Crestron FreeSpeech MP-FSMIC Installation Manual

Crestron MP-FSMIC
FreeSpeech™ Wireless Microphone
Installation Guide
Further Inquiries
If you cannot locate specific information or have questions after reviewing this
guide, please take advantage of Crestron's award winning customer service
team by calling Crestron at 1-888-CRESTRON [1-888-273-7876]. For
®
assistance in your region, please refer to the Crestron Web site
(www.crestron.com) for a listing of Crestron worldwide offices.
You can also log onto the online help section of the Crestron Web site
ww.crestron.com/onlinehelp) to ask questions about Crestron products.
First-time users will need to establish a user account to fully benefit from all
available features.
Future Updates
As Crestron improves functions, adds new features and extends the
capabilities of the MP-FSMIC, additional information may be made available as
manual updates. These updates are solely electronic and serve
as intermediary supplements prior to the release of a complete technical
documentation revision.
Check the Crestron Web site periodically for manual update availability and its
relevance. Updates are identified as an "Addendum" in the Download coumn.
Crestron Electronics, Inc.
15 Volvo Drive Rockleigh, NJ 07647
Tel: 888.CRESTRON
Fax: 201.767.7576
www.crestron.com
Regulatory Compliance
As of the date of manufacture, the MP-FSMIC has been tested and found to comply with
specifications for CE marking and standards per EMC and Radiocommunications Compliance
Labelling.
Installation Guide - DOC. 7166A
(2030245)
05.11
Specifications subject to
change without notice.
DESCRIPTION
Crestron FreeSpeech™ systems provide a very simple and affordable
solution for adding speech reinforcement as part of a complete classroom
media presentation system. Compact and lightweight, the MP-FSMIC can be
clipped to a lapel, hung around the neck, or placed in a tabletop stand*. As
part of a complete FreeSpeech wireless mic system, the MP-FSMIC affords
reliable and hassle-free operation. Simply press the ON button and go.
Advanced FreeSpeech RF/IR wireless technology ensures consistent
performance with complete freedom of movement — and minimized risk of
noise or feedback. The infrared "beacon" signal prevents interference
between multiple FreeSpeech systems in adjacent rooms, and even shuts
the mic off automatically if the instructor leaves the room with the mic on.
An internal rechargeable battery provides six hours of usage to last a full
school day. Recharging for up to two MP-FSMICs is handled by the
MP-FSDS2 docking station*.
MP-FSMIC
*Item(s) sold separately or as part of a MP-FS100_PAK or MP-FS200_PAK system package.
SPECIFICATIONS
Specifications for the MP-FSMIC are listed in the following table.
MP-FSMIC Specifications
SPECIFICATION
Wireless Communication
RF 2.4 GHz ISM Device; 79 Channels FHSS (2402
to 2480 MHz)
IR 38 kHz
Range (typical) 50 ft (~15 m) indoor, subject to site-specific
conditions (requires MP-FS-RX1 or MP-FS-RX2
receiver)*
Battery
Battery Type Lithium Ion Polymer, 3.7 Volt, 180 mAh
Usage per Charge 6 hours
Charging Time 2 hours
Cycle life >500 cycles (80% capacity)
(Requires MP-FSDS2 docking station/charger)*
Environmental
Temperature 41° to 104° F (5° to 40° C)
Humidity 10% to 90% RH (non-condensing)
Enclosure Plastic, matte black, includes magnetic clip for
lapel or lanyard attachment
Dimensions
Height 2.10 in (54 mm)
Width 1.00 in (26 mm)
Depth 0.95 in (24 mm)
Weight 0.7 oz (20 g)
Included Accessory
MP-FS-LANYARD Lanyard for MP-FSMIC
Available Accessories
MP-FS-RX1 FreeSpeech Single-Channel Wireless Mic Receiver
MP-FS-RX2 FreeSpeech Dual-Channel Wireless Mic Receiver
MP-FS100_PAK FreeSpeech Single-Channel Wireless Mic System
Package
MP-FS200_PAK FreeSpeech Dual-Channel Wireless Mic System
Package
MP-FSDS2 FreeSpeech Dual Wireless Mic Docking Station/
Charger
MP-FSTTS Tabletop Stand for MP-FSMIC
*Item(s) sold separately or as part of a MP-FS100_PAK or MP-FS200_PAK system package.
