Canon ZR930 Quick Start Manual

MiniDV Cam: Canon ZR930
Quick Start Guide Index:
p. 2) "AV" Settings; Load DV Tape
p. 3) Record Video
p. 4) Play Video—in Camera; on TV
p. 5) Recharge Battery; AC Power
p. 6) MiniDV to PC—User Transfer
Only
For other ZR930 features, ask AV Services—you may check out
the ZR930 manual.
AV Services: (919) 966-6536, Rosenau 233
Mon.–Fri., 8:00
Record Video
p. 3)
1. Turn ZR930 on: Hold green "unlock" button on POWER switch
and rotate POWER switch clockwise to CAMERA;
2. Open the lens cover by sliding down the lens cover switch;
3. Open the LCD panel 90° (or, leave closed to use the viewfinder);
4. Aim camera; focus is automatic. For added stability, use a tripod;
5. Start recording—press white start/stop button. Audio level sets
automatically;
6. Stop recording—press the white start/stop button again;
7. If finished, close panel and lens cover; turn POWER OFF.
POWER
switch
1 2
Opened
–5:00
AM PM
Start/stop button
3, 4, 5
"AV Default" Settings; Load MiniDV Tape
p. 2)
MiniDV cam "AV Default" settings for Canon ZR930:
A) EASY (autofocus/exposure); B) Tape speed: SP (Standard); C)
Screen width: Normal/TV; D) Battery record time: ≈ 50 minutes
w./full charge); E) Auto Power Off: 5 min.; F) Zoom speed: medium.
Load the miniDV tape; use only tapes labeled with
1. A) Slide the OPEN/EJECT button, and, as shown, B) tilt the cassette
compartment cover out. The cassette compartment will pop up.
(Note that for this action, you must have battery or AC power.);
2. Gently slide the miniDV tape into the cassette compartment, as shown;
3. Close the cassette compartment only by pushing it closed as shown—
the "push spot" is labeled PUSH. (The cassette compartment will then
retract, loading the tape.) Manually close the cover.
1 2
A
B
Play Videotape—in Camera...
p. 4)
1. Turn ZR930 on: Hold green "unlock" button on POWER switch
and rotate POWER switch counterclockwise to PLAY;
2. Open the LCD panel 90°;
3. Joystick image should appear on viewscreen. (If not, press Joystick.)
■
Use Joystick to Play ►, Stop
Forward tape ► ► , as per image on screen.
1 2
5, 6
Joystick
→
3
, Pause II, Rewind ◄◄ , and Fast
or on a TV Set
4. Follow steps 1–3 to
3
set up Cam for play;
5. Connect AV Cable
miniplug to Cam, as
shown;
6. Connect
yellow/white/red
"RCA" plugs to TV;
7. Use Joystick to
control playback.
