Tracker 3000
Operator Manual
Model #:
680022,
680267,
680570
P.O. Box 350, 100 Eagle Parkway, Adairsville, GA 30103
800.633.0519 or 770.773.3875 Fax 770.773.9903
www.EagleFloorSolutions.com, email - customerservice@eaglefloorsolutions.com
Solutions
Eagle Solutions, ©2008, Tracker Operator Manual Page #1
Advertisement
Table of Contents
Summary of Contents for Eagle Tracker 3000
- Page 1 Tracker 3000 Operator Manual Model #: 680022, 680267, 680570 Solutions P.O. Box 350, 100 Eagle Parkway, Adairsville, GA 30103 800.633.0519 or 770.773.3875 Fax 770.773.9903 www.EagleFloorSolutions.com, email - customerservice@eaglefloorsolutions.com Eagle Solutions, ©2008, Tracker Operator Manual Page #1...
- Page 2 Two 16” counter rotating brushes Machine Dimensions L 53” x W 30.5” x H 42” Total Weight 450 lbs All engines exceed Environmental Protection Agency (EPA) and California Air Resource Board (CARB) regulations for exhaust emissions. Eagle Solutions, ©2008, Tracker Operator Manual Page #2...
-
Page 3: Table Of Contents
Changing the Oil ....................Checking the Oil Level ..................Adjusting Belt Tension ..................Troubleshooting .................. Warranty Information ................ Instructions and Conditions for Warranty Reimbursement ......Engine Warranty Flat Rate Chart ..............Warranty Flat Rate Chart................. Eagle Solutions, ©2008, Tracker Operator Manual Page #3... - Page 4 Before We Begin Please Consider These Important Points!! • Your safety and the safety of those around you is your responsibility! • Only certified operators should be allowed to operate propane powered machines. • Read and understand this “Operator’s Manual.” Make sure everyone operating the machines reads and understands its basic operation of your particular machine. • Planned maintenance (PM) is the responsibility of the operator. • Regular maintenance by trained service technicians will ensure long life and satisfactory performance from your propane powered machine. It will also help to prevent serious injury to you and others. • Only a trained service technician should alter or adjust the fuel system or carburetors of a propane engine. Eagle Solutions, ©2008, Tracker Operator Manual Page #4...
-
Page 5: What Is Propane
F. The propane flame will vent propane vapor if internal tank pressure exceeds not burn hotter than 3595 the preset rating of the valve. The valve closes Service Tech School This class includes discussions on safe work environments and procedures, machine updates and the future of the industry and Eagle Solutions. Enjoy hands on training of electrical ignition and, starting systems, replacing of fuel systems, emissions testing, advanced failure analysis and tear down and reassembly procedures. You will be given a plant tour and meet the customer service people you speak with regularly on the phone. This certification program is NOT a small engines class. Although, you do not need to be a mechanic to attend you should have a general knowledge of engines. Call today for a class schedule, 800.633.0519. -
Page 6: Emissions
Air Filters: The air fuel ratio can be affected by before reading the level. Because of the importance dirty air filters, which can cause an imbalance in the of maintaining the correct oil level always consult air mixed with propane and increases emissions. It the engine manufacturer operation manual for the is imperative that the operator check and correct correct procedure. At all times the machine should dirty air filters every time the machine is used. be setting level on the floor when checking the oil. Eagle Solutions, ©2008, Tracker Operator Manual Page #6... -
Page 7: Other Areas For Safety With Propane
1. Take to a safe area outside, away from open buildings frequently by the public. Eagle machines flames and cigarettes. use a 20 POUND capacity cylinder and are not 2. Open the fixed liquid level gauge (bleeder allowed to be stored in buildings frequented by valve). Eagle Solutions, ©2008, Tracker Operator Manual Page #7... -
Page 8: Emergency Situations With Propane
If you subscribe to that type of service be very careful to: • Make sure the vendor installs a VERTICAL cylinder rack for vertical cylinders. • Check each cylinder for overfill. • Check each exchanged cylinder to be assured it is a VAPOR DRAW cylinder. • Check the manufacturing date on the collar to be assured it has not passed its recertification date (twelve years). Eagle Solutions, ©2008, Tracker Operator Manual Page #8... -
