SWIT S-2110DS User Manual

LED Panel Lights S-2110DA / S-2110DS
Thank you for choosing SWIT products. Please read the instructions before using, and keep it for future reference

Characteristics

◆
576pcs of ultra bright LEDs, 50,000hrs long life time
◆ Max luminance: 3200Lux at 1m distance; 10%-100%
flick-free dimming
◆ 5600K daylight output, 3200K output with filter
LCD touch screen, display and adjust brightness dimming
◆
◆ Power with V-lock battery (S-2110DS)/Gold mount battery
(S-2110DA), or AC-DC adapter
◆ Heat-free technology and constant current circuit design
ensure consistent, stable, and accurate light output in various
environments
Designed for professional videography and photography
◆

Cautions

1. Never disassemble the light or touch its inside with metal
objects to avoid damage.
2. Never solder the LED bulbs by non-professionals
3. Never block the louvers, otherwise LED lighting effect and
lifetime will be greatly reduced
4. Only use the provided adapter to avoid damage.
5. Never crash the LED touch screen with great force to avoid
damage.
6. Only use the light in the temperature range of -10 ~40 .

Specifications

MODEL S-2110DA
LED
Luminance
Beam angle
Color
temperature
Power
Working
DC 11-17V, 4-pin XLR socket
voltage
External power Gold mount plate
Dimension
Weight
Diffuser, 3200K filter, U-shape bracket,
Accessories

USER MANUAL

SWIT Electronics Co., Ltd.
℃ ℃
S-2110DS
576pcs of ultra bright LEDs
3200Lux/m
60°
5600K or 3200K with filter
≤ 4 0W
V-mount plate
403(W)×300(H)×95(D)mm
1.9kg
AC adapter, power cord

Front and rear view

Front view:
Rear view:
1 2 3 4 5 6 7

Operation instructions

1. Open the barn door, set up the U-shape bracket on the light
stand or bracket, and then fasten it. Loosen the knobs on both
sides of the U-shape bracket, and then fix the knobs after
adjusting the lighting angle.
2. Power the light with the AC power adapter or corresponding
battery, turn it on and then the light works.
3. The upper side of the LCD shows brightness. Press "↑"
rotate brightness dimming knob to adjust the brightness from
10%-100%.
4. The bottom side of the LCD shows color temperature:
5600K.
5. The diffuser/filter can be removed from the groove in front of
the LED by pressing button 1.
Tel:+86-25-85805753
Fax:+86-25-85805296
http://www.swit.cc
E-mail: contact@swit.cc
1. Lock catch for the
diffuser
U-shape bracket
2.
3.Gold mount/V-mount
battery plate
4. Brightness dimming
knob
5. Power switch
6. LCD touch screen
4-pin XLR socket
7.
8. Fastening screw
8
" ↓"or
、
