INSTALLATION INSTRUCTIONS
HB0113
WPD39M SERIES
!
INTENDED FOR DOMESTIC COOKING ONLY
!
READ AND SAVE THESE INSTRUCTIONS
INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER.
HOMEOWNER: USE AND CARE INFORMATION ON PAGES 9
10.
AND
BEST; Hartford, Wisconsin www.BestRangeHoods.com 800 558-1711
BEST; Drummondville, QC, Canada www.BestRangeHoods.com 866 737-7770
To register your product online or for additional information visit www.BestRangeHoods.com
SV20611 rev. 04
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Best WPD39M SERIES
Summary of Contents for Best WPD39M SERIES
-
Page 1: Read And Save These Instructions
INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER. HOMEOWNER: USE AND CARE INFORMATION ON PAGES 9 BEST; Hartford, Wisconsin www.BestRangeHoods.com 800 558-1711 BEST; Drummondville, QC, Canada www.BestRangeHoods.com 866 737-7770 To register your product online or for additional information visit www.BestRangeHoods.com SV20611 rev. 04... - Page 2 Heat oils 8. To reduce the risk of fire and electrical shock, the Best WPD39M slowly on low or medium settings. Series hood must be installed with Best interior blower model b) Always turn hood ON when cooking at high heat or when P12;...
-
Page 3: Table Of Contents
ONE-YEAR LIMITED WARRANTY FOR BEST PRODUCTS Broan-NuTone LLC (Broan-NuTone) warrants to the original consumer purchaser of Best products that such products will be free from defects in materials or workmanship for a period of one year from the date of original purchase. THERE ARE NO OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, IMPLIED WARRANTIES OR MERCHANT ABILITY OR FITNESS FOR A PARTICULAR PURPOSE. -
Page 4: Wpd39M Series Range Hood System
- WPD39M SERIES RANGE HOOD SYSTEM - ODEL ODEL ODEL ODEL (10" R (10" R IGH CAPACITY ROOF CAP OUND WALL CAP IGH CAPACITY ROOF CAP OUND WALL CAP ODEL (10" R OUND ADJUSTABLE ELBOW ILB11 (1100 ODEL LINE BLOWER INCLUDES 8"... -
Page 5: Select Blower Option, Install Ductwork And Electrical Wiring
Run 3-wire power supply cable to installation location. WARNING The power cable must be a GFCI protected branch circuit. For best capture of cooking impurities, the bottom of the hood must be located at a distance of 36" above cooking surface. XTERIOR OOF CAP... -
Page 6: Prepare Installation
2. PREPARE INSTALLATION WARNING When performing installation, servicing or cleaning the unit, it is recommended to wear safety glasses and gloves. NOTE: Before proceeding to the installation, check the contents of the box. If items are missing or damaged, contact the manufacturer. Make sure that the following items are included: - Range hood - Wood strip (attached to back of hood) -
Page 7: Install Wall Extension (Optional)
5. INSTALL WALL EXTENSION (OPTIONAL) AWWPD Series Wall extension must be installed before the hood (see instructions packed with wall extension). 6. REMOVE BAFFLE FILTERS, GREASE TRAY AND PANEL ASSEMBLY Remove tape on filters. Remove filters from hood (as illustrated below) and set aside. Remove tape on grease tray. -
Page 8: Install Rough-In Plate
8. INSTALL ROUGH-IN PLATE CAUTION Install rough-in plate using 4 x 10-32 locknuts and washers included in hood parts bag. Discard nuts provided with rough-in plate. Refer to the instructions included with the selected blower/rough-in kit (sold separately) for details on installing the rough-in plate. Install the rough-in plate so OCKNUTS that the wiring box is located on the right side as you are facing the hood. -
Page 9: Install Decorative Flue Cover (Optional)
NOTE: To ease removal of the bulbs, use a rubber dishwashing glove or use suction cup tool available from Best. Contact Best Customer Service at 1-800-558-1711 to order suction cup tool, part no. 99526707. -
Page 10: Care
14. CARE ( CONT Grease Drip Rail The grease drip rail should be cleaned frequently. Wash with clean cloth soaked in warm detergent solution. Wash more often if your cooking style generates greater grease like frying foods or wok cooking. Blower Cleaning Access the blower and use vacuum to clean. -
Page 11: Wiring Diagrams
16. WIRING DIAGRAMS Internal blower assembly 120 VAC COLOR CODE HEAT SENTRY THERMOSTAT BLACK GREEN WHITE YELLOW SPEED CONTROL FAN SWITCH LAMP SWITCH ROUGH-IN INTERNAL PLATE BLOWER ASSEMBLY HE0139A Remote blower assembly 120 VAC COLOR CODE HEAT SENTRY BLACK THERMOSTAT GREEN WHITE YELLOW... -
Page 12: Service Parts
17. SERVICE PARTS HL0190 RANGE HOOD WIDTH EY NO ART NO ESCRIPTION 36" 42" 48" 60" SV60887 IGHT SOCKET HOLDER ASSEMBLY SV05921 (120 V, 50 W, GU10 HIELDED HALOGEN BULB BASE SV03435 ™ ENTRY THERMOSTAT SV08549 AN KNOB SV03501 PEED CONTROL SV13924 ALE CONNECTOR SV13923...
