Contents Section Page Contents Handling the system Mode of operation, accessories, disclaimer Controlling the system with the Thitronik remote control Alarm storage Activating the panic alarm Running the system without the supply voltage Sabotage protection “Open contact” signal (ventilation function) “Battery low”...
C.A.S. which then gives out an alarm. In the event of an alarm, the GSM/GPS Combimodule for C.A.S. III (Item no: 101012) sends an SMS to up to 10 programmable telephone numbers. The alarm system can also be switched on or off via an SMS. By calling the GMS module, status...
SOS Message (GSM/GPS combi module needed). A panic alarm can be activated whether the system is armed or not armed. The panic alarm is activated by pressing both buttons on the Thitronik remote control simultaneously. ...
Bedienungsanleitung C.A.S. C.A.S. III operating instructions Seite 2 Page 3 1.5 Running the system without the 12 V supply voltage If a voltage supply is unavailable from either the vehicle or the parking place, the system will run on an integrated rechargeable battery for up to 48 hours.
When locking, the interior beeper emits a series of short beeps. This means that the system has detected that one or more of the wireless magnetic contacts is open. When activating C.A.S. III with the small button or the - button, there won´t be signal tones (see 1.2).
C.A.S. III operating instructions Page 5 1.9.1 Changing battery of the Thitronik remote control – Unscrew one or three screws on the back of the remote control and open the casing. (Depends on the remote control generation) – Remove the printed circuit board and remove the battery.
C.A.S. III operating instructions Page 7 2.1 Using the GSM/GPS combi module (optional) If a GSM/GPS combi module (Item no: 101012) has been connected, there are numerous additional functions and alarm options available. – Alarm message: if there is a break-in, gas or, if the cable loop is triggered, with in- formation on the type of incident, time of incident, position and speed.
Page 10
C.A.S. III operating instructions Page 8 2.2 Using the GSM/GPS combi module (optional) Activating by SMS: Send an SMS with “arm” to the number of the SIM inside. After receiving the SMS, the system acknowledges the process with a single flash from all 4 LEDs and a status message by SMS. Deactivating by SMS: Send an SMS with “disarm”...
C.A.S. III operating instructions Page 9 2.1 Information on using the GSM/GPS combi module (optional) SIM card used: In order to use the GSM module, you require the SIM card of a mobile phone supplier. We recommend using a card from T-mobile or Vodafone.
Page 12
C.A.S. III installation manual Page 10 Installation manual C.A.S. III Please read carefully before installation...
C.A.S. III installation manual Page 11 3.1 Scope of delivery C.A.S. III base, handheld transmitter, wireless magnetic contact with 2 different self-adhesive pads, 1 x warning sticker, installation manual, PG gland, connecting cable, status-LED, operating instructions 3.2 Installation instructions Since there is a risk of causing a short circuit when working on the vehicle electrical equipment, the negative pole of the battery must be disconnected if an on-board voltage supply has been installed.
C.A.S. III installation manual Page 12 3.6 Chart 1 programm selector switch Switch 1 Switch 2 Switch 3 Switch 5 Switch 6 acoustic status report Arming/Disar- input voltage Jammer triggers response by by SMS after ming via phone disruption trig-...
C.A.S. III installation manual Page 13 3.8.1 Disconnecting contacts or other transmitters Transmitters can only be deleted by erasing the memory. Hold down the “RX” button on the printed circuit board (Diagram 1, Page 13) until the central unit gives out a long beep. All the transmitters are now erased.
C.A.S. III installation manual Page 15 3.9.1 Installing the wireless contacts Choose the places where you want to install the wireless magnetic contacts. The transmitters can be installed both on the window and the frame (see diagrams on Page 8). The distance between the transmitter (Diagram 2, Part A, Page 13) and magnet (Diagram 2, Part B, Page 13) can be around 22 mm.
Page 18
C.A.S. III installation manual Page 16 3.9.3 Diagrams wireless magnetic contact It is possible to mount the transmitter Transmit LED casing in a lying position (on the left or, Transmitter rotated 180°, on the right) or standing cover on the side – depending on the frame...
C.A.S. III installation manual Page 17 3.9.4 Installing the cable loop (accessory) Choose a suitable place for installation at the back of the vehicle or on one of the sides. You can also obtain further holders as accessories (Item no: 100649) to use the cable loop for other areas of the vehicle.
C.A.S. III installation manual Page 18 3.9.6 Connecting the central unit Connect the connection cable fed through the base of the central unit to the connection terminals as follows (A, Diagram 1): white > - (GND/earth) brown > +12 V green >...
Deleting or changing of target number: In order to delete the target number, press the GSM button until the C.A.S. III sounds a long beep tone. Target numbers can also be overwritten. You should send a programming SMS...
C.A.S. III installation manual Page 21 4.1 Technical specifications Supply voltage: Current consumption: approx. 15mA without GSM/GPS combi module approx. 25-30mA with GSM/GPS combi module Assignable transmitters max: Transmitter frequency: 868,35MHz Transmitting power: <10mW Range max: up to 100m in the open...
C.A.S. III installation manual Page 22 Thitronik GmbH hereby declares that this product complies with the requirements and regulations of the directive 1995/5/EG. The full declaration of conformity is available for download: http://www.thitronik-automotive.de/support.html...
