Secoh JDK-30 Maintenance Manual

Linear compressors

Advertisement

LINEAR COMPRESSORS
MODEL
READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
KEEP THIS MANUAL FOR FUTURE REFERENCE.
SECOH SHANGHAI MEC LTD
MANUAL
FOR
: JDK-20
JDK-30
JDK-40
JDK-50

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JDK-30 and is the answer not in the manual?

Questions and answers

Summary of Contents for Secoh JDK-30

  • Page 1 MANUAL LINEAR COMPRESSORS : JDK-20 MODEL JDK-30 JDK-40 JDK-50 READ AND FOLLOW ALL SAFETY INSTRUCTIONS. KEEP THIS MANUAL FOR FUTURE REFERENCE. SECOH SHANGHAI MEC LTD...
  • Page 2: Parts Name

    Parts name Truss head screw Filter cover Filter element Inlet Overall Cover Outlet L-joint Hose Hose Clamp (2pcs) Power supply cord...
  • Page 3: Periodic Maintenance

    Periodic maintenance ○ Always disconnect power before servicing. Failure to do so could result in electrical shock, personal injury or death. ○ Clean the filter element quarterly. A clogged filter element can cause overheating or pump failure. Filter cover Filter element cleaning Filter element ○...
  • Page 4 ○ Undo the screws (B) and remove the holder Holder cover cover. (Ref: Fig 2-C) ○ Undo the screws (C) and replace the valve box of both sides. (Ref: Fig 2-C) ○ Undo the nuts (D) and remove diaphragm Overall cover holders and diaphragms from the magnet.
  • Page 5: Troubleshooting

    Trouble shooting Observation Possible cause Action ・ Improper electrical ・ Check plug and outlet Pump does not operate. connection and plug completely. Discharge air decreased. ・ Pipe or diffuser clogged ・ Clean pipe or diffuser. Pump surface ・ Valve in plumbing shut ・...
