Penclic KB3 User Manual

HB186-A 105G : 105X148.5mm

INDICATOR LIGHTS DESCRIPTION

Penclic Mini Keyboard KB3
User Manual
PACKAGE CONTENTS
① Caps Lock Indicator
②
1. Aluminium Keyboard 2. Micro-USB Cable 3. User Manual USB/Bluetooth Connection Indicator and Bluetooth Status Indicator
③ Power, Charging, and Battery Power Indicator
④ Power switch, move right ⑤ Micro USB port, for wired
(left in picture) to turn on. connection and charging
LIGHT FUNCTION DESCRIPTION
① Caps Lock Indicator: The blue light will be on.
② USB / Bluetooth state indicator:
(press "Fn + 1" switch to wireless connection. Light will turn blue.
Press "Fn + 2" switch to wired connection when cable is connected.
Light will turn green,)
Bluetooth connect status indicator: blue light will flash after pressing
the "Fn + C" keys together.
③
Power Indicator: Slide the power button to right side, the power
indicator will turn green. Charging Indicator: Red light whilst charging,
turns off once fully charged.
Battery power display indicator. Press "Fn + Backspace " to show
Play/Pause
battery status. Status indication: Flashing green. ( Each flash represents
① ② ③
25% battery. One Flash 25% charge. Two Flashes, 50% charge. Three
Flashes, 75% charge. Four Flashes, 100% charge)
Next Track

KEYS AND FUNCTIONS

Mute
Select your operating system after connecting to device.
Volume down
Keyboard combination Operating system
Fn + Q Android Volume up
alt
Fn + W PC
Screen Lock
Fn + E iOS and OSX
PrtSc N/A
Function list of escape and function key row.
Fn+ N/A
Android iOS Windows OSX
Battery Power
Fn+
Display
Back N/A N/A N/A
For the Windows tablets, Hold Fn and press key simultaneously to
activate action.
Home Home Web Browser N/A
Special Note:
Reduce Reduce Reduce Reduce
Brightness Brightness Brightness Brightness 1. This keyboard doesn't support the Windows Mobile.
2. For Android users: The Caps Lock indicator may not light up, but will
Increase Increase Increase Increase
still function normally.
Brightness Brightness Brightness Brightness
3. While connected to an iOS or OSX device, the red printing is used. PC
standard layout and Apple standard layout are slightly different.
Search for Search for
Search for N/A
Switch WIRELESS AND WIRED FUNCTION INTRODUCTION
Switch
N/A N/A
Language Language
1. Bluetooth wireless connection: Fit for devices with Bluetooth function.
Like tablets, smartphones, etc.
Previous Track Previous Track Previous Track Previous Track
2. USB wired connection: Fit for devices whitch can be connected with
USB cable, like notebooks, PC, etc.
3. Micro-USB cable. Wired mode:connect with desktops and notebooks,
Play/Pause Play/Pause Play/Pause
sync and charging function. Wireless mode: charging for the keyboard.

PAIRING WITH WIRELESS DEVICES

Next Track Next Track Next Track

HOW TO PAIR THE KEYBOARD WITH IPAD

Mute Mute Mute Step 1. Slide the Power switch to right side, to turn on the keyboard,
power light will turn green for 10 seconds. Note the State light
Volume
should be blue.
Volume down Volume down
down Optional step. If the State light is green when power is switched on,
press "Fn + 1" key to change to Bluetooth state.
Volume up Volume up Volume up
Step 2. Press the "Fn + C" keys together to activate pairing mode. The
State light will start to blink blue.
Screen Lock Screen Lock N/A Step 3. On the iPad, select: Settings- Bluetooth-On.
Step 4. The iPad will display "Penclic Mini Keyboard KB3" as an available
device.
N/A Print screen N/A
Step 5. Select "Penclic Mini Keyboard KB3" on the iPad, click on it, the
keyboard will now be paired to iPad and the Bluetooth indicator
Keyboard
N/A N/A
will turn off.
Display
Step 6. Press "Fn +E" keys on the keyboard switch to the iOS operating
Battery Battery
Battery Power
system setting.
Power Power
Display
Display Display
CHANGING KEYBOARD LAYOUT (CHOSEN IN THE
OPERATING SYSTEM)
Samsung Android: Shift +Space
Google Android: Ctrl +Space
Windows: Win+Space
iOS 8: Win+Space
iOS 9: Ctrl+Space

