XBC-KZ33
Block Camera
Part No.
EM13920
EM13921

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XBC-KZ33 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for InterTest XBC-KZ33

Summary of Contents for InterTest XBC-KZ33

  • Page 1 XBC-KZ33 Block Camera Part No. EM13920 EM13921...
  • Page 2 Revision History Revision History Date Version Contents 2018.02.09 V1.0.0 Release Document 2017.09.01 V1.0.0 Release Document iShot® Xblock® XBC-KZ33 Block Camera www.intertest.com...

  • Page 3: Table Of Contents

    Table of Contents ABLE OF CONTENTS TABLE OF CONTENTS ---------------------------------------------------- FEATURES ---------------------------------------------------- PRECAUTION ---------------------------------------------------- SPECIFICATIONS ---------------------------------------------------- OSD & MENU ---------------------------------------------------- DIMENSION ---------------------------------------------------- INTERFACE ---------------------------------------------------- FUNCTIONS ---------------------------------------------------- COMMAND LIST ---------------------------------------------------- www.intertest.com Operating Manual...

  • Page 4: Features

    The ICR will automatically engage depending on the ambient light, allowing the camera to be effective in day/night environment. • A Privacy Zone Masking function (max. 16 blocks) is available. iShot® Xblock® XBC-KZ33 Block Camera www.intertest.com...

  • Page 5: Precaution

    The customer should make sure that they have the most recent manual version. This document provides technical information for the user. KT&C reserves the right to modify the information in this document as necessary. The customer should make sure that they have the most recent manual version. www.intertest.com Operating Manual...

  • Page 6: Specifications

    Auto / Shutter Priority / Iris Priority/ Manual/Bright Brightness 0~14 AGC Limit -3dB ~ 58dB Manual Shutter X32~x2,1/25(30)/1/50(60) ~ 1/30000 Manual AGC -3dB ~ 58dB Manual Iris F1.6 ~ F19, Close Sens-Up Off ~ 32fields Spot AE, Slow AE response iShot® Xblock® XBC-KZ33 Block Camera www.intertest.com...
  • Page 7 Temperature& Humidity Operating condition Temperature (-10°C~50 °C / 14°F~122°F), Humidity (20% ~ 80%) Storage condition Temperature (-20°C~60 °C / -4°F~140°F), Humidity (20% ~ 95%) When CVBS is connected, WDR automatically turns off and Digital WDR operates. (NOTE1) www.intertest.com Operating Manual...
  • Page 8 9pin FFC (52207-0985, 1.0mm) 3pin External D&N Interface (SM03B-SRSS-TB, 1.0mm) 3pin AHD/TVI (53261-0371, 1.25mm) 2pin RS-485 (53261-0271, 1.25mm) MMCX ◎ : Main Video Output / Main Control Connector EM13921 EM13920 ATC-HZ7833M-LA (1/2.8‛) ATC-HZ7833M-LT (1/2.8‛) iShot® Xblock® XBC-KZ33 Block Camera www.intertest.com...

