1.0 Installation Overview

Please Note:
This product should only be installed by a qualifi ed electrician or
competent heating installer and should be in accordance with the
current edition of the IEEE wiring regulations.
GB

2.0 Product Specifi cation

Specifi cation
Power Supply
Switching Action
Switch Rating
Setting/Running Accuracy
Power Reserve
Max. Ambient Temperature
Dimensions, mm (W, H, D)
Design Standard
Control Pollution Situation
Rated Impulse Voltage
Ball Pressure Test

3.0 Installation

NB. For FRU units - go straight to point 6.
1. Loosen the fi xing screw in the base of the unit to release the
Wiring Cover.
2. Holding the unit face downwards, press fi rmly in the centre of
the wallplate and slide it apart and lift it from the module.
4
230Vac, ± 15%, 50 Hz
1 x SPST, Type 1B
264Vac, 50/60Hz, 3(1)A
±1 min./month
Minimum 24 hours
45°C
102 x 136 x 47
EN 60730-2-7
Degree 2
2.5kV
75°C
103E7
