E20XL03,-,- (TSEC LOCAL) T303 AC33-12004S HEAD-BRUSH(ASSY);SECC20/20+CARBON,-,-,-,- (TSEC LOCAL) T309 AC73-12001A RETRINER-RUBBER(ASSY);SECC+SILICON,-,-,- (TSEC LOCAL) Samsung Electronics...
  • Page 31 B257 B256 B255 B258 B254 B261 B264 B251 B263 B268 B267 B266 B265 B259 B253 B260 B252 B262...
  • Page 32 LEVER- SHIFT;PBT2002K,T10.9,L35,-,-,- B262 AC66-30012A LEVER- IDELR CHANGE;PBT330,T3.3,L50,-,W6.0,- (TSEC LOCAL) B263 AC61-60111A SPRING-LEVER SHIFT;TS,SWPB,PI0.7,D5.5,L13.8(OD6.9 B264 AC59-90001A UNIT-LOADING ASSY;X-5,-,- (TSEC LOCAL) B265 66823-0060-00 MOTOR-LOADING ASSY;POM+RF370C X-5 B266 AC66-20039A GEAR- WORM LO;PBT 2002K,-,-,-,D4.5,3,- B267 AC61-20224A HOLDER SHAFT;POM M90-44,T1.25,NAT,PI5XH5.5, B268 AC66-30149A BRAKE CAPSTAN-ASSY;POM,-,-,-,X5,- Samsung Electronics...
  • Page 33 Exploded View and Parts List 6-4 Housing Assembly H510 H520 H521 H533 H522 H530 H526 H532 H524 H531 H535 H540 H545 H544 H541 H550 H542 H543 H500 Samsung Electronics...
  • Page 34 CHASSIS- SIDE R;ABS HF-380,-,T10,BLK,-,X5,BLK (TSEC LOCAL) H542 AC66-80008A SLIDER DAMPER;LUCEL N109-LD,T4,L87,-,-,- (TSEC LOCAL) H543 AC61-60120A SPRING-SLIDE DAMPER;ES,SUS 304WPB,PI0.4,D3.8,L25(O (TSEC LOCAL) H544 AC66-30016A LEVER- LID OPENER;LUCEL N109-LD,T5.0,L34.7,W16.6 (TSEC LOCAL) H545 AC61-60123A SPRING-LID OPENER;TS,SWPB,PI0.55,D8.9,L15(OD10), (TSEC LOCAL) H550 61403-0073-00 SHAFT-ARM(ASSY);SUM24L X5FL0405A X-5 (TSEC LOCAL) Samsung Electronics...
  • Page 35 Exploded View and Parts List MEMO 6-10 Samsung Electronics...
  • Page 36: Electrical Parts List