  • Page 9: Osd & Menu

    ▶HOME POSITION : OFF/ON HOME POSITION Go to X1 position when power on. PRESET POSITION ▶PRESET POSITION : Select target position for PRESET AF PRESET MARGIN ▶PRESET : Select PRESET auto focusing range, 4~255 INITIAL (*)See. “FUNCTIONS” RETURN www.intertest.com Operating Manual...
  • Page 10 ▶BLC Y- POSITION : adjust BLC Y-window position INITIAL ▶BLC X-SIZE : adjust BLC X-window size RETURN ▶BLC Y-SIZE : adjust BLC Y-window size ▶HLC COLOR : BLACK/WHITE/YELLOW/CYAN/GREEN/MAGENTA/ RED/BLUE (Caution !!!) ◆ WDR is available if AE MODE is AUTO. iShot® Xblock® XBC-KZ33 Block Camera www.intertest.com...
  • Page 11 ▶DNR : Setting Digital Noise Reduction EFFECT ▶DIS : Setting Digital Image Stabilization INITIAL ▶EFFECT : Setting Digital Effects RETURN Setting Defog DEFOG ▶MODE ON/OFF : OFF/ON MODE ON/OFF MODE AUTO ▶MODE : AUTO/MANUAL LEVEL MIDDLE ▶LEVEL : LOW/MIDDLE/HIGH RETURN www.intertest.com Operating Manual...
  • Page 12 ▶RANGE : 10%/20%/30% RANGE ▶FILTER : LOW/MIDDLE/HIGH FILTER MIDDLE ▶AUTO C : OFF/HALF/FULL AUTO C HALF RETURN EFFECT Setting Digital Effect function PIC.EFFECT ▶PIC.EFFECT : OFF/NEGATIVE/BW HR MODE ▶HR MODE : OFF/ON RETURN High Resolution mode iShot® Xblock® XBC-KZ33 Block Camera www.intertest.com...
  • Page 13 ▶CAM ID DISP : OFF/ON, Camera ID display mode CAM ID POS ▶CAM ID POS : Camera ID display position setting ZOOM MAG DISP ▶ZOOM MAG DISP : OFF/ON ZOOM MAG POS ▶ZOOM MAG POS : Zoom ration display position setting INITIAL RETURN www.intertest.com Operating Manual...
  • Page 14 ▶IR LED : YES(use IR LED at night) /NO ▶DEFECT DET : defect detection ▶COLOR : Adjust R/B gain, R/B hue ▶COM : RS232 / RS485 communication Setting. (!!!) All of the SYSTEM menu items are NOT initialized. iShot® Xblock® XBC-KZ33 Block Camera www.intertest.com...
  • Page 15 (f.g) If you want to emphasize the GREEN color, adjust BY-GAIN- and RY- GAIN-. Setting Serial Interface CAM ID ▶CAM ID : 0~255 BAUDRATE 9600 ▶BAUDRATE: 2400/4800/9600/19200/38400/57800/115200 bps APPLY ▶APPLY : apply the <CAM ID>,<BAUDRATE> condition. RETURN www.intertest.com Operating Manual...

  • Page 16: Dimension

    Dimensions IMENSION Zoom module (ATC-HZ7833M-LA/LT) EM13921 / EM13920 iShot® Xblock® XBC-KZ33 Block Camera www.intertest.com...

  • Page 17: Interface

    DC12V input AHD_OUT HD-AHD output 5.0V (compatible 3.3V) +12V_IN DC 12V INPUT 5.0V (compatible 3.3V) CN301 (RS485) / 53261-0271 Name Description TRX+ RS485 TRX+ TRX- RS485 TRX- (AD key External Circuit) MENU TELE WIDE NEAR FAR N.U. www.intertest.com Operating Manual...
  • Page 18 HD-TVI output 5.0V (compatible 3.3V) +12V_IN DC 12V INPUT 5.0V (compatible 3.3V) CN301 (RS485) / 53261-0271 Name Description TRX+ RS485 TRX+ TRX- RS485 TRX- (AD key External Circuit) MENU TELE WIDE NEAR FAR N.U. iShot® Xblock® XBC-KZ33 Block Camera www.intertest.com...
  • Page 19 (caution) If the frame rate is 25 fps / 30 fps, it works as SINGLE even if LVDS MODE is set to DUAL. However, if the frame rate is 50 fps / 60 fps, LVDS MODE must be set to DUAL to operate as DUAL. www.intertest.com Operating Manual...
  • Page 20 Pixel Clock [MHz] TCLK+ [MHz] 1080p60 148.5 148.5 1080p50 148.5 148.5 1080i60 74.25 74.25 1080i50 74.25 74.25 1080p30 74.25 74.25 1080p25 74.25 74.25 720p60 74.25 74.25 720p50 74.25 74.25 720p30 74.25 74.25 720p25 74.25 74.25 iShot® Xblock® XBC-KZ33 Block Camera www.intertest.com...
  • Page 21 Output Format Pixel Clock [MHz] TCLK+ [MHz] 1080p60 148.5 74.25 1080p50 148.5 74.25 1080i60 74.25 37.125 1080i50 74.25 37.125 1080p30 74.25 37.125 1080p25 74.25 37.125 720p60 74.25 37.125 720p50 74.25 37.125 720p30 74.25 37.125 720p25 74.25 37.125 www.intertest.com Operating Manual...

  • Page 22: Functions

    PRESET position, send the SAVE & EXIT command. To end without saving, send CANCEL&EXIT command. (3) To save the current zoom and focus position to PRESET position without outputting PRESET POSITION menu, send SAVE & EXIT command. iShot® Xblock® XBC-KZ33 Block Camera www.intertest.com...

