JBL CSS8004 Technical Manual

Technical Manual
JBL CSS8004

SPECIFICATIONS

ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• Nominal Impedance:
• Driver Power Handling:
• Frequency Range (- 10 dB):
Driver/Grille Assembly:
Installed in CSS-BB
BACKCAN:
• Driver Sensitivity (mid-range)
(1W [2.83V], 1m, 2k - 6k Hz):90 dB
SYSTEM COMPONENTS:
• Transducer:
• DC Resistance:
PACKAGE
Warranty Card
59660
Instruction Sheet
445686-001
Carton
445690-001
Inner Carton
445689-001
Inside Carton Wrap
Liner
455688-001
Main PE Bag
445687-001
Accessory
Bag
445675-001
JBL Incorporated, 8500 Balboa Boulevard, P.O. Box 2200, Northridge, California 91329 U.S.A.
8 Ohms
15W
85 Hz - 18 kHz
130 Hz - 18 kHz
100 mm (4 in) speaker, 25 mm (1 in)
diameter voice coil with a Kapton™
coil-former
7.6 ohm
Screw (4)
882-31410-40
6 x 2 1/2
PH,WOOD, ZINC
AURAL SWEEP TEST SPECIFICATIONS:
A. System Aural Sweep Test:
PHYSICAL SPECIFICATIONS:
• Net Weight (ea):
WARRANTY INFORMATION:
• Refer to Warranty Statement packed with each product.
• Transformer Taps:
Orange Green
25V 0.7W 1.3W
White Blue
70V 0.7W 1.3W
100V 1.3W 2.5W
COMPONENT EXPLODED VIEW
Screw (2)
882-31910-10
6 x 3/4
PH,WOOD,BLK ZINC
Driver
444963-001
25V Input (2.5w Tap), 80 Hz to 18 kHz
1.0 lb (.90 kg.)
Gray Yellow Black
2.5W 5W COM
Brown Orange Black
2.5W 5W COM
5W N/C COM
Transformer
444966-001
5W
Transformer, BRKT
444972-001
Nut (6)
445670-001
M4
Washer (6)
445669-001
M4 Non-Slip
Grille
444957-001
01-11