    D1P03 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41 D1P06 0401-000101 DIODE-SWITCHING;1N4148,100V,200MA,500MW,4NS,DO D1P20 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41 D1S01 0402-001009 DIODE-RECTIFIER;1SR139,600V,1A,MSR D1S02 0402-001009 DIODE-RECTIFIER;1SR139,600V,1A,MSR D1S03 0402-001009 DIODE-RECTIFIER;1SR139,600V,1A,MSR D1S04 0402-001009 DIODE-RECTIFIER;1SR139,600V,1A,MSR D1S05 0402-000378 DIODE-RECTIFIER;EG01C,1000V,500MA,DO-41 D1S07 0402-001013 DIODE-RECTIFIER;1SR153-400,400V,800MA,DO-41 D1S31 0402-001013 DIODE-RECTIFIER;1SR153-400,400V,800MA,DO-41 D1S32 0402-001069 DIODE-RECTIFIER;RL10Z,200V,2A,DO,TP D1S33 0402-001069 DIODE-RECTIFIER;RL10Z,200V,2A,DO,TP 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41 Samsung Electronics...
  • Page 37 ZD1P02 0403-000557 DIODE-ZENER;MTZ5.1C,5.1V,5.09-5.37V,500MW, ZD1S1 0403-000539 DIODE-ZENER;MTZ18C,18V,17.42-18.33V,500MW, ZD1S2 0403-000294 DIODE-ZENER;MTZ4.7B,4.7V,4.55-4.80V,500MW, SYSTEM CONTROL/SERVO PARTS BD501 3301-000297 CORE-FERRITE BEAD;AA,3.6X1.2X5.7MM,1400,2900G BD601 3301-000297 CORE-FERRITE BEAD;AA,3.6X1.2X5.7MM,1400,2900G BD602 3301-000297 CORE-FERRITE BEAD;AA,3.6X1.2X5.7MM,1400,2900G BD605 AC27-92001B COIL-PEAKING AXIAL;BAL04ST101K,-,-,-,- C601 2202-000807 C-CERAMIC,MLC-AXIAL;22NF,+80-20%,25V,Y5V,3.5X19, (TSEC LOCAL) C602 2202-000797 C-CERAMIC,MLC-AXIAL;10NF,30%,16V,Y5P,3.5X19,-,TP (TSEC LOCAL) Samsung Electronics...
  • Page 38 C-CERAMIC,MLC-AXIAL;100NF,+80-20%,50V,Y5V,3.5X19 (TSEC LOCAL) C660 2202-000780 C-CERAMIC,MLC-AXIAL;100NF,+80-20%,50V,Y5V,3.5X19 (TSEC LOCAL) C6601 2401-001975 C-AL;47UF,20%,16V,GP,5X11MM,5,TP C6602 2401-001912 C-AL;1UF,20%,50V,GP,5X11MM,2MM,BK (TSEC LOCAL) C661 2202-000797 C-CERAMIC,MLC-AXIAL;10NF,30%,16V,Y5P,3.5X19,-,TP (TSEC LOCAL) C662 2401-001895 C-AL;100UF,20%,16V,GP,6.3X11MM,2.5M C663 2202-000279 C-CERAMIC,MLC-AXIAL;47PF,5%,50V,SL,3.5X19,-,TP (TSEC LOCAL) CN601 3711-002445 CONNECTOR-HEADER;BOX,2P,2R,1.5MM,STRAIGHT,SN CN602 3710-000546 CONNECTOR-SOCKET;20P,1R,1.5MM,ANGLE,SN CN603 3710-000546 CONNECTOR-SOCKET;20P,1R,1.5MM,ANGLE,SN Samsung Electronics...
  • Page 39 (TSEC LOCAL) R6020 2001-000924 R-CARBON;680OHM,5%,1/8W,AA (REC OPTION) (TSEC LOCAL) R6024 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA (PB OPTION) (TSEC LOCAL) R6025 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA (REC OPTION) (TSEC LOCAL) R603 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM (TSEC LOCAL) R6030 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M (TSEC LOCAL) R604 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM (TSEC LOCAL) Samsung Electronics...
  • Page 40 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M (TSEC LOCAL) R6605 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M (TSEC LOCAL) R6606 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M (TSEC LOCAL) R6607 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M (TSEC LOCAL) R661 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M (TSEC LOCAL) R662 2001-000633 R-CARBON;30KOHM,5%,1/8W,AA,TP,1.8X3.2MM (TSEC LOCAL) R663 2001-000954 R-CARBON;750KOHM,5%,1/8W,AA,TP,1.8X3.2M (TSEC LOCAL) R664 2001-000011 R-CARBON;75KOHM,5%,1/8W,AA,TP,1.8X3.2MM (TSEC LOCAL) Samsung Electronics...
  • Page 41 C-CERAMIC,MLC-AXIAL;100PF,10%,50V,Y5P,3.5X19,-,T (TSEC LOCAL) C303 2202-000243 C-CERAMIC,MLC-AXIAL;33PF,5%,50V,SL,3.5X19,-,TP (TSEC LOCAL) C304 2202-000243 C-CERAMIC,MLC-AXIAL;33PF,5%,50V,SL,3.5X19,-,TP (TSEC LOCAL) C305 2202-000797 C-CERAMIC,MLC-AXIAL;10NF,30%,16V,Y5P,3.5X19,-,TP (TSEC LOCAL) C306 2202-000780 C-CERAMIC,MLC-AXIAL;100NF,+80-20%,50V,Y5V,3.5X19 (TSEC LOCAL) C309 2202-000797 C-CERAMIC,MLC-AXIAL;10NF,30%,16V,Y5P,3.5X19,-,TP (TSEC LOCAL) C310 2202-000797 C-CERAMIC,MLC-AXIAL;10NF,30%,16V,Y5P,3.5X19,-,TP (TSEC LOCAL) C311 2202-000797 C-CERAMIC,MLC-AXIAL;10NF,30%,16V,Y5P,3.5X19,-,TP (TSEC LOCAL) Samsung Electronics...