  • Page 23: Automatic Exposure Mode

    Spot AE mode 8x 01 04 59 03 FF Position 8x 01 04 29 0p 0q 0r 0s FF pq:X(0~F), rs:Y(0~F) Noise Reduction • 3D-NR • 2D-NR WDR OFF WDR ON Defog • Sharpens cloudy images such as fog. www.intertest.com Operating Manual...

  • Page 24: Digital Image Stabilizer

    Moving to x1 position User Memory Area erOn 8x 01 70 24 03 FF Move to final position You can use up to 16 bytes to store data such as camera before power off number. iShot® Xblock® XBC-KZ33 Block Camera www.intertest.com...
  • Page 25 8x 01 70 05 11 0p 0q FF MOTION!!! (*3) Day->Night(EXT-L) 8x 01 70 05 20 0p 0q FF Night->Day(EXT-L) 8x 01 70 05 21 0p 0q FF (*) Blocks are output only within the Frame area. www.intertest.com Operating Manual...

  • Page 26: Privacy Zone Masking

    List(mm) 0F 0E 0D 0C 0B 0A 09 08 07 06 05 04 03 02 01 00 The priority order of the mask display is in the sequence from A (highest) to P (lowest). iShot® Xblock® XBC-KZ33 Block Camera www.intertest.com...
  • Page 27 The current setting status of the camera is displayed on the screen. Mask Size : Width/Height • CAM_Display 8x 01 04 15 02 FF 8x 01 04 15 03 FF (example) 1080p/30 FLIP CAPTURE ZOOM 3A30 DZOOM E8 F1.6 28dB MF FAR 1/1000 www.intertest.com Operating Manual...