PAIRING WITH DESKTOP (BLUETOOTH)

Step 1. Slide the Power switch to right side, to turn on the keyboard,
power light will turn green for 10 seconds. Note the State light
should be blue.
Optional step. If the State light is green when power is switched on,
press "Fn + 1" key to change to Bluetooth state.
Step 2. Press the "FN+ C" Keys together to enter pairing mode. The
Bluetooth light will start to blink blue.
Step 3. On your device, go to "settings". Activate its Bluetooth function

POWER SAVING MODE (BLUETOOTH MODE)

and search for the keyboards device.
The Keyboard will enter sleep mode after being idle for 30 minutes. To
Step 4. The device will display "Penclic Mini Keyboard KB3" as an
activate it, press any key and wait for 3 seconds to reconnect.
available device.
Step 5. Select "Penclic Mini Keyboard KB3" on your device, click on it,
the keyboard will now be paired to your device and the Bluetooth

HOW TO CHARGE

indicator will turn off.
1. Use the included Micro-USB cable for charging. Connect one end to a
Step 6.Choose your operating system.
USB charger or port, and the other to the keyboard. The keyboard can
be used while charging.
Fn + Q Android
2. Whilst charging, the power indicator will turn red. Approximately 2 hours
Fn + W Windows
until fully charged. (USB charger is not included, but cable to USB
Fn + E IOS / OSX port works)

BATTERY LIFE TIP

PAIRING WITH DESKTOP (WIRED)

When not in use for a prolonged period of time, it is recommended that
Step 1. Get the keyboard to the desktop with the cable.
the keyboard is turned off to lengthen the battery life.
Optional step. If the State light is blue when power is switched on,
press "Fn + 2"key to change to Wired state. (note: State

TROUBLESHOOTING FOR WIRELESS MODE

will not change if cable is not connected)
Step 2. Wait for drivers to install. If you are unable to connect the keyboard, please try the following:
Step 3. Press "Fn+ W" keys on the keyboard switch to the Windows
1. Make sure the keyboard is in Bluetooth mode. State indicator light is
operating system.
blue when keyboard is powered on. Press "FN+1" switch to wireless
Step 4.Choose your operating system.
connection.
Fn + Q Android 2. Starting with a full charge on both devices ensures that process won´t
be interrupted by low battery.
Windows
Fn + W
3. Make sure your devices Bluetooth is on.
Fn + E iOS / OSX
4. Make sure that the keyboard is within the effective operation distance
of 10 meters. (line of sight, walls etc. will reduce operational range)
NOTE FOR WIRELESS MODE

TROUBLESHOOTING FOR WIRED MODE

1. Keyboard can only be connected to one device at a time.
2. For other Bluetooth enabled devices, please verify the Bluetooth
Make sure that the keyboard is in wired mode. Press "FN+2" switch to
capability before attempting to connect to the keyboard.
wired connection, State indicator light should be green.
3. After pairing for the first time, your device will automatically connect
to the keyboard automatically when powering on or waking up the
keyboard. Unless the keyboard has been paired with something else.
4. In case of connection failure, Delete the pairing record from your
device and try the above procedures again.
SAFETY INSTRUCTIONS
1. Keep the keyboard away from sharp objects that could damage it.
2. Do not put heavy objects on the keyboard.
3. Do not stretch, twist or apply force to the keyboard.
4. To clean the keyboard, gently wipe it by using a moist cotton cloth.
5. Make sure the keyboard is turned off before cleaning. Do not use
liquid cleanser.
6. Please do not spill liquids on the keyboard.
7. Avoid extreme hot and cold temperatures.

TECHNICAL SPECIFICATIONS

Supported platforms of Penclic Mini Keyboard KB3.
- Windows XP and newer.
- Android
- iOS
No driver needed.
Bluetooth version 3.0
USB HID 1.1 compatible.
Battery capacity: 250mA
Battery type: Lithium-polymer battery
Battery voltage:3.1V~4.2V
Sleep energy saving mode activates after 30 minutes, press any button to
reconnect.
Wireless reach: 10 meters.
Measurements:
Height: 10.25 mm
Surface: 280 x 115.5 mm
Weight: 284 grams
Cable length: 150 cm
