  • Page 1 BF ENTRON LTD. Monitoring equipment Weld Analyser...
  • Page 2 M O N I T O R I N G E Q U I P M E N T Weld Analyser WA2 © BF ENTRON Ltd. Building 80 • The Pensnett Estate Kingswinford • West Midlands • DY6 7FQ Phone +44 (0)1384 455401 • Fax +44 (0)1384 455551 www.bfentron.co.uk...

  • Page 3: Table Of Contents

    File display ................... 12 Measuring welds ..............13 Capturing data with WA terminal ..........14 Installing WA terminal ..............16 Connecting your WA2 ..............17 USB port ..................17 Using WA Terminal ............... 20 Communications Port ..............21 Record Start/Stop ................. 21 Save ....................

  • Page 4: Introduction

    The WA2 is capable of measuring AC and MF DC welding current, the number of pulses in the weld and the duration of each weld. The information is displayed on a backlit FSTN LC display and may be stored in non-volatile EEPROM.

  • Page 5: Key Features

    I N T R O D U C T I O N Key features • Portable, hand-held compact unit • 128 x 64 LC display with yellow/green backlight and antiglare coating • Tactile keypad • Powered by three rechargeable AA batteries •...

  • Page 6: Specifications

    I N T R O D U C T I O N Specifications dimensions 85w x 30d x 170h mm weight 500 g including batteries operating temperature 0º to 45º C ambient power source three rechargeable NiMH AA batteries battery life 6 hours minimum, 2000mAh @ 25º...

  • Page 7: Installation

    + terminal to positive + terminal. • Switch off the WA2. • Ensure the charger is switched off. Connect it to the WA2 and switch the charger on. The red Power LED indicates that the charger is ready for use.

  • Page 8: Current Sensors

    I N S T A L L A T I O N • If the WA2 batteries are new or have only been used a few times, use the charger’s discharge mode before charging. Consult the charger’s documentation. • If the batteries are older or have been conditioned by the charger’s discharge cycle, the charger will fast charge the batteries and then revert to a trickle charge;...
  • Page 9 I N S T A L L A T I O N Connect the WA2 as shown below: Note that the joint current sensor can result reduced accuracy and the sensor should be orientated shown. sensor computer (optional) oscilloscope (optional)

  • Page 10: Connectors

    USB mini B cable if required. The USB device is provided by Future Technology Devices International Ltd. and Windows drivers are included on the WA2 companion CD. Updated drivers and drivers for Mac OS and Linux can be found on the FTDI website: http://www.ftdichip.com/Drivers/VCP.htm.

  • Page 11: Controls

    C O N T R O L S Section Controls Operating the WA2 he WA2 is controlled via a tactile keypad in conjunction with a graphical LC display. Keypad The function of the keys is described below: Function Data display...

  • Page 12: Display

    C O N T R O L S Display The keypad allows navigation through the features of the WA2 via a number of different displays as described below: Data display This is the default display and shows a summary of the most recent weld. The diagram...

  • Page 13: Setup Display

    The Print parameter determines the output from the USB port at the end of each weld. If printing is off, there is no output; if printing is set to all, the WA2 outputs the results of every ½ cycle (AC) or 10 ms (DC) reading; if printing is set to summary, the WA2 outputs the average current and duration for the weld.
  • Page 14 The Stop parameter (not shown) can be used to capture a specific section of a long weld. The WA2 will capture 300 cycles (AC) or 3 seconds (DC) of welding prior to the Stop parameter. If DC mode is selected, the Blanking and Stop parameters are programmed in ms.

  • Page 15: File Display

    The ID is a numeric identifier that is used to access the stored weld. Select an action and an ID (if applicable), then press to confirm the action. The WA2 will perform the action and then revert to the Data Display.

  • Page 16: Measuring Welds

    • Use the button to return to the Data Display. • Use the welding machine to produce a weld and check that the WA2 has read the welding current, duration and (if appropriate) the conduction angle and pulses. The Data Display shows a summary of the weld.

  • Page 17: Capturing Data With Wa Terminal

    WA2 in applications where long- term data logging is required. WA Terminal connects to your WA2 via your computer’s USB port. As your WA2 records each weld the information is transmitted to WA Terminal where the information can be inspected, saved or printed.
  • Page 18 C A P T U R I N G D A T A W I T H T E R M I N A L Specifications compatibility Microsoft Windows: 8/7/Vista/XP Server 2008 minimum requirements Pentium 233-megahertz (MHz) processor or faster (300 MHz is recommended) At least 64 megabytes (MB) of RAM (128 MB is recommended) At least 1.5 gigabytes (GB) of available...

  • Page 19: Installing Wa Terminal

    WA Terminal is a self-contained program and requires no installation. The program is supplied as a single executable file named WAT.EXE and is included on the WA2 companion CD. Copy the WAT.exe file to a location on your computer and run the...

  • Page 20: Connecting Your Wa2

    USB mini B cable. The USB device is provided by Future Technology Devices International Ltd. and Windows drivers are included on the WA2 companion CD. Updated drivers and drivers for Mac OS and Linux can be found on the FTDI website: http://www.ftdichip.com/Drivers/VCP.htm.
  • Page 21 C A P T U R I N G D A T A W I T H T E R M I N A L Windows 8 • type: device manager, select Device Manager and then press enter Windows 7/Vista •...
  • Page 22 C A P T U R I N G D A T A W I T H T E R M I N A L Expand the Ports node and determine which COM port has been allocated to the USB port (in this example the connection has been allocated to COM4).

  • Page 23: Using Wa Terminal

    WA Terminal at the end of each weld. If printing is off, no data is transmitted; if printing is set to All, the WA2 transmits the results of every ½ cycle (AC) or 10 ms (DC) reading; if printing is set to Summary, the WA2 transmits the average current and duration for the weld.

  • Page 24: Communications Port

    T E R M I N A L Communications Port Your WA2 should be connected to your computer via a USB port. Use this function to select the appropriate COM port that will be used for communications. WA Terminal will reprogram the port with the appropriate settings.

  • Page 25: Auto-Save

    Save button. If no file has been selected, the Auto-save function is disabled. Data display The data display shows the data that has been recorded from your WA2. The exact format depends on the configuration of your WA2. The time and date feature requires WA2 v4.2+ Closing WA Terminal The program can be closed at any time using any of the standard Windows actions.

  • Page 26: Data Persistence

    Windows registry happen immediately, and no backup is automatically made. Do not edit the Windows registry unless you are confident about doing so. The size and position of WA Terminal’s main window, together with the last used port stored System Registry. registry HKEY_CURRENT_USER\Software\BF ENTRON WA Terminal...