  • Page 42 2401-001912 C-AL;1UF,20%,50V,GP,5X11MM,2MM,BK (TSEC LOCAL) C370 B1102-0113 C-FILM;CQ 922 P 100V 473-J CQ298PVT473J ECQV473J C371 2202-000780 C-CERAMIC,MLC-AXIAL;100NF,+80-20%,50V,Y5V,3.5X19 (TSEC LOCAL) C372 2401-001975 C-AL;47UF,20%,16V,GP,5X11MM,5,TP (TSEC LOCAL) C373 2202-000780 C-CERAMIC,MLC-AXIAL;100NF,+80-20%,50V,Y5V,3.5X19 (TSEC LOCAL) C374 2401-000419 C-AL;10UF,20%,16V,GP,5X11,5,- (TSEC LOCAL) C375 2202-000243 C-CERAMIC,MLC-AXIAL;33PF,5%,50V,SL,3.5X19,-,TP (TSEC LOCAL) Samsung Electronics...
  • Page 43 COIL-PEAKING AXIAL;BAL04ST101K,-,-,-,- Q302 0501-000303 TR-SMALL SIGNAL;KSA733-Y,PNP,250MW,TO-92,-,120 Q303 0501-000303 TR-SMALL SIGNAL;KSA733-Y,PNP,250MW,TO-92,-,120 Q304 0501-000398 TR-SMALL SIGNAL;KSC945-Y,NPN,250MW,TO-92,TP,12 Q306 0504-000203 TR-DIGITAL;KSR1004,NPN,300MW,47K-47K,TO-9 Q307 0504-000203 TR-DIGITAL;KSR1004,NPN,300MW,47K-47K,TO-9 Q309 0501-000398 TR-SMALL SIGNAL;KSC945-Y,NPN,250MW,TO-92,TP,12 Q310 0501-000303 TR-SMALL SIGNAL;KSA733-Y,PNP,250MW,TO-92,-,120 Q312 0501-000398 TR-SMALL SIGNAL;KSC945-Y,NPN,250MW,TO-92,TP,12 Q313 0504-000203 TR-DIGITAL;KSR1004,NPN,300MW,47K-47K,TO-9 Q3A01 0501-000398 TR-SMALL SIGNAL;KSC945-Y,NPN,250MW,TO-92,TP,12 Samsung Electronics...
  • Page 44 R-CARBON;330KOHM,5%,1/8W,AA,TP,1.8X3.2M (TSEC LOCAL) R3A16 2001-000331 R-CARBON;12KOHM,5%,1/8W,AA,TP,1.8X3.2MM (TSEC LOCAL) R3A17 2001-000802 R-CARBON;5.6KOHM,5%,1/8W,AA,TP,1.8X3.2M (TSEC LOCAL) R3A18 2001-000718 R-CARBON;4.3KOHM,5%,1/8W,AA,TP,1.8X3.2M (TSEC LOCAL) R3A19 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2M (TSEC LOCAL) R3A20 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM (TSEC LOCAL) R3A24 2001-000454 R-CARBON;2.2MOHM,5%,1/8W,AA,TP,1.8X3.2M (TSEC LOCAL) R3A26 2001-000878 R-CARBON;6.2KOHM,5%,1/8W,AA,TP,1.8X3.2M (TSEC LOCAL) Samsung Electronics...
  • Page 45 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM (TSEC LOCAL) R413 2001-000904 R-CARBON;620OHM,5%,1/8W,AA,TP,1.8X3.2MM (TSEC LOCAL) R414 2001-000969 R-CARBON;75OHM,5%,1/8W,AA (REC OPTION) (TSEC LOCAL) R419 2001-000508 R-CARBON;220KOHM,5%,1/8W,AA (REC OPTION) (TSEC LOCAL) R450 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M (TSEC LOCAL) R451 2001-000554 R-CARBON;270OHM,5%,1/8W,AA,TP,1.8X3.2MM (TSEC LOCAL) AC40-20100C RF-MODULATOR;ENC479N8,PAL-BG/DK (TSEC LOCAL) 7-10 Samsung Electronics...
  • Page 46 (TSEC LOCAL) R716 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM (TSEC LOCAL) R717 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3.2MM (TSEC LOCAL) RM701 B1294-0076 MODULE-REMOCON;GP1U281R/SHARP 38KHZ SW701 3404-000240 SWITCH-TACT;15V,20MA,160+-50GF,6X6MM,- SW702 3404-000240 SWITCH-TACT;15V,20MA,160+-50GF,6X6MM,- SW703 3404-000240 SWITCH-TACT;15V,20MA,160+-50GF,6X6MM,- SW704 3404-000240 SWITCH-TACT;15V,20MA,160+-50GF,6X6MM,- SW705 3404-000240 SWITCH-TACT;15V,20MA,160+-50GF,6X6MM,- SW706 3404-000240 SWITCH-TACT;15V,20MA,160+-50GF,6X6MM,- SW707 3404-000240 SWITCH-TACT;15V,20MA,160+-50GF,6X6MM,- 7-11 Samsung Electronics...
  • Page 47 LED-IR;ROUND,5MM,150MW,5V,940NM,BK (TSEC LOCAL) QT01 0501-000534 TR-SMALL SIGNAL;2SC2412K,NPN,200MW,SOT-23,TP,1 (TSEC LOCAL) RT01 2007-000483 R-CHIP;1OHM,5%,1/10W,DA,TP,2012 (TSEC LOCAL) XT01 64539-102-311 CERAMIC RESONATOR;CSB455EBL/KBR455BKTL Note : ASSÕY REMOCON is only SV-A10G/CIS, SVR-17A. Please, refer to the separate information for the other models combind. 7-12 Samsung Electronics...
  • Page 48: Block Diagrams