  • Page 28: Command List

    = category code QQ = 01 (Command), 09 (Inquiry) RR = 00 (Interface), 04 (camera 1), 06 (Pan/Tilter), 07 (camera 2) X = 1 to 7 : camera address Header : Usually it uses 0x81 iShot® Xblock® XBC-KZ33 Block Camera www.intertest.com...
  • Page 29 Returned the device address to +1. IF_Clear(Broadcast) 88 01 00 01 FF 88 01 00 01 FF Returned the same command. IF_Clear (For x) 8x 01 00 01 FF z0 50 FF (Completion) ACK is not returned for this command. www.intertest.com Operating Manual...
  • Page 30 8x 01 04 03 00 FF Manual Control of R Gain 8x 01 04 03 02 FF Down 8x 01 04 03 03 FF Direct 8x 01 04 43 00 00 0p 0q FF pq: R Gain, 0x00~0xff iShot® Xblock® XBC-KZ33 Block Camera www.intertest.com...
  • Page 31 8x 01 04 66 03 FF CAM_ICR 8x 01 04 01 02 FF Infrared Mode ON(night)/OFF(day) 8x 01 04 01 03 FF CAM_AutoICR 8x 01 04 51 02 FF Auto dark-field mode On/Off 8x 01 04 51 03 FF www.intertest.com Operating Manual...
  • Page 32 Mask Settings (0: OFF, 1: ON) SetMaskColor 8x 01 04 78 pp pp pp pp pp: Mask Color Settings pp pp pp qq rr qq: Color Setting when 0 is iShot® Xblock® XBC-KZ33 Block Camera www.intertest.com...
  • Page 33 (*) Inactive : When the power is turned on, it starts up in the Inactive 8x 01 04 3F 10 7F FF settings before the power is turned off. Active 8x 01 04 3F 11 7F FF www.intertest.com Operating Manual...
  • Page 34 8x 01 70 24 03 FF After power on, move to final position before power off KT_FontSize Normal 8x 01 70 15 30 FF Function OSD / Title font size 8x 01 70 15 31 FF iShot® Xblock® XBC-KZ33 Block Camera www.intertest.com...
  • Page 35 50 02 FF y0 50 03 FF CAM_FreezeModeInq 8x 09 04 62 FF y0 50 02 FF y0 50 03 FF CAM_PictureEffectModeInq 8x 09 04 63 FF y0 50 00 FF y0 50 02 FF Neg.Art www.intertest.com Operating Manual...
  • Page 36 50 03 FF Spot AE Off CAM_SpotAEPosInq 8x 09 04 29 FF y0 50 0p 0q 0r 0s FF pq:X(0~F), rs:Y(0~F) CAM_MemoryInq 8x 09 04 3F FF y0 50 pp FF pp:memory number recalled last iShot® Xblock® XBC-KZ33 Block Camera www.intertest.com...
  • Page 37 Position Mode, 2(ON)/3(OFF) KT_CustomPresetInq 8x 09 70 3E FF y0 50 0p FF p: 1(custom preset activate) 0(custom preset inactive) KT_FontSizeInq 8x 09 70 15 FF p: 0(Normal Size) / 1(Big Size) y0 50 0p FF www.intertest.com Operating Manual...
  • Page 38 Stopped Focus Command 1: Executing 0: Stopped Zoom Command 1: Executing 0: Stopped Zoom Position (HL) Focus Position (HL) 1 Terminator (FFh) Zoom Position (LH) Focus Position (LH) Zoom Position (LL) Focus Position (LL) iShot® Xblock® XBC-KZ33 Block Camera www.intertest.com...
  • Page 39 Wide-D (1: Other than Off, 0: Off) R Gain (L) Back Light 1: On 0: Off Exposure Comp. 1: On 0: Off Slow Shutter 1: Auto 0: Manual B Gain (H) Shutter Position B Gain (L) Iris Position www.intertest.com Operating Manual...
  • Page 40 Camera ID (HL) Privacy Zone 1: On 0: Off Mute 1: On 0: Off Title Display 1: On 0: Off Display 1: On 0: Off Camera ID (LH) Picture Effect Mode Camera ID (LL) iShot® Xblock® XBC-KZ33 Block Camera www.intertest.com...
  • Page 41 High Sensitivity mode (1: ON, 0: OFF) NR Level Digital Zoom Position Gain Limit 1 Terminator (FFh) MD (1: On, 0: Off) AF Activation Time (H) Reserved Picture flip (1: On, 0: Off) AF Activation Time (L) www.intertest.com Operating Manual...
  • Page 42 Comments Byte Comments ents Destination Address Source Address 0 Completion Message (50h) Defog Mode(1:on,0:off) WideD mode (0: OFF, 1: ON) 1 Terminator (FFh) WideD blown-out highlight correction level 0: L 1: M 2: H iShot® Xblock® XBC-KZ33 Block Camera www.intertest.com...
  • Page 43 Enlargement Function3 Query Command....Command Packet 8x 09 7E 7E 05 FF Byte Comments Byte Comment Byte Comments Destination Address Reserved Reserved Source Address 0 Completion Message (50h) Reserved Reserved Reserved Reserved Reserved Reserved Reserved 1 Terminator (FFh) Reserved Reserved Reserved www.intertest.com Operating Manual...
  • Page 44 More Open F6.8 −7 −10.5 dB default F9.6 … More Close CLOSE Iris Open Limit Operating (fixed) Aperture (=sharpness) Range Index Level Close Limit Sharp (adjustable) … Dull Red/Blue Manual Gain 0x00 ~ 0xFF iShot® Xblock® XBC-KZ33 Block Camera www.intertest.com...
  • Page 45 3483 3709 0C33 1.41 33CC 3820 3920 3A0A GAMMA POSITION 3ADD Index Gamma 3B9C 0.45 3C46 0.50 3CDC 0.55 3D60 0.60 3DD4 0.65 3E39 0.70 3E90 0.75 3EDC 3F1E 3F57 3F8A 3FA4 3FB8 3FD0 3FE0 3FF0 4000 www.intertest.com Operating Manual...

  • Page 46: Title Setting

    Motion Setting AF Home Position AF Limited Range Title Display On/Off Title Setting Focus Position Display On/Off Focus Mode Near Limit Setting AF Sensitivity AF Mode AF Run Time AF Interval Time WB Mode iShot® Xblock® XBC-KZ33 Block Camera www.intertest.com...

  • Page 47: Baudrate

    00-FF Max. digital (Default:EB) zoom ratio = 256 ÷ (256-Value) FocusOffset 00-FF 00: None @DomeCover (Default:00) FF: Max. Auto Slow 1/30 shutter limit (default) 1/15 Enlargyment 00~FF Bit3:Auto ICR Mode (default:00) OFFON setting enable ON/OFF (1:ON, 0:OFF) www.intertest.com Operating Manual...
  • Page 48 (*) CVBS : If you connect directly to a CVBS monitor, select "CVBS". (*)Alternatively, you can change the color directly in the menu. (*)Alternatively, you can change the color directly in the menu. www.intertest.com 303 State Route 94 Columbia, NJ 07832 USA Office: 908-496-8008 Toll Free (U.S.): 800-535-3626...
