- Page 1 INSTALLATION, USE AND MAINTENANCE MANUAL Brio 250 Espresso Espresso Plus MDB Protocol English DOC. NO. H 162U 00 EDITION 1 03 01...
- Page 3 DICHIARAZIONE DI CONFORMITA’ DECLARATION OF CONFORMITY DÉCLARATION DE CONFORMITÉ KONFORMITÄTSERKLÄRUNG DECLARACIÓN DE CONFORMIDAD DECLARAÇÃO DE CONFORMIDADE VERKLARING VAN OVEREENSTEMMING INTYG OM ÖVERENSSTÄMMELSE OVERENSSTEMMELSESERKLÆRING YHDENMUKAISUUSTODISTUS Valbrembo, 03/05/2001 Dichiara che la macchina descritta nella targhetta di identificazione, è conforme alle disposizioni legislative delle direttive: 89/392, 89/336, 73/23 CEE e successive modifiche ed integrazioni.
-
Page 5: Table Of Contents
ADJUSTING THE BREWING CHAMBER VOLUMEPAGE 12 HYDRAULIC SYSTEM PAGE 23 ADJUSTING THE GRADE OF GRINDING PAGE 12 ADJUSTING THE COFFEE DOSE PAGE 12 PROGRAMMING MENU SUMMARY PAGE 24 WATER TEMPERATURE CONTROL PAGE 12 WIRING DIAGRAM PAGE 33 © by NECTA VENDING SOLUTIONS SpA 0301 162-00... -
Page 6: Introduction
Any other use is unsuitable and thus potentially dangerous. Fig. 1 Product code Serial number Model Frequency Type Operating voltage Current Absorbed power Water mains characteristics Boiler data © by NECTA VENDING SOLUTIONS SpA 0301 162-00... -
Page 7: Positioning The Vending Machine
Suitable for cups with a rim diameter of 73-74 mm. with a capacity of approximately 250 cups. COIN MECHANISM The machine is supplied with provisions for the installation of payment systems with MDB protocol. © by NECTA VENDING SOLUTIONS SpA 0301 162-00... -
Page 8: Power Consumption
Pump from a point of view of both electrical safety and health Electric mixers regulations. - Fuse protection for: Electronic card power supply transformer Executive power supply transformer © by NECTA VENDING SOLUTIONS SpA 0301 162-00... -
Page 9: Installation
The menu and instruction labels, as well as the self- adhesive labels to identify the product containers, are supplied with the machine and must be inserted or at- tached at the time of installation (see "selection dose" table). © by NECTA VENDING SOLUTIONS SpA 0301 162-00... -
Page 10: Connecting To The Power Supply
BILITY FOR ANY DAMAGE CAUSED BY NONCOMPLI- To energize the system with the door open, simply insert ANCE WITH THE ABOVE MENTIONED SAFETY RULES. the special key into the slot (see Fig. 7). 0301 162-00 © by NECTA VENDING SOLUTIONS SpA... -
Page 11: Filling The Water System
This operation must be carried out manually in ALL ing conduit; VERSIONS after any maintenance requiring the boiler - coffee dispensing spout; to be emptied but not the air-break. - sugar chute; - dispensing compartment. © by NECTA VENDING SOLUTIONS SpA 0301 162-00... -
Page 12: Loading
- fill the columns with cups ensuring that they are not ensure that all residue of the solution is removed. forced inside each other; - the central column must be filled last; - close the machine and make a test selection. 0301 162-00 © by NECTA VENDING SOLUTIONS SpA... -
Page 13: Loading Coffee
For safety reasons, when removing the tray a special 1 - Knurled nut switch installed on the left-hand side will cut off the power 2 - Spacer washer supply from the machine. 3 - Cup shifting arm © by NECTA VENDING SOLUTIONS SpA 0301 162-00... -
Page 14: Cleaning The Sugar Dispenser
- completely empty the water system using the special 1 - Sugar dispensing spout clamps. 2 - Pin 3 - Flexible lever 4 - Return spring 0301 162-00 © by NECTA VENDING SOLUTIONS SpA... -
Page 15: Operation Of The Brewer Unit
The weight of the instant products, the water dose and 6 - Swinging lever temperature are directly controlled by the microprocessor. To adjust them it is therefore necessary to follow the programming procedures. © by NECTA VENDING SOLUTIONS SpA 0301 162-00... -
