Automatic Turndown; Automatic Shut Off; Nighttime Setback Temperature Mode; Timer Mode - Element4 4 BUTTON REMOTE Operation Manual

Temp - Nighttime setback Temperature mode.
The appliance must be in standby mode, pilot ignited. The room temperature is measured and compared to the nighttime
setback temperature. The flame height is then automatically adjusted to achieve the nighttime setback temperature.

Timer mode.

The appliance must be in standby mode, pilot ignited. The Timer setting allows you to set 2 burner Temp times and 2 burner
Temp times every 24 hrs.
For Temp to operate as a thermostat, TEMP must be set at 4°C or higher.
If the Temp setting is decreased to - -, the motor will turn the valve to the standby position in the moon times and await the
next burner Temp cycle.

Setting the Temperature.

Select either the Temp MODE or the Temp MODE by briefly pressing the SET button.
Hold the SET button until the TEMP display flashes.
Set the desired temperature withÈorÇ.
Press OFF to complete the program.

Setting the Timer.

Select Timer mode by briefly pressing the SET button.
Press and hold the SET button until the P1 is displayed, and the time flashes. Set the hour by pressingÇand set the minutes by
pressingÈ.
Briefly press SET button for the next burner cycle time.
Once all 4 times are set, press OFF to complete the programming.
MANUAL KNOB IN
ON POSITION

Automatic Turndown.

1. In Manual/Temperature/Timer modes, the valve will turn to pilot flame if there is no change in flame height for a six hour
period. In Temperature or Timer mode, if the ambient room temperature changes, the flame height will adjust automatically to
maintain set temperature and the fire will continue to function normally. The valve will turn to pilot flame if the set temperature
and the ambient room temperature remain the same over a six hour period.
2. The valve turns to pilot flame if the temperature in the receiver is higher than 140°F/60°C. The main burner comes back on only
when the temperature is below 140°F/60°C.

Automatic Shut Off.

1. With low battery power in the receiver, the system shuts off the fire completely. This does not happen if the power supply is
interrupted.
2. The system shuts off the fire completely if there is no change in flame height for 5 days.
3. The system shuts off the fire if the main burner does not completely ignite approximately 20 seconds after ignition or after
pushing the Ç button.
Element4 Gas Fireplaces
OPERATING the FIREPLACE
(Gas Valve)
3
E 4
LEMENT
4 B R
UTTON EMOTE
MAIN VALVE KNOB
IN OFF POSITION