    System Control - - - - - - - - - - - - - - - - - - - - - - - - - Video - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Samsung Electronics...
  • Page 49 Block Diagrams Overall Block Diagram ASS'Y MAIN ASS'Y FULL DECK ASS'Y FUNCTION Samsung Electronics...
  • Page 50 Block Diagrams System Control/Servo Samsung Electronics...
  • Page 51 Block Diagrams Audio/Video Samsung Electronics...
  • Page 52: Wiring Diagram

    10. Wiring Diagram ASS'Y MAIN Samsung Electronics 10-1...
  • Page 53: Schematic Diagrams

    Function - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 11-8 11-6 Remote-Control - - - - - - - - - - - - - - - - - - - - - - - Samsung Electronics 11-1...
  • Page 54: Block Identification Of Main Pcb

    Important safety notices : Components identified with the mark ! have the special characteristics for safety. When replacing any of these components. Use only the same type. 3 Block Identification of Main PCB (Component Side) (Conductor Side) 11-2 Samsung Electronics...
  • Page 55: S.m.p.s/power

    Schematic Diagrams 11-1 S.M.P.S/POWER Samsung Electronics 11-3...
  • Page 56: System Control/servo

    Schematic Diagrams CAPSTAN SPEED CONTROL CYLINDER SPEED CONTROL 11-2 System Control/Servo CAPSTAN PHASE CONTROL CYLINDER PHASE CONTROL 11-4 Samsung Electronics...
  • Page 57: Audio/video

    Schematic Diagrams PB Y PROCESS REC Y PROCESS PB AUDIO PROCESS 11-3 Audio/Video PB C PROCESS REC C PROCESS REC AUDIO PROCESS Samsung Electronics 11-5...
  • Page 58 Schematic Diagrams PB VIDEO PROCESS REC VIDEO PROCESS 11-4 PB AUDIO PROCESS REC AUDIO PROCESS 11-6 Samsung Electronics...
  • Page 59: Function

    Schematic Diagrams 11-5 Function Samsung Electronics 11-7...
  • Page 60: Remote-control

    Schematic Diagrams 11-6 Remote-Control 11-8 Samsung Electronics...