Page 16: Standard Settings
For optimum results, it is advisable to vary the grade of - tightening will increase the temperature; grinding with the coffee grinder motor running. - loosening will decrease the temperature; - the temperature varies by approx. 1° C every 2 turns. 0301 162-00 © by NECTA VENDING SOLUTIONS SpA... -
Page 17: Maintenance
- remove the piston from the crosspiece; 4 - Upper piston snap ring 5 - Lower piston snap ring - remove the filter and the piston seal. 6 - Reference notches 7 - Ratiomotor handle pin © by NECTA VENDING SOLUTIONS SpA 0301 162-00... -
Page 18: Annual Sanitising
Selection disabled "Coffee sel. out" For espresso models only Brewer unit out of service "Empty tray" Number of coffee cycles reached "Take the drink" Drink ready "Only Dek available" Coffee bean hopper empty 0301 162-00 © by NECTA VENDING SOLUTIONS SpA... -
Page 19: Maintenance Mode
/fill tubes The function cannot be accessed when in program- ming mode. In that case it will be necessary to switch the machine off and on again. © by NECTA VENDING SOLUTIONS SpA 0301 162-00... -
Page 20: Programming
The machine will lock if the lack of water condition is not selections with jug facilities key signalled by the microswitch after 7 selections. "Set language" language of displayed messages 0301 162-00 © by NECTA VENDING SOLUTIONS SpA... -
Page 21: Setting The Water And Powder Doses
BILL VALIDATOR FAILURE The bill accepter is not working or does not communicate. CASHLESS FAILURE The key device or the magnetic card is not working or does not communicate. © by NECTA VENDING SOLUTIONS SpA 0301 162-00... -
Page 22: Setting The Basic Unit And The Decimal Point
Press the confirm button “ ” to display the current status; when pressing the change button “ ” the status starts blinking and can be changed with the “ ” and “ ” buttons. 0301 162-00 © by NECTA VENDING SOLUTIONS SpA... -
Page 23: Programming The Mdb Data
“full change tubes” blocked in order not to overflow the liquid waste tray, in the status. event the machine is not installed on a support cabinet. © by NECTA VENDING SOLUTIONS SpA 0301 162-00... -
Page 24: Direct Functions
- before confirming connect the printer; dispensed buttons on the coin mechanism. - press the confirm button “2” to start printing. 2- single selection counter 3 - failure counter 4 - single price counter normal discounted 0301 162-00 © by NECTA VENDING SOLUTIONS SpA... -
Page 25: Printed Board Functions And Indicator Lights
A relay card, fitted near the control board, is used in the to the following tables and to the selection dose table. "plus" model to control the decaffeinated doser device. © by NECTA VENDING SOLUTIONS SpA 0301 162-00... -
Page 26: Model Configuration
= MSP STIRRER RELEASE MOTOR = MSCB CUP COLUMN SHIFT MOTOR = EIA WATER INLET SOLENOID VALVE = MF2 INSTANT MIXERS 2 EXPANSION BOARD (model plus only) = MD5 DECAFFEINATED DOSER DEVICE 0301 162-00 © by NECTA VENDING SOLUTIONS SpA... -
Page 27: Hydraulic System
7 - Coffee unit 3 - By-pass 8 - Decaffeinated doser device (some models only) 4 - Vibration pump 9 - Boiler 5 - Mechanical filter 10 - Liquid waste tray overflow float © by NECTA VENDING SOLUTIONS SpA 0301 162-00... -
Page 28: Programming Menu Summary
Price N. 1 XXXX XXXX - 1 Price N. 8 PREVIOUS FUNCTION/ Set Prices/Sel. DECREASE DATA UNIT (- NEXT FUNCTION/ INCREASE DATA UNIT (+1) DELETE DATA/ EXIT FUNCTION CONFIRM DATA/ CONFIRM FUNCTION CHANGE DATA © by NECTA VENDING SOLUTIONS SpA 00301 162-00... - Page 29 Dec. point X + 1 Initialising Confirm? Working PREVIOUS FUNCTION/ Machine code DECREASE DATA UNIT (-1) NEXT FUNCTION/ INCREASE DATA UNIT (+1) DELETE DATA/ EXIT FUNCTION CONFIRM DATA/ CONFIRM FUNCTION CHANGE DATA 00301 162-00 © by NECTA VENDING SOLUTIONS SpA...
