Altec Lansing IMT802 Quick Start Manual

1. Ma ke sure the following items are
included in your package.
AUX Cable
4. Power on your speaker. Go to the Bluetooth Manager of your Bluetooth device.
Search Bluetooth devices and select "Sonic Boom" to start connecting.
When you power on your Sonic Boom speaker for the first
time, it will automatically go into pairing mode. The LED status
light on the button will turn blue and flash as your
speaker searches for a Bluetooth audio source to pair with.
Once you have successfully paired your speaker with a
Bluetooth audio source, the LED status light will stop flashing
and begin shining steadily while remaining blue.
6. Download the "Altec Connect" app (for iOS and Android) to control and
personalize your speaker.
Android iOS
Altec Connect allows you to:
• Use the House Party Pairing Mode to connect an unlimited number of
compatible speakers together for a bigger, more powerful sound.
• Stream and play music from on-demand music steaming services and from
your phone.
• Create unique music playlists with combined music from your phone and
from your music services.
• Control Play/Pause/Skip/Volume/Mute.
• Select Equalizer sound settings.
2. For a look at the various buttons on your speaker, view the graphic below.
AC Power Cable
Power On ...........................................
Power O ............................................Hold
Play / Pause........................................Press
Volume Up / Down..............................Press + or -
Pairing Mode / Disconnect Device....Press - and +
Factory Reset.....................
House Party Pairing...........................Hold
Next Track..........................................Hold +
Previous Track...................................Hold -
12V Car Charger
Bass Boost..........................................Press
-Pairing Additional Bluetooth Smartphone Devices to your Sonic Boom Speaker
By pressing the " - and + " buttons simultaneously, your speaker will go back
into pairing mode. The LED status light will flash, as your speaker searches
for another Bluetooth audio source to pair with.
WARNING!!
Your Sonic Boom speaker has an IP67 rating, as it is waterproof, sandproof and dustproof.
Nonetheless, special precautions must be heeded when using your speaker.
1. The waterproof covers on the top and rear of your speaker must be securely closed when
using your speaker in conditions where water or moisture are present. Failure to do so can
cause damage to your speaker.
2. Avoid using your speaker in standing water or in extreme weather situations such as thunder
and lightning storms.
3. Do NOT allow your speaker to be exposed to any water or moisture while it is being charged
or while it is plugged into a power outlet. Doing so can raise the risk of electric shock and also
cause damage to your speaker.
4. Make sure your speaker is completely dry before charging or plugging it into a power outlet.
Similarly, any phones or other devices paired with your speaker should be kept dry during use
unless otherwise noted by the device's manufacturer.
5. If your speaker is exposed to salt water, wash it o with fresh water and then dry thoroughly
before using.
Quick Start Guide
Hold for 2 Seconds
for 2 Seconds
................Hold - and + for 5 seconds
for 1-2 Seconds (master speaker)
Tap (slave speaker)
3. In order to charge your speaker's internal lithium ion battery follow the steps below:
A. Connect one end of the included AC Power Cable into the AC Charging Port
on the rear of your speaker.
B. Connect the other end of the AC Power Cable into a suitable wall outlet in your home.
C. Make sure that the ON/OFF switch on the rear of your speaker is in the ON position.
Charging: When charging, an orange LED light will illuminate. The orange light will turn o when
your unit is fully charged. A full charge takes approximately 4 hours.
AC
ON/OFF Charging
Switch Port
5.You can also use the included 3.5mm Auxiliary Cable to
connect audio devices through the AUX In port on your speaker.
Important Safety Precautions & Battery Information
1. Do not allow children or the infirm to play with your speaker without adult supervision.
2. Do not expose your speaker to excessive heat, flames or fire.
3. Always press all buttons carefully. Do not manhandle your speaker.
4. Do not use in extremely dry environments, as this can lead to static discharge during usage.
5. Do not expose your speaker to temperatures above 40°C. Keep out of direct sunlight.
6. Do not attempt to repair this product yourself. Contact a qualified service center if your speaker
is in need of service.
7. Do not drop, puncture or expose your speaker to excessive trauma.
8. Your speaker is not intended for commercial use.
9. Do not place near objects that generate a strong magnetic field.
10. Unplug this device when not in use for long periods of time or during lightning storms.
11. The device is equipped with an integrated lithium ion battery. The battery cannot be replaced.
Do not attempt to remove the battery from the device.
12. The battery used in this device may present a risk of fire or chemical burn if mistreated.
13. Please recycle or dispose of your speaker properly based on the laws and rules of your
municipality.
LED Light
