Intel LAN1 / LAN2 Controller
This item allows you to enable or disable the Intel LAN / LAN2 controllers.
Configuration options: [Disabled] [Enabled]
4.5.9

APM Configuration

The items in this menu allow you to set system wake and sleep settings.
ErP Ready
This item allows you to switch off some power at S4+S5 or S5 to get the system ready for
ErP requirement. When set to [Enabled], all other PME options are switched off.
Configuration options: [Disabled] [Enable(S4+S5)] [Enable(S5)]
4.5.10

Network Stack Configuration

The items in this menu allow you to configure Ipv4 / Ipv6 PXE support.
4.5.11

HDD/SSD SMART Information

This menu displays the SMART information of the connected devices.
NVM Express devices do not support SMART information.
4.5.12

USB Configuration

The items in this menu allow you to change the USB-related features.
The Mass Storage Devices item shows the auto-detected values. If no USB device is
detected, the item shows None.
USB Single Port Control
This item allows you to enable or disable the individual USB ports.
Refer to section 3.1 Motherboard layout for the location of the USB ports.
4.5.13

Thunderbolt(TM) Configuration

The items in this menu allow you to configure Thunderbolt settings.
TBT Root port Selector
This item allows you to select the thunder root port.
Configuration options: [Thunderbolt Disabled] [PCIE4_1] [PCIE16_1] [PCIE16_2] [PCIE16_3]
[PCIE16_4]
4.5.14

PCH-FW Configuration

This item allows you to configure the firmware TPM.