- Page 30 RAM. Fast/better dispensing Fast cycles OFF Fast cycles Selection counter PREVIOUS FUNCTION/ DECREASE DATA UNIT (- NEXT FUNCTION/ INCREASE DATA UNIT (+1) DELETE DATA/ EXIT FUNCTION CONFIRM DATA/ CONFIRM FUNCTION CHANGE DATA © by NECTA VENDING SOLUTIONS SpA 00301 162-00...
- Page 31 Maximum change Value = ##### XXXX XXXX - 1 PREVIOUS FUNCTION/ DECREASE DATA UNIT (-1) NEXT FUNCTION/ INCREASE DATA UNIT (+1) DELETE DATA/ EXIT FUNCTION Accepted coins CONFIRM DATA/ CONFIRM FUNCTION CHANGE DATA 00301 162-00 © by NECTA VENDING SOLUTIONS SpA...
- Page 32 Pre-grinding PREVIOUS FUNCTION/ DECREASE DATA UNIT (- NEXT FUNCTION/ INCREASE DATA UNIT (+1) DELETE DATA/ EXIT FUNCTION CONFIRM DATA/ CONFIRM FUNCTION CHANGE DATA © by NECTA VENDING SOLUTIONS SpA 00301 162-00...
- Page 33 Set washing Washing xx:xx Washing :xx Washing xx: Set band PREVIOUS FUNCTION/ DECREASE DATA UNIT (-1) NEXT FUNCTION/ INCREASE DATA UNIT (+1) DELETE DATA/ EXIT FUNCTION CONFIRM DATA/ CONFIRM FUNCTION CHANGE DATA 00301 162-00 © by NECTA VENDING SOLUTIONS SpA...
- Page 34 XXXX tray (plus models only) XXXX - 1 PREVIOUS FUNCTION/ DECREASE DATA UNIT (- NEXT FUNCTION/ INCREASE DATA UNIT (+1) DELETE DATA/ EXIT FUNCTION FAILURES LIST CONFIRM DATA/ CONFIRM FUNCTION CHANGE DATA © by NECTA VENDING SOLUTIONS SpA 00301 162-00...
- Page 35 DECREASE DATA UNIT (-1) NEXT FUNCTION/ Sel. N. 8 T= xxxx INCREASE DATA UNIT (+1) DELETE DATA/ EXIT FUNCTION CONFIRM DATA/ CONFIRM FUNCTION Sel. N. 8 D= xxxx CHANGE DATA DISPLAYING STATISTICS 00301 162-00 © by NECTA VENDING SOLUTIONS SpA...
- Page 36 Price 1 D = xxxx Price 8 D = In Service PREVIOUS FUNCTION/ DECREASE DATA UNIT (-1) NEXT FUNCTION/ INCREASE DATA UNIT (+1) DELETE DATA/ EXIT FUNCTION CONFIRM DATA/ CONFIRM FUNCTION CHANGE DATA DISPLAYING STATISTICS © by NECTA VENDING SOLUTIONS SpA 00301 162-00...
-
Page 37: Wiring Diagram
LAMP TRANSFORMER 230 V 24 V COFFEE UNIT MOTOR TX..DELAYED FUSE (X=COURRENT) GRINDER CUP SENSOR MD1-.. INGREDIENT MOTOR - INSTANT VARISTOR MDTE FRESH REA DOSER UNIT VENT INGREDIENT MOTOR - SUGAR © by NECTA VENDING SOLUTIONS SpA 0308 162-00... - Page 38 NECTA VENDING SOLUTIONS SpA Sx30504...
- Page 39 Brio Caffè 120V UL...
- Page 40 © by NECTA VENDING SOLUTIONS SpA NOTE...
- Page 41 © by NECTA VENDING SOLUTIONS SpA NOTE...
- Page 42 © by NECTA VENDING SOLUTIONS SpA NOTE...
- Page 43 The Manufacturer reserves the right to modify, without prior notice, the characteristics of the equipment described in this publication; and further declines to accept any responsibility for any inaccuracies contained in this publication which can be ascribed to printing and/or transcription errors. All instructions, drawings, tables and information contained in this publication are confidential and can neither be repro- duced completely or in part, nor be transmitted to third parties without the written permit of the Manufacturer, who has the sole ownership.