Page 9: Reminders
• Exhaust parts are extremely HOT. Be careful never attempt to disconnect it or circumvent it! not to allow them to come into contact with • Never attempt to bypass or disconnect the kill anything or anyone. switch or any other safety devices. • Do not attempt to change pads or abrasives while the engine is running. Eagle Solutions, ©2008, Tracker Operator Manual Page #9... -
Page 10: Machine Operation
• Never attempt to bypass or disconnect the kill • Remove the key from the switch, if applicable. switch or any other safety devices. • Remove the fuel cylinder from the machine and * To arrange for operation and safety training store it outside in a secure, approved cabinet. contact Eagle Solutions by phone at 770.773.3875, • Clean and inspect air and dust filters. email customerservice@eaglefloorsolutions.com or mail request to P.O. Box 350, Adairsville, GA 30103. Eagle Solutions, ©2008, Tracker Operator Manual Page #10... -
Page 11: Machine Set-Up & Operation
1. Clear area of all displays. Remove any dust and rapid motion. stickers from floor. 3. Remove and inspect. 2. Prepare stripping solutions according to 4. Reinstall in similar motion. instructions on the chemical label. 5. Remove transport wheel. 3. Apply solution to the floor using a mop or solution spreader. KEEP FLOOR WET WITH SOLUTION! Eagle Solutions, ©2008, Tracker Operator Manual Page #11... -
Page 12: Stopping The Machine
Extra filters may be ordered from Eagle service technician. To keep the machine in good Solutions at 800.633.0519. Keep a log book of working condition, simply follow the daily, weekly maintenance and/or repairs. -
Page 13: Daily Maintenance - (Every Four Hours Of Operation)
» Check valve clearance. deck. » Torque valve cover bolts. » Inspect spark plugs. Replace if necessary. 4. Check belt tension by pinching belt together. » Remove engine shroud and clean cooling Belt should depress only ½” (12 mm). fins. Eagle Solutions, ©2008, Tracker Operator Manual Page #13... -
Page 14: Troubleshooting
Center or replace pad(s), tighten Incorrect oil level Check and adjust oil level Engine overloaded See engine owners manual for Dirty filters servicing Clean or replace filters Faulty spark plug Check adjust/replace spark plug Eagle Solutions, ©2008, Tracker Operator Manual Page #14... -
Page 15: Warranty Information
The manufacturer manufacturer’s authorized Date purchased: _______________________ representative in no event shall be liable for direct, indirect, incidental or consequential damage. Model Number: _______________________ Abuse and failure to properly maintain engine will void warranty. Proper engine maintenance includes Serial Number: _______________________ filter and oil changes as described in the engine manufacturer’s operator manual. See information Eagle Solutions, ©2008, Tracker Operator Manual Page #15... -
Page 16: Instructions And Conditions For Warranty Reimbursement
6. Approved travel and service charges will also contact Eagle Solutions to determine if the be credited to you upon receipt of the defective defective component(s), travel charges, and parts. service fees will be covered under the Eagle Warranty Conditions Solutions Warranty Policy. 6. The service technician will contact Eagle 1. Approved warranty return items must be... -
Page 17: Engine Warranty Flat Rate Chart
UPPER ENGINE SHROUD LOWER ENGINE SHROUD AIR CLEANER/MUFFLER AIR CLEANER CASE STARTER MOTOR ASSY AIR CLEANER ELEMENT OR COVER STARTER BRUSH(ES) (INCLUDES STARTER (R&R)) MUFFLER OR HEAT COVERS MISC EXHAUST PIPE(S) OR GASKET(S) DIAGNOSIS Eagle Solutions, ©2008, Tracker Operator Manual Page #17... -
Page 18: Warranty Flat Rate Chart
EXHAUST SYSTEM HANDLE MANIFOLD MUFFLER / MOUNTING BRACKET ELECTRICAL SYSTEM 0.25 BATTERIES/BATTERY BOXES 0.25 DRIVE SYSTEM KEY SWITCH BELTS 0.25 0.25 WIRING HARNESS CLUTCHES PAD DRIVERS/STRIP BRUSHES 0.25 PULLEYS 0.25 TENSIONERS 0.25 Eagle Solutions, ©2008, Tracker Operator Manual Page #18... - Page 19 Eagle Solutions, ©2008, Tracker Operator Manual Page #19...
- Page 20 Kawasaki - 17hp 680428 Planned Maintenance Kits from Eagle will help your engine run longer and cleaner. Without proper maintenance you run the risk of increased emissions and loss of warranty. Don’t let that happen to you. Give your machines some fresh breath by replacing the recoil dust filter, the carburetor air filter element, carburetor foam pre- filter and clean oil and filter today.
